Page 1: Operation Guide
FS-C5400DN OPERATION GUIDE Please read this Operation Guide before using this machine. Keep it close to the machine for easy reference.
Page 3: Table Of Contents
Contents Legal and Safety Information Machine Parts Components at the Front of the Printer ........1-2 Components at the Left of the Printer ........1-2 Internal Components ..............1-3 Components at the Rear of the Printer ........1-3 Operation Panel ................1-4 Printing Operation Changing Network Interface Parameters .........
Page 4 Appendix Interface ..................A-2 USB Interface ................A-2 Network Interface ................A-3 About the Options ..............A-5 Expansion Memory Modules .............A-6 General Description of Options ..........A-9 Specifications ................A-12 Glossary Index...
Page 5: Legal And Safety Information
All rights are reserved. Copying or other reproduction of all or part of this guide, any copyrightable subject matter without the prior written consent of Kyocera Mita Corporation is prohibited. Any copies made of all or part of this guide, any copyrightable subject must contain the same copyright notice as the material from which the copying is done.
Page 6 License Agreements Typeface Trademark Acknowledgement All resident fonts in this printer are licensed from Monotype Imaging Inc. Helvetica, Palatino and Times are registered trademarks of Linotype-Hell AG. ITC Avant Garde Gothic, ITC Bookman, ITC ZapfChancery and ITC Zapf Dingbats are registered trademarks of International Typeface Corporation.
Page 7 Your exclusive remedy and the sole liability of Monotype Imaging in connection with the Software and Typefaces is repair or replacement of defective parts, upon their return to Monotype Imaging. 10 IN NO EVENT WILL MONOTYPE IMAGING BE LIABLE FOR LOST PROFITS, LOST DATA, OR ANY OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR ANY DAMAGES CAUSED BY ABUSE OR MISAPPLICATION OF THE SOFTWARE AND...
Page 8: Original Ssleay License
Redistributions of any form whatsoever must retain the following acknowledgment: "This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (http:// www.openssl.org/)" THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT "AS IS" AND ANY EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED.
Page 9 If you include any Windows specific code (or a derivative thereof) from the apps directory (application code) you must include an acknowledgement: "This product includes software written by Tim Hudson (tjh@cryptsoft.com)" THIS SOFTWARE IS PROVIDED BY ERIC YOUNG "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED.
Page 10: Interface Connectors
Compliance and Conformity This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 11: Safety Information
Radio Frequency Transmitter This machine contains a transmitter module. We, the manufacturer (Kyocera Mita Corporation) hereby declare that this equipment (page printer), model FS-C5400DN is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Radio Tag Technology...
Page 12: Cautionary Labels
Cautionary Labels The printer bears any of the following labels. High temperature inside. Do not touch parts in this area, because there is a danger of getting burned. Label inside the printer (Laser radiation warning) For Europe, Asia, and other countries For U.S.A.
Page 13: Cdrh Regulations
CDRH Regulations The Center for Devices and Radiological Health (CDRH) of the U.S. Food and Drug Administration implemented regulations for laser products on August 2, 1976. These regulations apply to laser products manufactured after August 1, 1976. Compliance is mandatory for products marketed in the United States.
Page 14 7779. Disclaimer Kyocera Mita will not be liable to customers or any other person or entity for any loss or damage caused or alleged to be caused directly or indirectly by equipment sold or furnished by us, including but not limited...
Page 15: Energy Saving Control Function
Energy Saving Control Function To reduce energy consumption while in a waiting state, the device comes equipped with an energy saving control function for switching to a Sleep Mode where power consumption is automatically reduced to a minimum after a certain amount of time elapses since the device was last used. Sleep The device automatically enters Sleep when 45 minutes have passed since the device was last used.
Page 16: Installation Precautions
Installation Precautions Environment CAUTION Avoid placing the printer on or in locations which are unstable or not level. Such locations may cause the printer to fall. This type of situation presents a danger of personal injury or damage to the printer. Avoid locations with humidity or dust and dirt.
