Adding Dhcp Option 60 And 201 To An Isc Dhcp Server - HP T5135 - Compaq Thin Client User Manual

Either:
a. From the main Windows menu select Start > Run.
b. Enter Cmd in the Open: field. A Command shell appears.
c. Enter netsh then press the
d. Enter dhcp then press the
e. Enter server \\servername (using the UNC name for the server).
Or:
a. Enter server <ip_address> (using the IP address of the server.). A "dhcp server >"
prompt appears in the command window.
b. Enter add optiondef 60 (name of your choice) STRING 0 then press the
key.
c. Enter set optionvalue 60 STRING "PXEClient" then press the
d. To confirm that the settings are correct, enter show optionvalue all then press the
Enter
3. Add option 201, and set the value to "'Management_Gateway_IP_Address' '40003'"
a. Type in add optiondef 201 (name of your choice) STRING 0 then press the
Enter
b. Type in set optionvalue 201 STRING 'Management_Gateway_IP_Address'
'40003' then press the
address of the server running the Management Gateway service.)
c. To confirm that the settings are correct, type in show optionvalue all then press the
Enter
NOTE:
'40003' must be written exactly as shown above, including the single quotes and separated by
a single space, otherwise errors will occur.
The DHCP server should then be ready to be used with PXE.

Adding DHCP Option 60 and 201 to an ISC DHCP Server

If ISC DHCP server 2.0 is in use, it must be updated to ISC DHCP server 3.0 as version 2.0 does not
support vendor specific information. For more information, see http://www.isc.org.
28 Chapter 2 Installing HP Device Manager
key.
key.
Enter
key.
When setting optionvalue 201, 'Management_Gateway_ IP_Address'
Enter key.
Enter key.
key. (The Management_Gateway_IP_Address is the
Enter
Enter key.
