P
REFACE
This manual describes how to install and use the 19" Media Converter
Chassis System. The system introduced here is capable of housing up to
sixteen media converters, each of which offers one channel media conversion
solution:
100BASE-TX ↔ 100BASE-FX
10/100BASE-TX ↔ 100BASE-FX
100BASE-FX ↔ 100BASE-FX (multi-mode ↔ single-mode)
1000BASE-T ↔ 1000BASE-SX/LX
1000BASE-SX ↔ 1000BASE-LX
In this manual, you will find:
• Introduction on the Chassis System
• Product features
• Illustrative LEDs functions
• Installation instructions
• Specifications
• Ordering Information
The chassis shown in the figures of this manual is fitted with
Attention!
redundant power supplies. Proprietary media converters and a
second power supply shall be ordered separately!
(multi-mode ↔ single-mode)