Page 17: Other Precautions
Power Supply/Grounding the Printer WARNING Do not use a power supply with a voltage other than that specified. Avoid multiple connections in the same outlet. These types of situations present a danger of fire or electrical shock. Plug the power cord securely into the outlet. If metallic objects come in contact with the prongs on the plug, it may cause a fire or electric shock.
Page 18: Precautions For Use
Precautions for Use Cautions when Using the Printer • Do not place metallic objects or containers with water (flower vases, flower pots, cups, etc.) on or near the printer. This type of situation presents a danger of fire or electrical shock should they fall inside. •...
Page 19 Other Precautions • Do not place heavy objects on the printer or cause other damage to the printer. • Do not open the top/left/rear cover, turn off the main switch, or pull out the power plug during printing. • During printing, some ozone is released, but the amount does not cause any ill effect to one's health.
Page 20 About the Operation Guide This Operation Guide has the following chapters: Chapter 1 - Machine Parts This chapter explains the names of parts. Chapter 2 - Printing Operation This chapter explains how to print from your workstation. Chapter 3 - Handling Paper This chapter explains how to replace the toner container and how to care for your printer.
Page 21: Machine Parts
1 Machine Parts This chapter provides explanations and illustrations for you to determine the parts and their functions. Try to be familiar with the names and functions of these parts for correct use and optimal performance. This chapter contains explanations on the following topics: Components at the Front of the Printer Components at the Left of the Printer Internal Components...
Page 22: Components At The Front Of The Printer
Components at the Front of the Printer Operation Panel Front Cover Paper Stopper Top Cover (Top Tray) MP (Multi-Purpose) Tray Paper Cassette Power Switch Components at the Left of the Printer 10 11 12 13 Left Cover Waste Toner Box 10 Magenta Toner Container (M) 11 Cyan Toner Container (C) 12 Yellow Toner Container (Y)
Page 23: Internal Components
Internal Components 14 Paper Transfer Unit 15 Paper Ramp 16 Duplex Unit Components at the Rear of the Printer 20 21 17 USB Memory Slot 18 Power Cord Connector 19 Option Interface Slot 20 Network Indicators 21 Network Interface Connector 22 USB Interface Connector 23 Rear Cover Machine Parts...
Page 24: Operation Panel
Operation Panel 25 26 24 Message Display 25 Ready Indicator 26 Data Indicator 27 Attention Indicator 28 Arrow Keys 29 [MENU] Key 30 [Left Select] Key 31 [Right Select] Key 32 [Back] Key 33 [OK] Key 34 [Cancel] Key Machine Parts...
Page 25: Printing Operation
2 Printing Operation This chapter contains explanations on the following topics: Changing Network Interface Parameters Printing a Status Page Installing the Printer Driver Printing from Application Software Status Monitor 2-10 Uninstalling Software (Windows PC) 2-13 Printing Operation...
Page 26: Changing Network Interface Parameters
Changing Network Interface Parameters This printer supports TCP/IP, TCP/IP (IPv6), NetWare, AppleTalk, IPP, SSL Server and the IPSec protocols and Security Level. The table below shows the items required for each of the settings. Configure the printer's network parameters as appropriate for your PC and your network environment.
Page 27: Printing A Status Page
Printing a Status Page After completing the network settings, print a status page. The status page allows you to confirm a range of information, including network addresses and network protocols. To print a status page, select Status Page from the Report Print menu. Refer to Report Print on page 4-11 for detailed information.
Page 28: Installing The Printer Driver
Installing the Printer Driver Ensure the printer is plugged in and connected to the PC before installing the printer driver from the CD-ROM. Installing the Software in Windows If you are connecting this printer to a Windows PC, follow the next steps to install the printer driver.
Page 29 Express Mode In Express Mode, the installer automatically detects the printer when it is turned on. Use Express Mode for standard connection methods. In the installation method selection window, select Express Mode. The print system detection window appears and the installer detects the connected printers.
