DIP Switch Settings

Located on the rear panel of the printer are a series of small switches used to set
various communication parameters and option settings. Use a small, blunt pointed
object like a pencil to change the position of these switches.
Use the instructions below and the table on the next page to set the
dip switches for your printing requirements.
DIP Switch
1 & 2
3
4
5 & 6
7
8
Note
If changes are made to DIP switch settings while the printer is powered
on, the power must be cycled for the changes to be recognized.
QLS-4100 X
Function
RS-232 Serial Baud Rate
RS-232 Handshaking
Parallel or Serial Communication
Not Used (Factory Set to Off)
Cutter and Cutter/Stacker Option
Standard or Windows Host Mode
24
