  • Page 1 Installation Manual SuperSmart EtherHub-16se...
  • Page 2 Installation Manual SuperSmart EtherHub-16se Advanced 16-Port 10BASE-T Smart Ethernet Hub...
  • Page 3 Phone: 408-452-8900 FAX: 408-452-8988 BBS: 408-452-8828 FAST FAX: 408-452-8811 Accton, EtherHub and SwitcHub are trademarks or registered trademarks of Accton Technology Corporation. Other trademarks or brand names mentioned herein are trademarks or registered trademarks of their respective companies. E0895-R01 150483-101...
  • Page 4: Fcc Warning

    FCC Warning This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 5 Sicherheitshinweise 1. Die Steckdose muß sich in der Nähe des Gerätes befinden und leicht zugänglich sein. 2. Zum Reinigen den Stecker aus der Steckdose ziehen. Beim Reinigen keine Flüssigreiniger oder Sprays verwenden, sondern ein angefeuchtetes Tuch. 3. Das ..gerät nicht in Naßräume oder in der Nähe von Wasser benutzen, wie z.B.
  • Page 6: About This Guide

    Use them again to repack the unit in case there is a need to return it for repair. To qualify for product updates and product warranty registration, fill in the and return it Owner Registration Card to Accton Technology Corporation. About this Guide...
  • Page 7: Table Of Contents

    Contents Chapter 1: Introduction Overview Features of the SuperSmart Hub Chapter 2: Hardware Description Front Panel Display SmartWatch LED Panel PWR/CPU Isolated Utilization Collision Segment LED Indicators Port Status Indicators Partition Link/Traffic Diagnostic Test LED Indicators Configure Button Station Ports Daisy-Chain Switch Rear Panel Displays Port Connections...
  • Page 8 SuperSmart User’s Guide Chapter 4: Setup and Configuration System Setup Diagnostic Tests Upon Power On During Normal Operation Multi-Segment Architecture Hot Remove Function Using the Configure Button Selections Available Appendix A: Product Specifications Features Physical Characteristics Standards Compliance Appendix B: Product Support Services Product Registration Problem Report Hardware Repair Service...
  • Page 9 List of Figures Figure 2.1 SmartWatch LED Panel Figure 2.2 Daisy-Chain Switch Setting Figure 2.3 The SuperSmart Rear Panel Figure 3.1 Stacking Hubs without a Rack Figure 3.2 Mounting Hubs Using a Mounting Rack...
  • Page 10: Chapter 1: Introduction

    Chapter 1: Introduction Overview The SuperSmart (EtherHub-16se) hub is a powerful and innovative LAN network enhancement product. This hub supports a multi-segment bus architecture that enhances traffic flow and network bandwidth utilization. It offers the network manager a wide range of flexible configuration options, allowing you to effectively increase your network’s bandwidth.
  • Page 11: Features Of The Supersmart Hub

    SuperSmart User’s Guide Features of the SuperSmart Hub One optional port (BNC, AUI or fiber-optic) for connecting to any Ethernet media via slide-in alternative module transceiver Supports daisy chaining by using a daisy-chain switch to convert port 16 to a daisy-chain port Automatic polarity detection and correction permits automatic recovery due to wiring errors Automatically partitions any bad port to protect the network...
  • Page 12: Chapter 2: Hardware Description

    Chapter 2: Hardware Description This chapter describes the hardware features of the SuperSmart hub. Before connecting any network device to the hub, please read this chapter carefully. For easier management and control of the hub, familiarize yourself with the front panel indicators and Configure button.
  • Page 13: Pwr/Cpu

    SuperSmart User’s Guide PWR/CPU Color: Green Label: PWR/CPU Function: Power indicator LED Activity Condition Indication STEADY LIGHT Unit is receiving power; CPU is running. BLINKING LIGHT Unit is receiving power; CPU is running. NO LIGHT Power is disconnected; no power received. Isolated Color: Green...
  • Page 14: Collision