Page 30 Insert the included CD-ROM (Product Library) into the CD-ROM drive. Double-click the CD-ROM icon. Double-click either OS X 10.2 and 10.3 Only or OS X 10.4 or higher depending on your Mac OS version. Double-click Kyocera OS X vx.x. Printing Operation...
Page 31 The printer driver installation program starts up. Choose Select Destination, Installation Type and then install the printer driver as directed by the instructions in the installation software. Note In addition to Easy Install, the Installation Type options include Custom Install, which allows you to specify the components to be installed.
Page 32 Click the IP icon for an IP connection or the AppleTalk icon for an AppleTalk connection and then enter the IP address and printer name. Select the installed printer driver and click Add. Select the options available for the printer and click Continue. Printing Operation...
Page 33: Printing From Application Software
The selected printer is added. This completes the printer setup procedure. Printing from Application Software The steps required to print a document created with an application are explained below. You can select the printing Paper Size and Output Destination. Load the paper required into the paper cassette. From the application File menu, select Print.
Page 34: Status Monitor
Status Monitor The Status Monitor monitors the printer status and provides an ongoing reporting function. It also allows you to specify and modify settings for printers not included in the KX driver. The Status Monitor is installed automatically during KX driver installation. Accessing the Status Monitor Use either of the methods listed below to launch the Status Monitor.
Page 35 If the printer is connected to a TCP/IP network and has its own IP address, use a web browser to access the COMMAND CENTER to modify or confirm the network settings. For more information, refer to the KYOCERA COMMAND CENTER Operation Guide. Preferences... Specify the Sound Notification and Appearance settings for the Status Monitor.
Page 36: Status Monitor Settings
Status Monitor Settings Use the Preference option to set up the Status Monitor. The Status Monitor has two tabs to configure its settings. Sound Notification Tab The Sound Notification tab contains the following items. IMPORTANT To confirm the settings on Sound Notification tab, the computer requirs the sound capabilities such as sound card and speaker.
Page 37: Uninstalling Software (Windows Pc)
Appearance Tab The Appearance tab is contains the following items. Enlarge window Doubles the size of the Status Monitor window. Always on top Positions the Status Monitor in front of other active windows. Transparency Displays the Status Monitor as a transparent window. Uninstalling Software (Windows PC) The software can be uninstalled (removed) using the CD-ROM (Product Library) supplied with the printer.
Page 38 2-14 Printing Operation...
Page 39: Handling Paper
3 Handling Paper This chapter contains explanations on the following topics: General Guidelines Selecting the Right Paper Special Paper Paper Type 3-13 Loading Paper 3-14 Handling Paper...
Page 40: General Guidelines
General Guidelines The machine is designed to print on standard copier paper (the type used in ordinary dry copier machines), but it can also accept a variety of other types of paper within the limits specified below. Note The manufacturer assumes no liability for problems that occur when paper not satisfying these requirements is used.
Page 41: Recommended Paper
Item Specification Squareness of corners 90° ±0.2° Moisture content 4 % to 6 % Direction of grain Long grain Pulp content 80 % or more Minimum and Maximum Paper Sizes The minimum and maximum paper sizes are as follows. For non standard paper such as transparency, labels, vellum, cardstock, envelope, coated and thick, the MP (Multi-Purpose) tray must be used.
Page 42: Selecting The Right Paper
Selecting the Right Paper This section describes the guidelines for selecting paper. Condition Avoid using paper that is bent at the edges, curled, dirty, torn, embossed, or contaminated with lint, clay, or paper shreds. Use of paper in these conditions can lead to illegible printing and paper jams, and can shorten the life of the machine.
Page 43: Basis Weight
Smoothness The paper should have a smooth, uncoated surface. Paper with a rough or sandy surface can cause voids in the printed output. Paper that is too smooth can cause multiple feeding and fogging problems. (Fogging is a gray background effect.) Basis Weight Basis weight is the weight of paper expressed in grams per square meter (g/m²).
Page 44: Moisture Content
Moisture Content Moisture content is defined as the percent ratio of moisture to the dry mass of the paper. Moisture can affect the paper’s appearance, feed ability, curl, electrostatic properties, and toner fusing characteristics. The moisture content of the paper varies with the relative humidity in the room.
