- Page 1 VDSL Switch-VS2512A VDSL Splitter-VM2524 VDSL Splitter-VM2548 Installation Guide...
- Page 3 Installation Guide VDSL Switch-VS2512A VDSL Switch supporting 12 VDSL Lines, with 1 Slot for Optional Gigabit Uplink, 10/100BASE-TX, or 100BASE-FX Modules VDSL Splitter-VM2524 VDSL Splitter supporting 24 VDSL Lines VDSL Splitter-VM2548 VDSL Splitter supporting 48 VDSL Lines...
- Page 4 Singapore 229594 Phone: +65 238 6556 Fax: +65 238 6466 Internet: www.acctontech.com Accton is a trademark of Accton Technology Corporation. Other trademarks or brand names mentioned herein are trademarks or registered trademarks of their respective companies. VS2512A VM2524 VM2548 E072002-R01...
- Page 5 Accton Technology Corporation Limited Warranty: Accton warrants all its products to be free of manufacturing defects in workmanship and materials, under normal use and service, for the applicable warranty term. All Accton products carry a standard 90-day limited warranty from the date of purchase from Accton or its Authorized Reseller.
-
Page 6: Limited Warranty
Limited Warranty WARRANTIES EXCLUSIVE: IF AN ACCTON PRODUCT DOES NOT OPERATE AS WARRANTED ABOVE, CUSTOMER'S SOLE REMEDY SHALL BE REPAIR OR REPLACEMENT OF THE PRODUCT IN QUESTION, AT ACCTON’S OPTION. THE FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER. -
Page 7: Japan Vcci Class A
Compliances FCC - Class A This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause interference to radio communications. It has been tested and found to comply with the limits for a Class A computing device pursuant to Subpart B of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment. - Page 8 CE Mark Declaration of Conformance for EMI and Safety (EEC) This information technology equipment complies with the requirements of the Council Directive 89/336/EEC on the Approximation of the laws of the Member States relating to Electromagnetic Compatibility and 73/23/EEC for electrical equipment used within certain voltage limits and the Amendment Directive 93/68/EEC.
-
Page 9: Safety Compliance
Safety Compliance Warning: Fiber Optic Port Safety When using a fiber optic port, never look at the transmit laser while it is powered on. Also, never look directly at the fiber TX port and fiber cable CLASS I LASER DEVICE ends when they are powered on. - Page 10 Wichtige Sicherheitshinweise (Germany) Bitte lesen Sie diese Hinweise sorgfältig durch. Heben Sie diese Anleitung für den späteren Gebrauch auf. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie keine Flüssigoder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung.
-
Page 11: Table Of Contents
Contents Chapter 1: About the VDSL Switch-VS2512A Overview VDSL Technology Switch Architecture Management Options Description of Hardware VDSL Switch-VS2512A VDSL Splitter-VM2524 and VDSL Splitter-VM2548 Ethernet-over-VDSL CPE Status LEDs Optional Media Extender Modules Power Supply Receptacle 1-11 Key Features 1-12 Chapter 2: Network Planning Introduction to Switching Sample Applications Internet Connections... - Page 12 Contents Appendix A: Troubleshooting Diagnosing Switch Indicators Power and Cooling Problems Installation In-Band Access Appendix B: Cables Specifications. Twisted-Pair Cable and Pin Assignments 10BASE-T/100BASE-TX Pin Assignments 1000BASE-T Pin Assignments 1000BASE-T Cable Requirements Cable Testing for Existing Category 5 Cable Adjusting Existing Category 5 Cabling to Run 1000BASE-T RJ-21 Port Pin Assignments Console Port Pin Assignments DB-9 Port Pin Assignments...
