Technical Specifications; Care And Maintenance - AT&T Plug&Share 6800B4X User Manual

Technical Specifications

Technical Specifications
Standards
• IEEE 802.11
• IEEE 802.11b
• IEEE 802.3u
• IEEE 802.3
VPN Pass Through/Multi-Sessions
• PPTP
• L2TP
• IPSec
Advanced Firewall Features
• NAT with VPN Pass through
• MAC filtering
• IP filtering
• URL Filtering
• Domain Blocking
• Scheduling
Device Management
• Web-based (Internet Explorer® v5.5 or later)
Wireless Data Rates
• With Automatic Fallback
• 4X Turbo Speed Technology
• 22 Mbps
• 11 Mbps
• 5.5 Mbps
• 2 Mbps
• 1 Mbps
Encryption
• WEP 64/128/256-bit RC4
Media Access Control
• CSMA/CA with ACK
Frequency Range
• 2.4GHz to 2.472GHz
Operating Range
• Indoors: Up to 300 feet (100m)
• Outdoors: Up to 980 feet (300m)

Care and maintenance

Always unplug this product before cleaning. Use a damp cloth to clean the exterior housing only. Do not
use liquid cleaners or aerosol cleaners.
Periodically visit our web site to check for free driver upgrades that can help maximize the performance
and reliability of your wireless network:
www.plugandshare.att.com
AT&T Plug&Share 22 Mbps Turbo Wireless Router 6800B4X
™
Modulation Technology
• DSSS: Direct Sequence Spread Spectrum
Modulation Techniques
• Barker (1Mbps/0db)
• Barker (2Mbps/3db)
• CCK (5.5Mbps/5.5db)
• PBCC (5.5 Mbps/1.5db)
• CCK (11Mbps/8.5db)
• PBCC (11Mbps/4.5db)
• PBCC (22Mbps/8.5db)
Transmit Power
• 15dBm ± 2dB
External Antenna Type
• Omni-directional
Ethernet Cable
• RJ45 Ethernet cable
Operating Climate Range
• Temperature: 32° to 131°F (0° to 55°C)
• Humidity: 32% to 90% relative humidity
Storage Climate Range
• Temperature: -40° to 140°F (-40° to 60°C)
• Humidity: 15% to 90% relative humidity
Power Input
• External Power Supply DC 5V, 2.4A
Safety & Emissions
• FCC
• UL
76