Page 45: Special Paper
Packaging: Paper should be packed in a sturdy carton to protect it from damage during transport. Quality paper obtained from a reputable supplier is usually correctly packaged. Note You might see the printer emitting steam in the area around the top tray if you use damp paper, but it is safe to continue printing.
Page 46 Transparency Transparencies must be able to withstand the heat of fusing during the printing process. The recommended transparency product is 3M CG3700 (Letter, A4). The table below lists the specifications for transparency: Item Specification Tolerance of heat Must tolerate at least 190 °C (374 °F) Thickness 0.100 to 0.110 mm (3.9 to 4.3 mils) Material...
Page 47 Labels Labels must be fed from the MP tray or optional paper feeder PF-510. The basic rule for printing on adhesive labels is that the adhesive must never come into contact with any part of the machine. Adhesive paper sticking to the drum or rollers will damage the machine. Label paper has a structure comprising of three layers, as shown in the diagram.
Page 48 Postcards Fan the stack of postcards and align the edges before loading them in the MP tray. Make sure the postcards you are going to set are not curled. Feeding curled postcards may cause paper jams. Some postcards have rough Rough edges on the back (those are Edge...
Page 49: Thick Paper
Thick Paper Fan the stack of paper and align the edges before loading them in the MP tray. Some types of paper have rough edges on the back (those are created when the paper is cut). In this case, put the paper on a flat place and rub the edges once or twice with, for example, a ruler to smooth them.
Page 50 IMPORTANT When printing on coated paper in very humid environments, ensure that the paper is kept dry as moisture may cause sheets to stick together when they are fed into the printer. Paper Type Indicators (Optional paper feeder PF-510) If you are going to load non standard paper in the optional paper feeder PF-510, cut out the blank section of the...
Page 51: Paper Type
Paper Type The printer is capable of printing under the optimum setting for the type of paper being used. Setting the paper type for the paper source from the printer’s operation panel will cause the printer to automatically select the paper source and print in the mode best suited to that type of paper.
Page 52: Loading Paper
Loading Paper The following explains the procedure for loading paper in the cassette and the MP tray. Loading Paper into the Cassette Fan the media (paper/transparencies), then tap it on a level surface to avoid media jams or skewed printing. Pull the paper cassette all the way out of the printer.
Page 53 Pull the release lever of both side guides and slide to the desired Paper Guides paper size. Release Lever Pull the release lever and slide the paper stopper to the desired paper Release Lever size. Paper Stopper When using non-standard size paper, move the paper guides and paper stopper all the way out, insert the paper, then adjust the paper guides and paper stopper to the size of the paper.
Page 54 Insert the paper cassette into the slot in the printer. Push it straight in as far as it will go. There is a paper gauge on the right side of the front of the paper cassette to indicate the remaining paper supply. When paper is exhausted, the pointer will go down to the level of (empty).
Page 55 Adjust the position of the paper guides on the MP tray. Standard paper sizes are marked on the MP tray. For standard paper sizes, slide the guides to the position marked correspondingly. Align the paper with the paper guides and insert as far as it will go. Note Do not load more paper than will fit under the load limits on the inside of the MP tray.
Page 56: Paper Stopper
Paper stopper Align the paper stopper to the desired paper size. • For A4 or Letter size paper Move the paper stopper as far as the location of ① . • For Legal size paper Face the paper stopper upward, pull up as shown at ① and move it as far as the location of ②...
Page 57: Using The Operation Panel
Using the Operation Panel This chapter contains explanations on the following topics: General Information Understanding the Operation Panel Keys Using the Menu Selection System Setting a Mode Selection Menu 4-10 Report Print 4-11 USB Memory (USB memory selection) 4-17 Custom Box 4-21 Job Box 4-26...
Page 58: General Information
General Information This chapter provides the information you need to configure the Ecosys Color printer. In general you need to use the operation panel only to make default settings. You can make most changes to the printer settings using the printer driver through the application software. Note Changes to printer settings made using a software application override changes made using the operation panel.
