Arturia MOOG MODULAR V 2.6 User’s User Manual page 60

MIN
6.3.5.5 Multiple assigned parameters
It is possible to assign multiple parameters to a single control. This allows you to change many
parameters with one fader or knob.
Activate "Learn" mode, select a parameter (GUI control)
Tweak control to assign it (optionally setup minimum and maximum)
Select a second parameter
And tweak the same control
Deactivate "Learn" mode
Tweaking assigned control should modify both parameters with regards to assignation setup
(Min, Max).
6.3.5.6 Tricks
The Oscillator 1 to 9 tune controls have two parameters: FINE and COARSE tune. If
"Learn" mode is ON, clicking on control provides access to the assignation of the FINE
parameter, shift+clicking on control provides access to assignation of the COARSE
parameter.
60
Output
parameter
values
MIN
Output
parameter
values
MAX
Input
control
values
POSITIVE SLOPE
parameter_value = MIN + (MAX – MIN) * control_value
MAX
Input
control
values
DEFAULT
Output
parameter
values
MIN
NEGATIVE SLOPE
ARTURIA – MOOG MODULAR V 2.6 – USER'S MANUAL
Input
control
MAX
values