    SuperSmart User’s Guide For example, if network utilization reaches 1%, the LED labeled 1% will light. However, if network utilization rises above 1% (e.g., 30%), the LED labeled 30 and all the other LEDs before it (i.e., 1, 5, and 15) will light in rapid succession. These LEDs monitor the share of valid network frames transmitted by this hub within a 10Mbps bandwidth.
  • Page 15: Segment Led Indicators

    SuperSmart User’s Guide When more than 31 consecutive collisions occur on the cable segment connected to a port, that port is automatically partitioned by the hub. The hub automatically reconnects this port when a data packet longer than 512 bits (normal) is transmitted or received by the partitioned port without collision.
  • Page 16: Partition

    SuperSmart User’s Guide Partition LED Activity Condition Indication STEADY RED LIGHT PARTITION Indicates port partitioning due to an abnormal network condition. NO LIGHT Port is in good condition. The Partition LEDs are also used as diagnostic LEDs. Please refer to the section on Diagnostic Test LED Indicators later in this chapter for more information.
  • Page 17: Diagnostic Test Led Indicators

    SuperSmart User’s Guide TROUBLESHOOTING If the Link/Traffic LED does not light up when a device is connected to its corresponding port, check that both the hub and connected device are powered on. For devices connected to the hub using a twisted-pair cable, check that the cable length does not exceed 100 meters.
  • Page 18: Configure Button

    SuperSmart User’s Guide The system tests each component one at a time. The unit will complete the test cycle even if a problem is detected on any of the components. If no lights are ON, this means that all the hub components passed the diagnostics.
  • Page 19: Station Ports

    SuperSmart User’s Guide Station Ports The unit has sixteen RJ-45 station ports. Using twisted-pair cable, connect your workstation (via the network interface card’s port) to any available RJ-45 port. Port 16 can be converted into a daisy-chain port by enabling the Daisy-Chain switch (see the following Daisy-Chain Switch section for related information).
  • Page 20: Rear Panel Displays

    SuperSmart User’s Guide Rear Panel Displays This section describes significant features of the unit’s rear panel. POWER POWER Alternative Port SWITCH SOCKET Connectors ALT PORT FlexBus 1500 This device complies with Part 15 of the FCC Operation is subject to the following two (1) This device may not cause harmful 100-250 VAC (2) This device must accept any interference...
  • Page 21: Alt Port

    SuperSmart User’s Guide ALT Port The slot labeled ALT PORT is for an optional slide-in transceiver module. Three types of transceiver modules are available - AUI (10BASE2) for thick Ethernet cable BNC (10BASE5) for thin Ethernet cable (default) fiber optic (10BASE-F) BNC Module (10BASE2) The BNC module has a built-in transceiver with a BNC port for connection using thin coaxial cable.
  • Page 22: Chapter 3: Hardware Installation

    Chapter 3: Hardware Installation This chapter describes how to install the hardware unit. Before You Begin 1. Before installing the hub, verify that the electrical values meet the following specifications. AC Power Frequency 100 to 240V (+/- 10%) 50 to 60Hz (+/- 3Hz) The hub is equipped with a power supply that automatically detects the input voltage level.
  • Page 23: Hardware Installation

    SuperSmart User’s Guide Hardware Installation 1. Find a location for the hub. The unit is suitable for desktop or rack-mount installation. A good location is at the center of all the devices you want to link, close to the trunk segment, and near a power outlet. The SuperSmart hubs can be stacked with other hubs using a mounting rack or directly on top of one another through the FlexBus 1500 ports.
  • Page 24: Stacking Hubs Without A Rack

    SuperSmart User’s Guide Stacking Hubs without a Rack 1. Stick a self-adhesive rubber foot (comes with this package) on the 4 hollow spaces at the bottom of the first hub. 2. Place the first hub in the area where you want the stack to be installed.
  • Page 25: Mounting Hubs On A Rack

