7.2.4

Phaser

Amount Sets the depth of the phaser action
Rate Sets the speed of the phaser
Sweep Sets the phaser resonance
Stereo width Sets the width of the stereo space
Dry Sets the gain applied to the input signal
Stages Sets the phaser type (6 or 12 stages)
Wet Sets the gain applied to the treated signal
VCA1-VCA2 Connects the phaser to the VCA1 or VCA2 output
The phaser module treats the signal coming from the 2 output amplifiers, eventually treated
by an equalizer, in function with the state of the 2 "VCA1" and "VCA2" interrupters.
The action consists of dephasing the input signal and combining it with the original signal. Thus
we can have a filter that combs (with notches) the frequency spectrum to the rhythm of an
oscillator which follows the frequency set with the "rate" button. The "depth" button sets the
amplitude for the action of the filtering, while "Resonance" amplifies certain harmonica. The
rotating "stereo width" button sets the amplitude of the stereophonic aspect of the phaser.
When the "stereo width" is set to 0, the left and the right channel are in phase. When it is set
to 0.5, the sound seems to rotate, and when it is set to 1, the sound seem to go from one side
to another.
There are two types of phaser, one has 6 levels, the other has 12, set with the "type" selector.
A 6-stage phaser has 3 notches, and a 12-stage has 6.
The rotating "dry" and "wet" buttons are respectively used to set the amplitude of the original
signal and the treated signal.
ARTURIA – MOOG MODULAR V 2.6 – USER'S MANUAL
Amount
Rate
Stereo width
Dry
VCA1-VCA2
Phaser
Sweep
Stages
Resonance
Wet
