6.2 Disassembly Sequence Chart

Use the chart below to determine the section number to be
referenced when removing computer components.
Section Description
5.3 Preparing the Computer for
Disassembly
5.4 Hard Drive
5.5 Computer Feet
5.6 Bluetooth Board
5.7 MultiBay II Device
5.8 External Memory Module
5.9 Keyboard
5.10 Switch Cover
5.11 LED Board
5.12 TPM Security Module
5.13 Fan
5.14 Heat Sink
Maintenance and Service Guide
Disassembly Sequence Chart
Battery pack
Removal and Replacement Procedures
# of Screws Removed
0
2 loosened to remove the
hard drive cover
1 loosened to remove the
hard drive
6 to disassemble hard drive
0
0
1
1 loosened to remove the
memory module
compartment cover
3
3
5
1
2 loosened
4 loosened