-
Page 13: Chapter 1: About The Vdsl Switch-Vs2512A
Chapter 1: About the VDSL Switch-VS2512A Overview Accton’s Ethernet-over-VDSL system consists of end-user CPEs (Customer Premise Equipment) connected to a VDSL switch and splitter by standard telephone cable. The VDSL connection delivers an Ethernet data link rated up to 15 Mbps symmetric (full duplex), while simultaneously supporting standard telephone services. -
Page 14: Vdsl Technology
About the VDSL Switch-VS2512A VDSL Technology VDSL (Very High Bit-Rate Digital Subscriber Line) is at the high-end of all the DSL technologies, offering the best combination of fiber optics and copper to provide high-speed broadband Internet access. VDSL’s primary application is in providing a broadband data service to multi-tenant residential or commercial buildings. -
Page 15: Switch Architecture
Overview Switch Architecture The VDSL Switch-VS2512A employs a wire-speed, non-blocking switching fabric. This permits simultaneous wire-speed transport of multiple packets at low latency on all ports. This switch also features full-duplex capability on all ports, which effectively doubles the bandwidth of each connection. Management Options This switch contains a comprehensive array of LEDs for “at-a-glance”... -
Page 16: Description Of Hardware
About the VDSL Switch-VS2512A Traffic Priority This switch provides Quality of Service (QoS) by prioritizing each packet based on the required level of service, using four distinct categories with Weighted Round Robin Queuing. It uses IEEE 802.1p and 802.1Q tags to prioritize incoming traffic based on input from the end-station application. -
Page 17: Vdsl Splitter-Vm2524 And Vdsl Splitter-Vm2548
Description of Hardware The switch also includes key system and port indicators that simplify installation and network troubleshooting. The front panel has LEDs for Ethernet link status/activity and VDSL link status, as well as system status indicators. The following figure shows the components of the VDSL Switch. Expansion Slot Stacking Master Ethernet Port... -
Page 18: Ethernet-Over-Vdsl Cpe
About the VDSL Switch-VS2512A The following figures shows the components of the VDSL Splitter-VM2524 and VDSL Splitter-VM2548. Line VDSL Splitter -VM2524 VM2524 VDSL Line Connector (to end users) VDSL Switch VDSL Line Connector PBX/MDF Connector (to switch) (to POTS provider) Figure 1-3. -
Page 19: Status Leds
Description of Hardware Status LEDs The LEDs, which are located on the VS2512A front panel for easy viewing, are shown below and described in the following table. VDSL Ethernet 9 10 11 12 Stacking Power Activity Activity Link Link/Speed Master Diag Figure 1-5. -
Page 20: Optional Media Extender Modules
About the VDSL Switch-VS2512A Optional Media Extender Modules Optional 1000BASE-SX Module (VM2512A-1SX-SC-M) 1000BASE-SX Multimode Module VM2512A-1SX-SC-M Figure 1-6. Single-Port 1000BASE-SX Gigabit Module Using multimode fiber optic cable, the 1000BASE-SX port can be connected to a remote site up to 550 m (1805 ft) away. The 1000BASE-SX Gigabit module operates at 1 Gbps, with support for full-duplex mode and flow control. - Page 21 Description of Hardware 1000BASE-SX GBIC transceivers provide one short-wavelength (850 nm) Gigabit port that can be used for a high-speed backbone or server connection. This port can be connected to a site up to 220 m (722 ft) away with 62.5/125 micron multimode fiber cable, or up to 500 m (1641 ft) with 50/125 micron multimode fiber cable.
- Page 22 About the VDSL Switch-VS2512A Optional 10/100BASE-TX Module (VM2512A-4TX) 10/100BASE-TX Module VM2512A-4TX Figure 1-11. 4-Port 10/100BASE-TX Module Using Category 3, 4, or 5 twisted-pair cable for 10 Mbps links or Category 5 twisted-pair cable for 100 Mbps links, you can connect to another device up to 100 m (328 ft) away.
