Keyboard Follow Management - Arturia MOOG MODULAR V 2.6 User’s User Manual

7.4.1

Keyboard follow management

Threshold
Low/High
Bend/Portamento
Slope
Pivot
Threshold
Low/High
High
Bend/Portamento
There are four independent keyboard follows. Each possessing a slope setting with the "Slope"
knob, a pivot note chosen in the "pivot" display and a threshold note chosen with the
"threshold" display begin from which the slope is null.
Each of the keyboard follows can generate a trigger signal. Two displays allow the choice of a
low and high note. When the keyboard detects a note between the 2 limits, the trigger signal
is active as long as the note remains active. When the note is outside of the limits, the trigger
signal remains inactive. If the notes selected for the upper and lower limits are such that the
lower note is higher than the upper, then the note detected by the keyboard must be outside
of the limits to activate the trigger signal.
The "Portamento" and "PitchBend" buttons of each of the keyboard follows allows the
affectation of a portamento or pitch bend. The pitch bend can be inverted (the modulation is
negative when the command is positive), which allows us, for example, to lower the filter cut-
off frequency insofar as the tuning of the oscillators is raised.
It is also possible to replace the portamento (continuous glide of the frequency) with a
glissando (frequency glide by semi-tone)
ARTURIA – MOOG MODULAR V 2.6 – USER'S MANUAL
Keyboard follow
Sets the slope of the keyboard follow
Selects the pivot note of the keyboard follow
Selects the threshold note of the keyboard follow
Selects the low (high) note of the generator for the trigger of the
keyboard follow
Selects the high note of the generator for the trigger of the keyboard
follow which can also be inverted
Request for affectation of a pitch bend (portamento) or glissando to the
keyboard follow
Keyboard follow management
Slope
Pivot
97