    SuperSmart User’s Guide Mounting Hubs on a Rack 1. Confirm that the rack you will use is an EIA standard-size 19-inch rack. 2. Use the screws provided with the mounting rack to mount the hub using the hub’s mounting brackets. SuperSmart Hub Stack (Up to 10 Hubs) Figure 3.2...
  • Page 26: Connecting The Hub System

    SuperSmart User’s Guide Connecting the Hub System 1. Plug one end of the FlexBus 1500 cable (provided) in the BUS OUT port of the top hub and the other end to the BUS IN port of the next hub. Repeat this step for each hub in the stack.
  • Page 27 SuperSmart User’s Guide 3. Connect the hub to an Ethernet trunk, if necessary. (Applies only to hubs with a slide-in module transceiver installed in the ALT PORT.) Plug the BNC T-type connector into the BNC port of the hub, and use this port to connect the device to the RG-58A/U thin Ethernet trunk.
  • Page 28 SuperSmart User’s Guide The unit will automatically select the setting that matches the input voltage connected. Therefore, no additional adjustments are necessary when connecting it to any input voltage within the range marked on the rear panel. The unit supports a "hot remove" feature which permits you to connect/disconnect cables without powering off the hub and without disrupting the operation of the hubs in stack.
  • Page 29: Chapter 4: Setup And Configuration

    Chapter 4: Setup and Configuration System Setup Diagnostic Tests Upon Power On Upon power on, the system performs an internal self-diagnostic test of major hub components. If any component fails during the test, the hub will try to complete the diagnostic procedure. Otherwise, the system will hang.
  • Page 30: Multi-Segment Architecture

    SuperSmart User’s Guide Multi-Segment Architecture The SuperSmart hub supports multi-segment configuration through the FlexBus 1500 cabling. Three Ethernet segments are embedded in the hub’s FlexBus 1500 port providing 3 isolated segments (i.e., separate collision domains). You can choose to attach a hub to a segment, or to leave it isolated. Nodes attached to a specific segment (e.g., Segment 1) can only communicate with nodes attached to the same segment.
  • Page 31: Using The Configure Button

    SuperSmart User’s Guide Using the Configure Button There are 5 configuration functions accessed in sequence using the Configure button, including: Segment Setting Demo Function Diagnostic Function Reset Function. A "long press" on the button allows you to switch from one function to the next.
  • Page 32 SuperSmart User’s Guide To summarize, 1. Access configuration functions by using a "long press". LEDs light up to indicate the current configuration function. (Example: One of the Segment LEDs will BLINK to indicate that the system is in Segment Setting mode.) 2.
  • Page 33: Selections Available

    SuperSmart User’s Guide Selections Available This section shows the selections available for each function and the corresponding LED display. The functions are listed here in sequence. Segment Setting Active LEDs: Segment LEDs Attach the hub to one segment. Segment LED 1 Segment LED 2 Segment LED 3 Segment Number Selection...
  • Page 34 SuperSmart User’s Guide Reset function Active LEDs: Partition LED 3 Link/Traffic LED 3 (labeled Reset) Activating the Reset function will revert all selections (made using the Configure button) to factory default settings. Activity Selection Link/Traffic LED 3 BLINKING Enable Reset function Partition LED 3 BLINKING Stop Reset function...
  • Page 35: Appendix A: Product Specifications

    Appendix A: Product Specifications Features Up to 10 modules (170 station ports) Expansion FlexBus 1500 cable Expansion Interface Segmentation Supports 3 or more segments in a stack Hot swappable modules Fault Tolerance Physical Characteristics Station Ports 16 10BASE-T (RJ-45) Optional Backbone Port 100V - 260V AC ( 10%), 50- 60 Hz ( 3 Hz) System Power...
  • Page 36: Standards Compliance

