Connection from the setting computer

Connect the computer for setting to the TM printer by the wireless LAN. The setting of the
wireless LAN of the setting computer is set for the Dynamic Status Sheet.
As for the setting method of the setting computer, refer to the manual of the computer
used.
• Network Mode (Ad‐Hoc)
• SSID (Ex: EpsonNetIBSS)
• IP Address (Ex: 192.168.192.2)
(Donʹt set the same address as the IP Address of the printer to the setting computer.
Example: If the IP Address is 192.168.192.168, the IP Address of the setting computer should
be set to another number, such as 192.168.192.2. The same address (192.168.192.168) cannot be
used.)
• Channel (Ex: 11 ch)
When you set up a TM printer equipped with more than one wireless LAN interfaces, turn
on only one printer. If more than one printer is turned on at the same time, the TM printer
cannot be set up.
At this stage, the TM printer can communicate with the setting computer.

Setting of the UB-R03

Set up the UB‐R03 according to the following steps.
1
Boot the TMNet WinConfig V3 of the setting computer.
Select [All Programs]-[EPSON TMNet WinConfig V3]-[TMNet WinConfig].
40