-
Page 23: Power Supply Receptacle
Description of Hardware Optional 100BASE-FX Module (VM2512A-4FX-MTRJ-S) 100BASE-FX Singlemode Module VM2512A-4FX-MTRJ-S Figure 1-14. 4-Port 100BASE-FX Single-mode Module Using 9/125 micron single-mode fiber cable, the 100BASE-FX ports can be connected to a remote site up to 20 km (12.43 miles) away. The 100BASE-FX module operates at 100 Mbps, with support for full-duplex mode and flow control. -
Page 24: Key Features
About the VDSL Switch-VS2512A Key Features VDSL features (CPE side) include: • High-speed Internet access over existing phone lines • VDSL connection provides the following rate/range options: Rate Mode Max. Range 15 Mbps Symmetric 1070 m (3500 ft) 10 Mbps Symmetric 1220 m (4000 ft) 5 Mbps... - Page 25 Key Features • Provides Store-and-Forward switching for intra-VLAN traffic • Supports wire-speed Layer 2 switching • Supports flow control, using back pressure for half duplex and IEEE 802.3x for full duplex • Broadcast Storm Control • Desktop or rack-mountable Management features include: •...
- Page 26 About the VDSL Switch-VS2512A 1-14...
-
Page 27: Chapter 2: Network Planning
Chapter 2: Network Planning Introduction to Switching A network switch allows simultaneous transmission of multiple packets via non-crossbar switching. This means that it can partition a network more efficiently than bridges or routers. The switch has, therefore, been recognized as one of the most important building blocks for today’s networking technology. -
Page 28: Internet Connections
Network Planning Internet Connections The figure below shows a VDSL Switch-VS2512A and VDSL Splitter-VM2524 providing a broadband data service to a multi-tenant residential or commercial building. In this implementation, fiber optic cable carries data from a telephone company’s central office to the building; then the installed telephone copper wires take the data and deliver it to individual units within that building. -
Page 29: Making Vlan Connections
Sample Applications Making VLAN Connections VLANs can be based on port groups, or each data frame can be explicitly tagged to identify the VLAN group to which it belongs. When using port-based VLANs, ports can be assigned to one or more groups. Port-based VLANs are suitable for small networks. -
Page 30: Application Notes
Network Planning Application Notes For network applications that require routing between dissimilar network types, you can attach the VDSL switch directly to a router. The multimode fiber modules are fitted with SC connectors, but you can attach an ST plug to the switch using Accton’s optional SC-to-ST plug converter (Part Number: ST5002, for 62.5/125 micron cable only). -
Page 31: Chapter 3: Installing The Vdsl Switch And Splitter
Chapter 3: Installing the VDSL Switch and Splitter Preparing the Site In multi-tenant buildings, phone lines coming from the service provider are generally attached to a PBX or MDF distribution box in the basement. These lines run from the PBX to a punch-down block, and then up to the POTS terminals for individual users. The following figure displays the normal wiring before installing the VDSL switch and splitter. -
Page 32: Package Contents
Installing the VDSL Switch and Splitter Package Contents VDSL Switch-VS2512A • VDSL Switch-VS2512A • Four adhesive foot pads • Bracket Mounting Kit containing two brackets and four screws for attaching the brackets to the switch • One Power Cord—either US, Continental Europe or UK •... - Page 33 Mounting • Power requirements: 100 to 240 VAC (± 10%) at 50 to 60 Hz (± 3Hz). The switch and splitter power supplies automatically adjust to the input voltage level. Make sure that a properly grounded power outlet is within 2.5 m (8 ft) of the switch and splitter.
-
Page 34: Desktop Or Shelf Mounting
Installing the VDSL Switch and Splitter Mount the device in the rack, using four rack-mounting screws (not provided). E x p a n s io n M o d u St ac kin Do wn M as te Ac tiv VD SL Of f Lin k... -
Page 35: Installing An Optional Module Into The Switch
Mounting If installing a single switch only, go to “Powering On the Switch” at the end of this chapter. If installing multiple switches, attach four adhesive feet to each one. Place each device squarely on top of the one below, in any order. Installing an Optional Module into the Switch 1 0 0 0 B A S E... -
Page 36: Installing A Gbic Transceiver
Installing the VDSL Switch and Splitter Installing a GBIC Transceiver Figure 3-6. Installing a GBIC Transceiver Caution: Install only 5 V GBIC transceivers into the module slots. You can install a GBIC transceiver as described below: Insert the transceiver with the SC connector facing out toward you. Note that the transceiver is keyed so that it can only be installed in one orientation. -
Page 37: Connecting To The Stack's Backplane
Powering On the Switch Connecting to the Stack’s Backplane Plug one end of the provided stack cable in the “Down” port of the top unit and the other end to the “Up” port of the next unit. Repeat this step for each unit in the stack. Form a simple chain starting at the “Down”... - Page 38 Installing the VDSL Switch and Splitter Check the front-panel LEDs as the switch is powered on to be sure the Power LED is lit. If not, check that the power cable is correctly plugged in. The switch will automatically select the setting that matches the connected input voltage. Therefore, no additional adjustments are necessary when connecting it to any input voltage within the range marked on the front panel.
