QuickLabel Systems QLS-4100X Operation & Setup Manual page 105

Replacement Parts
Part Number
14076-001
14039-001
14039-401
14041-101
14039-101
14039-501
14058-000
14057-201
14057-301
23701-211
24034-002
24034-004
13832-000
14050-400
14050-050
14050-500
RN1716
14109-020
14046-200
10609-016
25747-000
23682-114
14099-000
24878-000
12361-013
26599-800
14039-301
26599-100
26599-600
26599-000
26599-200
26599-700
26588-100
26599-300
26599-400
26599-500
42592-001
42545-000
25995-000
42455-001
25459-200
24164-010
24164-000
10787-001
* Recommended Spare Parts
Parts specifications are subject to change without notice.
Contact QuickLabel Systems Technical Support to identify the correct parts and obtain current pricing.
Please have the serial number of your printer available.
QLS-4100 X
Description
*Printhead
*Drive Roll (black polyurethane)
*Drive Roll (blue silicone)
*Pinch Roller (aluminum with coating)
*Platen Roller (black polyurethane, 60 Dur., bearings installed)
*Platen Roller (blue silicone, 50 Dur., bearings installed)
*Bearing Block Assembly (drive roll)
*Lever Printhead Lift (4)
*Lever Drive Roll Lift
*Belt Timing 3mm 211T
*Fuse 6.3 A (110VAC)
*Fuse 4.0 A (220VAC)
*Cleaning Pads (case of 50)
Platen Shaft (4)
Drive Shaft
Drive Shaft Stub
Drive Snap Ring (2)
Collar (9)
Shaft End Plate (5)
#6 Pan Head Philips
Motor Assy, Main
Pulley, Drive
Gas Spring, Drive Station
Motor Assy, TTR (4)
Slip Clutch, TTR (4)
Sensor, Optical Encoder
Roller, Optical Encoder
Sensor, TTR / Head Up (9)
Thru Sensor Probe
Reflective Sensor Probe
Sensor Amplifier Assy (2)
Pressure Switch Assy
Harness, Assy Printhead (4)
Harness, Assy Motor
Harness, Assy TTR Sensors
Harness, Assy Head Up Sensors
Controller, Assy PCB
Power Supply, Assy PCB w/ Microstepper, Assy PCB IM483
Microstepper, Assy PCB IM483 - only
Keypad, Assy PCB
Display, LCD w/ harness
Cable, Parallel
Cable, Serial
Cord, Power
105