Page 59: Understanding The Operation Panel
Understanding the Operation Panel The operation panel on the top of the printer has a 5-line by 21-character liquid crystal display (LCD), ten keys, and three indicators (LED). Messages that appear on the display and functions of indicators and keys are explained in this chapter.
Page 60: Status Information
Status Information Message Meaning The printer is warming up and is not ready. Please wait. When the printer is switched on for the first time, this message will take several minutes. This message appears when the printer is preparing to print coated paper (Coated) fed Please wait.
Page 61: Indicators In Message Display
Indicators in Message Display Ready to print. UW A4 VX A6 [ Toner Ready, Data, and Attention Indicators The following indicators light during normal operation and whenever the printer needs attention. Depending on the status of lighting, each indicator has the following meaning: Indicator Description Flashing.
Page 62: Keys
Keys The operation panel keys are used to configure the printer operation. Note that certain keys have a secondary function. Cancel Key This key is used to: • Cancel a printing job. • Stop the alarm sound. Canceling a Printing Job While the printer displays Processing., press [Cancel].
Page 63: Back Key
OK Key This key is used to: • Finalize settings of numeric values and other selections. Back Key • Cancels the menu setting currently displayed and returns to the menu for the previous step. Left Select Key / Right Select Key •...
Page 64: Using The Menu Selection System
Using the Menu Selection System Menu Selection System This section explains how to use the menu selection system. [MENU] on the operation panel allows you to use the menu to configure the printer settings to your specific needs. Settings can be made when Ready to print., Sleeping., Please wait.
Page 65: Custom Box
For more information, please refer to Custom Box on page 4-21 , Job Box on page 4-26 or RAM Disk Setting (Using the RAM disk) on page 4- Note Only when USB memory is installed, USB Memory is displayed. Selecting a Menu The mode selection menu is hierarchical.
Page 66: Setting A Mode Selection Menu
Setting a Mode Selection Menu This section explains the setting procedures used for each menu item in the mode selection menu. While the printer displays Ready to print., Please wait., Menu: Sleeping. and Processing., press [MENU]. The Mode Selection Report Print Menu is displayed.
Page 67: Report Print
Report Print Prints a report. The options available in the Report Print menu are as follows: • Menu Map (Printing a menu map) • Status Page (Printing a printer's status page) • Font List (Printing a list of the printer's fonts) •...
Page 68: Menu Map
Menu Map Sample Menu Map Printer FS-C5400DN Firmware version 4-12 Using the Operation Panel...
Page 69: Status Page
The numbers in the following diagram refer the items explained below the diagram. The items and values on the status page may vary depending on the printer’s firmware version. Status Page Printer FS-C5400DN Firmware version Paper Settings Interface Block Group Settings...
Page 70 Firmware Version This item shows the version and release date of the printer firmware. Printer Settings Information This item shows various printer settings for hardware-related items: MP tray paper size and type Paper cassette size and type Sleep time Formfeed timeout time Installed Options This item shows the options installed in the printer: Hard disk...
Page 71: Font List
Press [Yes] ([Left Select]). The message Accepted. appears and Print. the printer prints the font list. Are you sure? Pressing [No] ([Right Select]) returns you to the Report Print menu z Font List without printing the font list. RAM File List (Printing a list of the files on the RAM disk) This allows you to print a list of the files on the RAM disk.
Page 72 MemCard FileList (Printing a list of the files on a memory card) This allows you to print a list of the files on a memory card. IMPORTANT This message will be displayed only when the memory card is installed in the printer and properly formatted. In the Report Print menu, press to select MemCard FileList.
Page 73: Usb Memory (Usb Memory Selection)
USB Memory (USB memory selection) This specifies the settings for removing the USB memory and printing USB memory content. The USB Memory menu automatically appears when you install the USB memory. IMPORTANT This message is displayed only when the USB host block is set to Unblock.
Page 74 Print File (Prints the selected file) You can use this to specify printing for files in the USB memory. Use the procedure described in Print File (Printing and checking the files in the USB memory) on page 4-17 to display a list of the files in the folder containing the file you want to print.
