1. Parts of the Printer

Upper Unit Lock
Release Lever:
Power Indicator:
Print Tray:
Paper Guides:
Paper Feeding Tray:
(Tray)
Cassette 1:
Cassette 2:
(option)
Power Switch:
Use to open the Upper Unit.
Light indicates when the Printer is turned ON.
Prints are output from the Printer, face down onto this tray
which can hold up to 500 sheets of standard paper.
Slide the guides to secure the paper stack.
Capable of holding up to 150 sheets of A4 (8.5" × 11")
paper.
Capable of holding up to 250 sheets of standard-size paper.
(A4, A3, B4 or 8.5" × 11", 11" × 17", 8.5" × 14" )
Capable of holding up to 250 sheets of standard-size paper.
(A4, A3, B4 or 8.5" × 11", 11" × 17", 8.5" × 14")
Use to turn the Printer ON and OFF.