    SuperSmart User’s Guide Standards Compliance Standards Ethernet-IEEE 802.3 Repeater Standard and Repeater Management Standard UL 1950 Safety CSA 22.2-950 Canada TÜV/GS/EN60950 Germany IEC 950 International Electromagnetic Emissions FCC Class A Electrostatic IEC 801.2, EN55101-2 IEC 801.3, EN55101-3 EFT/Noise IEC 801.4, EN55101-4 Vibration IEC 68-2-34 Environmental...
  • Page 37: Appendix B: Product Support Services

    Appendix B: Product Support Services Product Registration Fill in the Owner Registration Card and mail it to Accton Technology Corporation. Accton will keep your record and inform you of any new Accton unit developments. Problem Report If problems occur during unit operation, please check the adapter configuration settings, cables, connectors, network terminators, hardware compatibility and other network components.
  • Page 38: Software Update And Upgrade Service

    SuperSmart User’s Guide After repair, Accton will inform you of the date of delivery and the exact amount due. Please send the payment by T/T (Telegram Transfer), and Accton will send you the fixed component after receiving payment. With or without warranty, if the hardware is found to be free of defects, you will only be charged for testing and handling.
  • Page 39: Interactive Fast Fax (U.s.a. Office

    To obtain software upgrades connect via ftp to ftp.accton.com.tw Send your technical questions by email to support@accton.com.tw Mail your technical questions to: International Headquarters USA Headquarters Accton Technology Corporation Accton Technology Corporation Attn: Technical Support Attn: Technical Support No. 1 Creation Road III...
  • Page 40: Limited Warranty

    SuperSmart User’s Guide Limited Warranty Accton warrants to the original owner that the product delivered in this package will be free from defects in material and workmanship for the lifetime of the product. For the warranty to apply, you must register your purchase by returning the registration card indicating the date of purchase and including proof of purchase.
  • Page 41: Return Process

    For warranty information: All territories except North and South America: Accton Technology Corporation, International Headquarters No. 1, Creation Rd. III, Science-based Industrial Park, Hsinchu 300, Taiwan, R.O.C. Phone: 886-35-770-270 Fax: 886-35-770-267...
  • Page 42: Ordering Information

    SuperSmart User’s Guide Ordering Information Advanced 16-port smart Ethernet hub SuperSmart EtherHub-16se (EH2051) Alternative Module for Backbone Port AUI transceiver interface module EH1552 Fiber-optic transceiver ST connector interface EH1553 module Secure multi-segment backbone hub EtherHub-SBH (EH2001) 8-port smart Ethernet switching hub SwitcHub-8s (EH2002) Product Support Services...
  • Page 43: Glossary

    Glossary Alt Port An optional port found on the backplane of the SuperSmart hub. A BNC, AUI or fiber-optic module can be installed in the ALT port. AUI (attachment unit interface) A 15-pin interface specified by the IEEE 802.3 standard for connecting a PC, server, or other device to an Ethernet transceiver or Media Access Unit (MAU).
  • Page 44 SuperSmart User’s Guide Multi-Segment Architecture Type of architecture that enhances traffic management and network bandwidth utilization by segregating network traffic. RJ-45 Connector Most common terminator for twisted-pair wiring. 10BASE-T IEEE’s specifications for running Ethernet using twisted-pair. Terminator A resistor placed at each end of an Ethernet cable to make sure that signals do not reflect back and cause errors.
  • Page 45: Index

    Index ALT Port • 2-10 EtherHub-16se • 1-1 Alternative Interface Module • 1-1 FCC Warning • i BNC Module • 2-10 FlexBus 500 • 2-9 BUS IN • 2-9 Front Panel • 2-1 BUS OUT • 2-9 Hardware Description • 2-1 Canadian Standards Association •...
  • Page 46 SuperSmart User’s Guide Package Contents • v Utilization • 2-2 Partition LEDs • 2-5 Port Connections ALT Port • 2-10 BNC Module • 2-10 FlexBus 500 • 2-9 Port Status LEDs • 2-4 Product Specifications • A-1 Product Support Services • B-1 Bulletin Board Service •...
  • Page 47 EH2051 E0895-R01 150483-101...