Page 75 Press [Yes] ([Left Select]). The message Accepted. appears and Accepted. printing begins. Press [No] ([Right Select]) to return to the file list selection screen. Detail (Shows the details of the selected file) Use this to view detailed information on the files and folders in the USB memory.
Page 76 Press [OK]. The printer is now ready for the USB memory to be removed and the Mode Selection menu screen appears. IMPORTANT If the screen on the left appears, the USB memory is Cannot remove the still being used. Wait until the relevant job (e.g. printing from the USB memory while in use.
Page 77: Custom Box
Custom Box IMPORTANT To use a Custom Box, an optional hard disk must be installed in the printer. The hard disk must be formatted from the printer. For more information, refer to Format Hard Disk on page 4-77. A Custom Box is a general-purpose box that allows users to store print data on the printer's hard disk so that it can be reused as required.
Page 78 When the password has been entered, press [Enter] ([Right Select]). Note After the password is input, collation is done. Incorrect Password is displayed for the incorrect password, and it returns to the input screen. Try to input be a correct password. Box number/Box name (Select a File) To print/delete a file in the Custom Box, first select the file to be printed or deleted.
Page 79 Press to select Print. Press [OK]. The Copies menu screen appears. Copies: If you want to change the number of remaining copies to be printed, (1 - 999) use the arrow keys to set the number of copies to be printed. /**1-copies Press to increase or decrease, respectively, the value at the...
Page 80 Press to select Delete. Press [OK]. A confirmation screen appears. Delete. Are you sure? z j AAAA Press [Yes] ([Left Select]). The message Completed. appears Completed. and the selected file(s) are deleted. Pressing [No] ([Right Select]) returns you to the Print/Delete menu screen without deleting the file.
Page 81 Press [OK]. Details for the file that is selected with the cursor Detail: appears. File Name: 1/ 6 The details for the file covers 6 pages in all. Press to view to the ABCDEFGHIJKLMNOPQRSTN next page or to return to the previous page. [ Detail ] In the File Name screen, if the file name is abbreviated because it Detail:...
Page 82: Job Box
Job Box IMPORTANT To use the Job Box, an optional hard disk must be installed in the printer. The RAM disk may also be used in the Proof-and-Hold and Private Print modes. Job Box is a print function that makes the Job Retention function possible. The settings are specified from the printer driver.
Page 83 Quick Copy is only displayed if there are any jobs that were saved to the hard disk in Quick Copy mode. Private/Stored is only displayed if there are any jobs that were saved to the hard disk or RAM disk. Quick Copy (Using Quick Copy) This mode enables you to print the requested number of copies of a job, simultaneously storing the job on the hard disk/RAM disk.
Page 84 Select/Deselect All Files All files in the Job Box are selected. In the file list screen, press to select All Files. l User01: All Files Q Data01 Q Data02 [ Menu ] [ Select ] Press [Select] ([Right Select]). l User01: When there is a file not checked in the Job Box, all files will be All Files checkmarked.
Page 85 Press [Yes] ([Left Select]). The message Accepted. appears and Accepted. the printer prints the selected job. Pressing [No] ([Right Select]) returns you to return to the previous screen. Deleting a Quick Copy Job Jobs saved using Quick Copy are automatically deleted when you turn the printer off, but you can also use this procedure to delete jobs individually.
Page 86 Press to select Delete. A confirmation message is appears. Delete. Are you sure? z Q Data01 Press [Yes] ([Left Select]). The message Completed. appears Completed. and the printer deletes the selected job. Pressing [No] ([Right Select]) returns you to return to the previous screen.
Page 87 Select the checkmarked file and press [Select] ([Right Select]) again to cancel the selection. Note To select all files, follow the steps of Select/Deselect All Files on page 4-28 Print a File Print the file(s) selected in the Job Box. In the file list screen, select the item and press [OK].