-
Page 39: Chapter 4: Making Network Connections
Chapter 4: Making Network Connections Twisted-Pair Devices Each device requires an unshielded twisted-pair (UTP) cable with RJ-45 connectors at both ends. For 100BASE-TX connections, Category 5 cable is required; for 10BASE-T, Category 3, 4 or 5 cable can be used. Cabling Guidelines The RJ-45 ports on the switch support automatic MDI/MDI-X operation, so you can use standard straight-through twisted-pair cables to connect to any other network... -
Page 40: Wiring Closet Connections
Making Network Connections ES2002-TS VDSL CPE Room Basement Punch Telephone Line Down from Central Office Blocks PBX/MDF VDSL Line Line Line VDSL Splitter -VM2524 VDSL VM2524 Splitter 100BASE-FX Singlemode Module VDSL Switch -VS2512A Stacking VDSL Ethernet Stacking Power Reset Activity Activity VM2512A-4FX-MTRJ-S Link... -
Page 41: Fiber Optic Devices
Connecting to the Punch-down Blocks Label the cables to simplify future troubleshooting. To end users To ISP (Internet) Patch Panel 1000BASE-SX Multimode Module 1000BASE-SX Multimode Module VDSL Switch -VS2512A VDSL Switch -VS2512A T ig er S w it ch 10 /1 0 0 T ig er S w it ch 10 /1 0 0 6 7 2 4 L 3 6 7 2 4 L 3... - Page 42 Making Network Connections Caution: This switch uses lasers to transmit signals over fiber optic cable. The lasers are compliant with the requirements of a Class 1 Laser Product and are inherently eye safe in normal operation. However, you should never look directly at a transmit port when it is powered on.
-
Page 43: Appendix A: Troubleshooting
Appendix A: Troubleshooting Diagnosing Switch Indicators The VDSL Switch-VS2512A can be easily monitored through panel indicators to identify problems.The table below describes common problems you may encounter and possible solutions. If the solutions in the table fail to resolve the problem contact Accton Technical Support for advice. -
Page 44: Installation
Troubleshooting Installation Verify that all system components have been properly installed. If one or more components appear to be malfunctioning (such as the power cord or network cabling), test them in an alternate environment where you are sure that all the other components are functioning properly. -
Page 45: Appendix B: Cables
Appendix B: Cables Specifications. Cable Types and Specifications Cable Type Max. Length Connector 10BASE-T Cat. 3, 4, 5 100-ohm UTP 100 m (328 ft) RJ-45 100BASE-TX Cat. 5 100-ohm UTP 100 m (328 ft) RJ-45 1000BASE-SX 50/125 or 62.5/125 micron core MMF See the following table SC or ST 1000BASE-LX 9/125 micron SMF... -
Page 46: 10Base-T/100Base-Tx Pin Assignments
Cables 10BASE-T/100BASE-TX Pin Assignments For 100BASE-TX/10BASE-T connections, a twisted-pair cable must have two pairs of wires. Each wire pair is identified by two different colors. For example, one wire might be red and the other, red with white stripes. Also, an RJ-45 connector must be attached to both ends of the cable. -
Page 47: 1000Base-T Pin Assignments
Twisted-Pair Cable and Pin Assignments 1000BASE-T Pin Assignments 1000BASE-T ports switch support automatic MDI/MDI-X operation, so you can use straight-through cables for all network connections to PCs or servers, or to other switches or hubs. The table below shows the 1000BASE-T MDI and MDI-X port pinouts. These ports require that all four pairs of wires be connected. -
Page 48: Adjusting Existing Category 5 Cabling To Run 1000Base-T
Cables Adjusting Existing Category 5 Cabling to Run 1000BASE-T If your existing Category 5 installation does not meet one of the test parameters for 1000BASE-T, there are basically three measures that can be applied to try and correct the problem: Replace any Category 5 patch cables with high-performance Category 5e cables. -
Page 49: Port Pin Assignments
Console Port Pin Assignments Console Port Pin Assignments The DB-9 serial port on the switch’s front panel is used to connect to the switch for out-of-band console configuration. The on-board menu-driven configuration program can be accessed from a terminal or a PC running a terminal emulation program. The pin assignments used to connect to the serial port are provided in the following tables. - Page 50 Cables...
