DSL-300 ADSL Ethernet Modem User's Guide

Technical Specifications

Standards:
ITU G.992.1 (G.dmt)
ITU G.992.2 (G.lite)
ITU G.994.1 (G.Hs)
ANSI T1.413 (Issue 2)
Protocol:
TCP/IP
Data
G.dmt full rate: Downstream up to 8 Mbps
Transfer
Upstream up to 640 Kbps
Rate:
G.lite: Downstream up to 1.5 Mbps
Upstream up to 512 Kbps
Media Interface
RJ-11 port ADSL telephone line connection
Exchange:
RJ-45 port for 10BASET Ethernet connection
DC inputs:
Input: 120V AC 60Hz 24W
Power Adapter:
Output: 18V DC 750 mA
Power
10 Watts (Max)
Consumptio
n:
Operating
0° to 50° C (32° - 122° F)
Temperatur
e:
Humidity:
5 to 95% (non-condensing)
Dimensions
223.3mm x 131.7mm x 35mm
:
Weight:
455gm (1 lb.)
EMI:
CE Class B
Safety:
UL/CUL TUV
20
General
Physical and Environmental
FCC Class B C-Tick BSMI
A