Page 88 Press to select the user name you entered in the printer driver. Press [OK]. The printer displays a list of the jobs stored under the l User01: selected user name. All Files Q Data01 Q Data02 [ Select ] Press to select the name of the job to be deleted.
Page 89 Private/Stored (Printing a Private Print/Stored Job) In private printing, you can specify that a job is not printed until you release the job from the operation panel. When sending the job from the application software, specify a 4-digit access code in the printer driver. The job is released for printing by entering the access code on the operation panel ensuring confidentiality of the print job.
Page 90 Press to select Print. If the selected job was saved as a Private Print job, its ID is displayed. If the job was saved in stored job (0000-9999) mode, the number of direct copies is displayed. 0123456789 [Bckspace] [ Enter Enter the access code entered in the printer driver.
Page 91 Press [OK]. The Private/Stored screen appears listing the user Private/Stored: names for stored jobs. User01 User02 User03 Press to select the user name you entered in the printer driver. Press [OK]. The printer displays a list of the jobs stored under the l User01: selected user name.
Page 92 Press [Enter] ([Right Select]). If the entered access code is Delete. correct, the Delete menu screen appears. If the entered access code Are you sure? is incorrect, the ID menu screen reappears. z Q Data01 Note When the access code is set to the document selected in the check box, ID error is displayed for the disagreement.
Page 93 In the Job Box menu, press to select Job Box Settings. Press [OK]. The Job Box Settings screen appears. Job Box Settings: a b Quick Copy Jobs JobRet.Deletion [ Exit Select JobRet.Deletion and press [OK]. The JobRet. Deletion menu screen appears. Press to select the desired Automatic Delete time.
Page 94: Job Log
Job Log You can use the Job Log to check the history of jobs that have already finished printing. As well as jobs printed from PCs, this log shows the outcomes for jobs printed directly from USB memory and reports such as status pages. The information available in the Job Log is listed below.
Page 95 Press [Detail] ([Right Select]). The Job Log details screen 0006 Detail: appears. Job Name: The detailed job log covers 6 pages in all. Press to view to the next ABCDEFGHIJKLMNOPQRSTN page or to return to the previous page. [ Detail ] Pressing [OK] while file or folder details are displayed returns you to the Job Log menu.
Page 96: Counter (Viewing The Counter Value)
Counter (Viewing the counter value) Displays the number of pages printed. The options available in Counter are as follows: • Total (Displaying the total printed pages) • Color (Displaying the color printed pages) • Black & White (Displaying the monochrome printed pages) Press [MENU].
Page 97 Black & White (Displaying the monochrome printed pages) This allows you to check the total number of monochrome pages printed and the number of monochrome pages printed in each of the 9 paper sizes. You cannot change the displayed number. In the Counter menu screen, press to select Black &...
Page 98: Paper Settings
Paper Settings This sets the paper size and type for the MP tray and cassettes from which paper is supplied. The options available in Paper Settings are as follows: • MP Tray Set. (MP tray settings) • Cassette (1 to 5) Set. (Settings for the cassettes) •...
Page 99 Press [OK]. The Paper Size screen appears listing the paper sizes Paper Size: that can be supplied from the MP tray. 1 *Envelope Monarch Envelope #10 The available paper sizes are as follows: Envelope DL Envelope Monarch Envelope #10 Envelope DL Envelope C5 Executive Letter...
Page 100: Media Type
Press [OK]. The MP Tray Set. menu screen appears. MP Tray Set.: Paper Size Media Type [ Exit Press to select Media Type. Press [OK]. The Media Type screen appears listing the media types Media Type: that can be supplied from the MP tray. 1 *Plain Transparency The available paper sizes are as follows:...
Page 101 Pull the cassette out of the printer and set the paper size using the paper size dial. Paper Size Dial Adjust the paper guides in the cassette to the size of the paper to be used for printing and load the paper into the cassette. Custom Paper Size If you use a non-standard size paper, load the paper and turn the paper size dial to Other (refer to Loading Paper on page 3-14).