-
Page 51: Appendix C: Specifications
Appendix C: Specifications VDSL Switch Model VDSL Switch-VS2512A Physical Characteristics VDSL Specificationss Supports evolving ETSI, ANSI and ITU standards Modulation: 4 to 256 QAM Frequency Division Duplexing Data Rate: Up to 15 Mbps symmetric Range: Up to 1525 m (5000 ft) Ports 1 RJ-21 Port (contains 12 VDSL lines) 1 Stacking Port Pair... -
Page 52: Switch Features
Specifications Humidity Operating: 5% to 90% AC Input 100 to 240 V, 50 to 60 Hz Power Consumption 40 Watts maximum Heat Dissipation 137 BTU/hr maximum Maximum Current 0.5 A @ 110 VAC 0.25 A @ 240 VAC Switch Features Spanning Tree Protocol Forwarding Mode Store-and-forward... -
Page 53: Management Features
VDSL Switch Management Features In-Band Management Telnet, Web-based HTTP, or SNMP manager (AccView Network Management software provided free) Out-of-Band Management RS-232 DB-9 console port Software Loading TFTP in-band or XModem out-of-band MIB Support MIB-II (RFC1213), Interfaces Evolution MIB (RFC 2863), Ethernet-Like MIB (RFC 2665), Bridge MIB (RFC 1493), Extended Bridge MIB: P-bridge, Q-bridge (RFC2674), RMON MIB (RFC 2819), Entity MIB (RFC 2737), RADIUS authentication client MIB (RFC 2618), Accton’s private MIB... -
Page 54: Warranty
Specifications Immunity EN 61000-4-2/3/4/5/6/8/11 Safety CSA/NRTL (CSA 22.2.950 & UL 1950) EN 60950 (TÜV/GS) CB (UEC60950) Warranty Limited Lifetime VDSL Splitter Models VM2524 VM2548 Ports VM2524: 1 RJ-21 Port (contains 24 VDSL lines) VM2548: 2 RJ-21 Ports (each port contains 24 VDSL lines) Network Interface RJ-21 flat cable Weight... -
Page 55: Slide-In Modules
Slide-in Modules Immunity EN 61000-4-2/3/4/5/6/8/11 Safety CSA/NRTL (CSA 22.2.950 & UL 1950) EN60950 (TÜV/GS) CB (UEC60950) Warranty Limited Lifetime Slide-in Modules 1000BASE-SX Extender Module Model VM2512A-SX-SC-M Ports 1 1000BASE-SX SC-type port Network Interface SC connector, 50/125 or 62.5/125 micron multimode fiber cable Operating Mode Fixed at 1000 Mbps, full duplex Auto-negotiation of flow control... -
Page 56: 1000Base-T Extender Module
Specifications 1000BASE-T Extender Module Model VM2512A-1GT Ports 1 1000BASE-T RJ-45 port Network Interface RJ-45 connector, 100-ohm Category 5 or 5e twisted-pair cable (using all four wire pairs) Operating Mode 1 Gbps, full duplex, autonegotiation of speed and flow control 10/100 Mbps, full and half duplex, autonegotiation of speed, duplex mode, and flow control Standards IEEE 802.3ab... -
Page 57: 10/100Base-Tx Extender Modules
Slide-in Modules 10/100BASE-TX Extender Modules Models VS2512A-4TX VS2512A-1TX Ports VS2512A-4TX 4 10/100BASE-T RJ-45 ports VS2512A-1TX 1 10/100BASE-T RJ-45 port Network Interface RJ-45 connector, 100-ohm , UTP cable 10BASE-T - Categories 3, 4, or 5 100BASE-TX - Category 5 Operating Mode 10/100 Mbps, full and half duplex Auto-negotiation of speed and flow control Standards... - Page 58 Specifications...
