Label Counter

The QLS-4100 X can dynamically display either the ongoing total number of la-
bels that have been printed since the printer was last powered up or the number of
labels that have been printed within any specific batch or print job. The printer's
label counting feature can also be turned off.
To set the Label Counter function:
Press the NEXT or PREVIOUS key until the Counter menu is displayed.
1
Pause: Counter
2 Press the + or - key until the desired counting option is displayed.
Available Choices are:
• Off - no counter is displayed
• Total - count of labels printed since last power on
• Batch - count of labels printed in current batch
Press the SELECT key to confirm your choice.
3
The selected counter mode will now appear on the display while printing.
Ready
Total
Counter
Ready
Batch
Counter
000010 of 0000150
QLS-4100 X
Off
00000068
*
47
