Space Requirements
SR24 iT Scanner
There should be a clearance of the following dimensions between the wall and the rear of the
unit as well as it's right and left sides to provide ample space for the ventilation ports to dis-
sipate heat.
100 mm
503 mm or 19-3/4"
or 4"
100 mm
or 4"
1. Installation Precautions
100 mm
or 4"
1-3
