Step 1: Connect the supplied AC power cord to the back of the chassis.
Step 2: Attach the plug into a standard AC outlet with a voltage range from
100~240Vac.
Step 3: Turn on the chassis system by flipping the switch beside the receptacle to
ON position. The LED on the front panel of power supply will come on
then.
.
Installing and Removing the Power Supply
To remove a power supply out the chassis, you have to loose the hand screw
counter clockwise and pull out the power supply from the chassis.
To install a power supply to the chassis, you have to fasten the hand screw
clockwise and slide in the power supply to the chassis.
You c a n slid e in a nd o ut the p ower sup p ly from the b ay,
fa sten or loose the ha nd sc rew c loc kwise or c ounter
c loc kwise b y using hand or sc re wdriver.
If the Chassis System needs to work alone, you can
Attention!
stick up four Rubber foot below the chassis!
11
