NVIDIA Quadro FX5800 Graphics Card
installation
Introduction
This document describes how to install an NVIDIA Quadro FX5800 Graphics Card with an auxiliary
power adapter cable in an HP Workstation.
NVIDIA Quadro FX5800 Graphics Card
Auxiliary power adapter cable
Card support bracket for HP xw8600 and xw9400 Workstations
Fan for HP xw8600 Workstation
Warranty information
To determine the compatibility of this product with your HP workstation, see QuickSpecs online at
http://www.hp.com/go/productbulletin.
Before installing an NVIDIA FX5800 Quadro graphics card, ensure the following criteria are met:
HP
800 Workstations must contain an 1110 Watt power supply.
HP xw8600 and xw9400 Workstations must contain a 1050 Watt power supply for dual cards. (1050
Watt power supply is recommended for single card.)
System memory cannot exceed 32 GB with dual FX5800 cards (HP xw8600 Workstations).
System cannot contain Dual FSB1600/ Quad core processors with dual FX5800 cards (HP xw8600
Workstations).
ENWW
© 2008–2009 Hewlett-Packard Development Company, L.P.
Printed in the U.S.
Introduction
1

Advertising

   Related Manuals for HP Xw9400 - Workstation - 16 GB RAM

   Summary of Contents for HP Xw9400 - Workstation - 16 GB RAM

  • Page 1: Kit Contents, Before You Begin

    System memory cannot exceed 32 GB with dual FX5800 cards (HP xw8600 Workstations). ● System cannot contain Dual FSB1600/ Quad core processors with dual FX5800 cards (HP xw8600 Workstations). © 2008–2009 Hewlett-Packard Development Company, L.P. Printed in the U.S. ENWW Introduction...

  • Page 2: Warnings And Cautions

    Warnings and cautions WARNING! Any surface or area of the equipment marked with this symbol indicates the presence of an electrical shock hazard. To reduce the risk of injury from electrical shock, do not open any enclosed area marked with this symbol. WARNING! To reduce the risk of electric shock or damage to your equipment: —...

  • Page 3: Removing Components

    Step 1—Preparing for component installation NOTE: Workstation models vary. All illustrations are examples only. Accessing the internal components of the workstation If you need help preparing the workstation for this installation, consult the removal and replacement procedures in the service guide for your workstation at http://www.hp.com/support/ workstation_manuals.

  • Page 4

    Step 2—Installing the front PCI fan in the HP xw8600 Workstation CAUTION: To prevent overheating an HP xw8600 Workstation, a front PCI fan is required when installing the NVIDIA Quadro FX5800 graphics card. If the HP xw8600 Workstation includes dual high- performance graphics cards and lacks a front PCI fan, the BIOS detects an illegal cooling configuration error and reports that the front PCI fan is missing.

  • Page 5

    Attach the front fan to the card guide. Place the fan in the card guide with the fan label facing into the card guide and the fan protector screen facing outward. Place the fan wire through the slot in the card guide. Snap the fan into place in the card guide.

  • Page 6

    Step 3—Installing the graphics card NOTE: The FX5800 graphics card occupies two expansion slots on the system board. HP recommends placing the keyed components of the card in the primary graphics slot. To identify a PCI Express (PCIe)-x16 expansion slot, see the service label on the workstation access panel. Position the graphics card.

  • Page 7

    Step 4—Connecting the power Close the expansion slot retention clamp to secure the card in the slot Connect the 6-to-8 pin auxiliary power adapter cable, supplied with this kit, to the workstation auxiliary power supply , and then to the FX5800 card NOTE: No connection is made at point .

  • Page 8

    Step 6—Reassembling the workstation Reinstall the workstation card support, if applicable. Reinstall the side access panel. Reconnect power to the workstation and all external devices. Restore power to the workstation and all external devices. Step 7—Configuring the software For instructions on loading and setting up the graphics drivers, see the manufacturer’s documentation shipped with the NVIDIA Quadro graphics card.
