Features of the QLS-4100 X

Facing the left side of the QLS-4100 X with its cover lifted, you can view the
media unwind, print stations, and related mechanical parts.
The items below identify the QLS-4100 X components as shown in the illustration
on the following page:
Media Retainer
1
Media Supply Mandrel
2
3 TTR Rewind - print station # 4
4 TTR Supply - print station # 4
5 TTR Rewind - print station # 3
6 TTR Supply - print station # 3
7 TTR Rewind - print station # 2
8 TTR Supply - print station # 2
9 TTR Rewind - print station # 1
10 TTR Supply - print station # 1
11 Print Station Lift Lever
12 Drive Roller Lift Lever
Drive Roller
13
Pressure Roller
14
Print Station # 1
15
16 Print Station # 2
17 Print Station # 3
18 Print Station # 4
19 Media Travel Roller
20 Media Sensor Assembly - Gap and Reflective
21 Lower Media Guide Roller
22 Media Dancer Arm
23 Upper Media Guide Roller
QLS-4100 X 13
