Product Update: HP Netserver LXr 8500 Installation Guide: Gasket Installation (cont.)
Figure 3-11. Place the New Gaskets Flush Against the PCI Access Panel Hinges
12. To replace the PCI access panel, lower it onto the top cover, about ½ inch to the rear of its normally closed
position. See Figure 3-6 in the HP Netserver LXr 8500 Installation Guide.
13. Push the PCI access panel forward until the tabs along its front edge line up with the screw holes on the top
cover.
14. Re-attach the two T-15 Torx
15. Replace the top cover and reboot the HP Netserver.
HP Part Number 5971-3021
Printed in April 2001
®
screws to the top cover. Be sure you use the short T-15 Torx
®
screws.
'"&$ ( '