- Page 59 Slide-in Modules...
- Page 60 Specifications C-10...
-
Page 61: Appendix D: Ordering Information
Appendix D: Ordering Information VDSL Switch-VS2512A Products and Accessories Product Number Description VS2512A 12-port VDSL switch with one media expansion slot VS2524 24-port VDSL switch with one media expansion slot and one SFP slot VM2524 24-port VDSL Splitter VM2548 48-port VDSL Splitter ES2002-TS VDSL CPE VS2524-1SX-SC-M... - Page 62 Ordering Information...
-
Page 63: Glossary
Glossary 10BASE-T IEEE 802.3 specification for 10 Mbps Ethernet over two pairs of Category 3, 4, or 5 UTP cable. 100BASE-FX IEEE 802.3u specification for 100 Mbps Fast Ethernet over two strands of 50/125 or 62.5/125 micron core fiber cable. 100BASE-TX IEEE 802.3u specification for 100 Mbps Fast Ethernet over two pairs of Category 5 UTP cable. - Page 64 Glossary Collision Domain Single CSMA/CD LAN segment. Customer Premises Equipment (CPE) Terminating equipment, such as terminals, phones, routers and routers, supplied by the phone company, installed at customer sites, and connected to the phone company network. CSMA/CD CSMA/CD (Carrier Sense Multiple Access/Collision Detect) is the communication method employed by Ethernet, Fast Ethernet, or Gigabit Ethernet.
- Page 65 Glossary IEEE 802.3ab Defines CSMA/CD access method and physical layer specifications for 1000BASE-T Fast Ethernet. IEEE 802.3u Defines CSMA/CD access method and physical layer specifications for 100BASE-TX Fast Ethernet. IEEE 802.3x Defines Ethernet frame start/stop requests and timers used for flow control on full-duplex links.
- Page 66 Glossary Private Branch Exchange (PBX) A telephone exchange local to a particular organisation who use, rather than provide, telephone services. POTS Plain Old Telephone Service. Redundant Power Unit (RPU) A backup power supply that automatically takes over in case the primary power supply should fail.
-
Page 67: Index
Index full-duplex connectivity 2-1 Numerics 1000BASE-LX connections 4-3 1000BASE-SX connections 4-3 GVRP 1-3 1000BASE-X connections 4-3 100BASE-FX connections 4-3 100BASE-LH connections 4-3 indicators, LED 1-7 100BASE-LX connections 4-3 installation desktop or shelf mounting 3-4 installing a GBIC transceiver 3-6 accessories, ordering D-1 installing optional modules 3-3 adhesive feet, attaching 3-4 port connections 4-1... - Page 68 Index IGMP Snooping 1-3 Internet connections 2-2 multimode and single-mode fiber optic remote connections 2-2 cables 4-3 SC port connections 4-3 multimode fiber optic cables 4-3 screws for rack mounting 3-2 SC-ST Converter 4-3, 4-4 serial port 1-3 network site selelction 3-1 connections 4-1, 4-3 SNMP agent 1-3 null-modem cable 1-3...
- Page 69 Index Web-based management 1-3 Weighted Round Robin Queuing 1-4 Index-3...
- Page 70 Index Index-4...
- Page 72 VS2412A VM2524, VM2548 E072002-R01 150000010100A...
