bizhub 950 Specifi cations
Type Console type
Copying system Laser electrostatic transfer method
(dual beam)
Original glass Stationary
Photoconductor OPC
Light source Xenon lamp
Developing method Dry-type dual-component reverse
magnetic brush developing
Fixing method Heat roller
Density adjustment Automatic and manual (9 levels),
Preset density (2 types)
Magnifi cation ratio 1:1 ± 1.0% or less
Enlargement: ×1.214 (121.4%),
×1.294 (129.4%), ×1.545 (154.5%),
×2.000 (200.0%)
Reduction: ×0.939 (93.9%),
×0.772 (77.2%), ×0.647 (64.7%),
×0.500 (50.0%)
Minimal: ×0.930 (93.0%) (fi xed)
XY Zoom (interlocked and individual):
0.250 to 4.000 (25.0%–400.0%)
(in 0.001 increments)
User-set zoom ratio: 3
Resolution 600 dpi
Copy paper Tray 1, 2, 3: 11 to 57 lb. bond (216 g/m
Bypass Tray: 11 to 65 lb. bond (244 g/m
Any tray using Embossed setting:
14 to 57 lb. bond (216 g/m
LCT: 11 to 80 lb. bond (300 g/m
NOTE: Ink-jet paper is unavailable.
Copying speed 95 copies/min. (8.5" × 11"), 76 copies/min.
(8.5" × 11"R), 63 copies/min. (8.5" × 14"),
54 copies/min. (11" × 17"), 92 copies/min.
(5.5" × 8.5", 5.5" × 8.5"R)
Set quantity 1 to 9999 sheets or 1 to 9999 sets
Memory 256 MB (RAM) + 30 GB (HDD)
Original document Type: sheets/ books (using original glass)
Size: 11.93" × 18.11" (303 mm × 460 mm)
maximum
Copy size Max. 12.36" × 18.11" (314 × 460 mm) –
3.94" × 5.83" (Min. 100 × 148 mm)
Image loss: leading and trailing edges
2.0 mm ± 2.0 mm, front and rear 1.5 mm
± 1.5 mm
Konica Minolta
bizhub PRO 950
Specifi cation & Installation Guide
2
)
2
)
2
)
2
)
Tray capacity Bypass tray: 150 sheets (21 lb. paper)
Main body trays 1 and 2 (universal tray):
500 sheets (21 lb. paper)
Main body trays 3 (universal tray):
1,000 sheets (21 lb. paper)
Warm-up time Approx. 5.5 minutes
First-page copy time Approx. 3.1 seconds (8.5" x 11")
Sound power level Main body: 79 dB (operating)/
58 dB (standby)
Power requirements AC 208–240 V, 16 A, 60 Hz
Power consumption 3.66 KW or less (with full options)
Weight Approx. 628.3 lbs. (Main body + ADF)
Dimensions Main body + ADF
39.25" (W) x 30.7" (D) x 47.4" (H)
Main body + ADF + LU-407
+ FS-611 + MK-721 + TU-502
132.75" (W) x 30.7" (D) x 47.4 (H)
Space requirements Main body + ADF + LU-407
+ FS-611 + MK-721 + TU-502
144.6" (W) x 76" (D)
7.87" (200 mm) or more on the back
5.91" (100 mm) or more on both sides
Duty Cycle
Up to 750,000. Maximum monthly print volume
supported under standard vendor supplied service.
Defi nes the upper end of the expected customer volume
for the device. Customers should consider multiple
machines if average monthly volume approaches duty
cycle on a continual basis.
4/2009
