FC-SCSI Interface SpecificationDescribes the IceCube SCSI interface. Targetted as part of OEM manual.Disk Array Con
Event Event
Number Name
(dec/hex)
0/0x0 No Sense
1/0x01 Undefined
2/0x02 Unsupported LUN Capacity
3/0x03 Parameter List Length Error
4/0x04 Invalid Field In Parameter List
5/0x05
No Physical Device Present
6/0x06 Invalid Opcode
7/0x07
Invalid Bit In CDB
8/0x08
Logical Block Address Out Of
Range
9/0x09 Not Ready
10/0x0a
Undefined
11/0x0b Power On Unit Attention
12/0x0c Hardware Error Unit Attention
13/0xd Commands Cleared Unit
Attention
14/0x0e
Mode Parameters Changed
Unit Attention
15/0x0f Unconfigured LUN
16/0x10 Invalid Target LUN
17/0x11 Invalid Source LUN
18/0x12 Not Enough Space
19/0x13
Command Illegal In Current
State
20/0x14
Becoming Ready
21/0x15
Recovered With Low Level
Retries
22/0x16 Recovered By Disk Drive
23/0x17
Disk Drive Media Error
Table 1. Controller Log Event Code Descriptions
Predictive Suspected
Maintenance Components
Implication
N N.A. None
N N.A. None
N N.A. None
N N.A. None
N N.A. None
N N.A. None
N N.A. None
N N.A. None
N N.A. None
N N.A. None
N N.A. None
N N.A. None
N N.A. None
N N.A. None
N N.A. None
N N.A. None
N N.A. None
N N.A. None
Y Ignore None
N N.A. None
N N.A. None
Y Ignore Disk,
controller, disk
interface
Y See information Disk Drive
provided by
drive vendor
Y See information Disk Drive
Error! No text of specified style in document.
Description
N No sense data is available.
N Undefined event code.
N An attempt was made to create a LUN with an
unsupported capacity. The capacity was either zero
or was greater than the maximum LUN capacity
supported by the subsystem.
Y The length of the parameter list was incorrect for the
command and it's parameters.
Y One or more of the fields in the parameter list
contained an invalid value.
Y A command attempted to access a device (disk or
enclosure controller) that is not currently present in
the subsystem.
Y The opcode in the command that was received is not
supported by the subsystem. This error could be
due to the LUN Security configuration.
Y One or more fields in the CDB contained an illegal
or unsupported value.
Y The LBA specified in the command was out of
range for the LUN that it was sent to.
N The array is not ready to process the command that
was received. Furthermore, the array will not
become ready until an initializing command is
received and successfully processed.
N Undefined event code.
N The array just completed a reset operation.
Y The most recent reset operation detected a hardware
error during a selftest operation.
N Another originator sent commands to the array that
resulted in commands being cleared for the current
originator.
N Another initiator sent commands to the array that
resulted in shared mode parameters being changed
for the current initiator.
N The LUN to which the command was sent is
currently not configured for use.
N The subsystem does not support the LUN that was
specified in the most recent command. The LUN is
the target of the requested action.
N The subsystem does not support the LUN that was
specified in the most recent command. The LUN is
the source of the requested action.
Y A write command had to move data in order to find
enough space to complete. Errors were encountered
during this process which precluded the controller
from providing enough space for the write. This
would generally result from multiple failing or
missing drives. This failure can also result from
faulty space management logic in the controller.
N The current subsystem state precludes processing of
the requested command.
N The subsystem is not ready to process the command
that was received. However, it is in the process of
becoming ready and will be able to process that
command soon.
N On a previous attempt(s), the drive failed the I/O.
The PDD retried the I/O and the drive returned good
status. PDD stands for Physical Device Driver.
Specifically this error indicates that the RAID
implementation was not involved in the retries.
N The disk drive returned a status of
CHECK_CONDITION, RECOVERED_ERROR.
N The disk drive returned a status of
