Introduction
This document defines the supported HP NetServer LP1000r configurations using the HP Rack Storage/12FC
and Microsoft Cluster Server. These configurations minimize single points of failure (SPOF, SPOFless
provide extended availability. The specific configuration certified and supported by both Hewlett-Packard and
Microsoft is defined, as are other guidelines to assist you in configuring your clustered NetServers. This guide
is prescriptive; it describes the configurations supported by HP. Any deviance to these configurations can result
in an inoperative cluster or an operating cluster with degraded performance, hidden SPOFs, etc., and therefore
will not be supported by HP.
What's Defined in a Racked Cluster
Cluster
Type of SPUs
Number of nodes
Shared Storage
LANs:
Client LAN
Intra-cluster
(Heartbeat) LAN
Power source
1
For more information about configuring a SPOFless cluster, refer to the HP white paper, High Availability
MSCS Cluster Solution on the HP NetServers, HA Planning website.
HP NetServer LP1000r
with
HP Rack Storage/12FC
Cluster Configuration Guide
21 March 2001
(see
Versions
at the end of this document)
Cluster
SPUs
Local and Shared Storage
Intra-cluster and Client LANs
Shared Storage Cabling
HP NetServer LP1000r
Each node must be the same model SPU, but may have different clock
speeds, main memory sizes, cache sizes, and number of CPUs .
2
HP Rack Storage/12FC with 2 FCArray Cards, HP disks, and using an
HP D8602A HBA in each server. See
Any NIC that is HP and Microsoft approved. See
Embedded NIC with crossover cable, or, configure as a VLAN through an
Ethernet switch. See
Intra-cluster LAN
Direct from power mains, power conditioner or uninterruptible power
supply (UPS) using any power conditioner or UPS.
Shared Storage
below.
1
1
) and
below.
Client LAN
below.

Advertising

   Related Manuals for HP D7171A - NetServer - LPr

   Summary of Contents for HP D7171A - NetServer - LPr

  • Page 1

    Microsoft Cluster Server. These configurations minimize single points of failure (SPOF, SPOFless ) and provide extended availability. The specific configuration certified and supported by both Hewlett-Packard and Microsoft is defined, as are other guidelines to assist you in configuring your clustered NetServers. This guide is prescriptive;...

  • Page 2

    System software: Navigator version L.20.00 or later Operating System Microsoft Windows NT 4.0 Service Pack SP6a or later Model HP NetServer LP1000r Clock speed 1 GHz No. of CPUs BIOS version 4.06.12 or later CPU cache Any size 256 MB minimum. Must be HP. Local storage Local Storage below.

  • Page 3

    FC Array Assistant A.002-5 Status SCSI ID 5 (fixed) Disk SCSI IDs 0 – 3, 8 – 15 (fixed) Disk drives: Any HP drive supported by storage enclosure Fibre-channel cables Optical (Server to Hub only): 50 meter D6980A 100 meter D6981A Copper (Shared Storage to Hub and Server to Hub ): 3 meter D6978A 5 meter D6979A...

  • Page 4

    Fibre-channel HBA with GBIC Fibre-channel Hub with GBICs NOTES The bottom two shared storage devices are SCSI HP Rack Storage/12s and are optional to the cluster configuration. LEGEND Heavy (blue) lines are fibre channel Optical or Copper cables. See cabling in this guide for specifications.

  • Page 5

    Power Cabling to Separate Power Circuits (For SPOFless with 2 hubs, connect second hub to PDU that first hub is not attached to)

  • Page 6

    Fibre-channel HBA with GBIC Fibre-channel Hub with GBICs Each copper cable goes to Port ‘ x’ on the RS/12FC array controllers. NOTES The bottom two shared storage devices are SCSI HP Rack Storage/12s and are optional to the cluster configuration. Each copper cable goes LEGEND to Port ‘...

  • Page 7

    Fibre-channel HBA with GBIC For a direct connection, copper cable goes to Port ‘ x’ on first RS/12FC array controller. NOTES The bottom two shared storage devices are SCSI HP Rack Storage/12s and are optional to the cluster configuration. Copper cable goes to Port ‘...

  • Page 8

    Versions 21 March 2001 Initial release...
