AGFA SR 24 iT Operator's Manual page 15

viii
Contents
13. Selecting the Output Format .............................................. 2-25
14. Using Auto Masking .......................................................... 2-27
15. Manual Masking Panels (Optional) ................................... 2-28
16. Using Manual Masking ...................................................... 2-29
17. Using Centering and Fit ..................................................... 2-31
18. Using the Cycle Print Mode .............................................. 2-32
19. Selecting the Connection Mode ......................................... 2-34
20. Selecting the Resolution .................................................... 2-35
21. Registering the Job Program .............................................. 2-36
22. Calling the Job Program .................................................... 2-37
23. Using the Electrical Zoom ................................................. 2-38
24. Adjusting the Illumination of the Screen ........................... 2-40
25. Replacing the Projection Lamp ......................................... 2-41
Chapter 3
1. Parts of the Printer ................................................................. 3-2
2. Troubleshooting and Maintenance ........................................ 3-4
Chapter 4
1. Specifications ......................................................................... 4-2
Selecting the paper source ............................................... 2-25
Selecting the print format ................................................. 2-26
Selecting Auto Masking ................................................... 2-27
Operating Conditions for Auto Masking ......................... 2-27
Selecting Trimming ......................................................... 2-29
Defining the Print Area .................................................... 2-29
Clearing a Defined Print (Scan) Area .............................. 2-30
Selecting Masking ............................................................ 2-30
Centering .......................................................................... 2-31
Fit ..................................................................................... 2-31
Specifying the interval between scanning operations ...... 2-32
Operating in the Cycle Print Mode .................................. 2-33
Zoom + ............................................................................. 2-38
Zoom - .............................................................................. 2-38
Clearing the Zoom magnification .................................... 2-39
MSP 3000 Printer
Replenishing the Paper Supply .......................................... 3-4
Replacing the Toner Cartridge ........................................... 3-7
Clearing Misfeeds .............................................................. 3-9
Solving Irregular Printing Problems ................................ 3-12
Miscellaneous
SR24 iT............................................................................. 4-2
SR24iT+ A3/A4 Laser Printer......................................... 4-3