Page 102 Press [OK]. The Other Paper screen appears listing the paper sizes Other Paper Size: a b that can be used in the cassette. 1 *Envelope C5 Executive The available paper sizes are as follows: Letter Envelope Monarch (#2) [ Exit Envelope #10 (#2) Envelope DL (#2) Envelope C5...
Page 103 Setting a Custom Paper Size In the procedure below, select the units to be used for entering the custom paper size and then enter the paper width and length. As shown in the figure, enter the Y and X values for the paper size, using the selected units.
Page 104 Use the arrow keys to enter the paper length. Press to increase or decrease, respectively, the value at the blinking cursor. to move the cursor right and left. The range of paper lengths you can set for each cassette is as follows: •...
Page 105 Press [OK]. The Cassette # Set. menu screen appears. Cassette 1 Set.: a b # shows the number of the cassette installed in the printer (1 to 5). Media Type Other Paper Size Custom PaperSize [ Exit Press to select Media Type. Press [OK].
Page 106 Setting the Paper Thickness You set the paper thickness by selecting a paper weight. The available paper weights are as follows (grammages are provided as a guide) Extra Heavy (OHP) Heavy 3 (170 to 220 g/m Heavy 2 (135 to 170 g/m Heavy 1 (120 to 135 g/m Normal 3 (90 to 120 g/m Normal 2 (75 to 90 g/m...
Page 107 In the Paper Settings menu, press to select Media Type Set.. Press [OK]. The Media Type Set. screen appears listing the Media Type Set.: a b media types that can used with the printer. Plain Transparency Preprinted [ Exit Press to select the media type for which you want to set the paper weight.
Page 108 Press [OK]. A menu for the selected media is displayed. CUSTOM 1: Paper Weight Duplex [ Exit Press to select Paper Weight. Press [OK]. The Paper Weight screen appears listing the paper Paper Weight: weights that can used with the printer. Extra Heavy 2 *Heavy 3 Heavy 2...
Page 109 Press [OK]. The duplex printing permission is set and the Media Type Set. screen reappears. Reset Type Adj. (Resets customized settings) This resets all the settings specified in Media Type Set. (Paper type settings) on page 4-49. In the Paper Settings menu, press to select Reset Type Adj..
Page 110: Print Settings
Print Settings These settings specify the following printing parameters: paper feed source, paper feed mode, duplex printing, override A4/LTR, emulation mode, color mode, print quality, and setting pagination. The options available in Print Settings are as follows: • Paper Selection (Selecting the paper feed source) •...
Page 111 Paper Feed Mode (Setting the paper feed source) This mode specifies how the paper should be fed once the paper feed source and paper type have been chosen. If Auto is selected, the printer searches for a paper feed source that matches the paper size and type, and paper is then delivered from that source.
Page 112 Duplex (Setting the duplex printing) Using the duplexer, you can automatically print on both sides of the paper. The duplexer is mounted underneath the printer. Duplex printing is only available for those media types that can be fed from one of the cassettes. Duplex printing is available for the following paper(media) types: PLAIN PREPRINTED...
Page 113 In the Print Settings menu, press to select Duplex. Press [OK]. The Duplex screen appears showing the list of Duplex: available duplex printing modes. 1 *Off Bind Long Edge Bind Short Edge Press to select the desired duplex printing mode. The message display toggles through the following: Off (default) Bind Long Edge...
Page 114 Press [OK]. The Emulation Set. menu screen appears. Emulation Set.: Emulation KPDL Error Rpt. [ Exit Press to select Emulation. Press [OK]. The Emulation screen appears showing a list of the Emulation: available emulations. 1 *PCL6 The available emulations are as follows: KPDL PCL6 KPDL(Auto)
Page 115: Gloss Mode
Color Mode (Selecting color or black & white printing) You can use the Color Mode menu on the operation panel to select the Color or Black & White printing mode. By default, the printer is set to print in color mode. In the Print Settings menu, press to select Color Mode.
Page 116 Press [OK]. The EcoPrint mode is set and the Print Quality menu screen reappears. Gloss Mode (Selecting the Gloss mode) Gloss mode, when set to High, increases the effect of glossiness in printing by reducing the printing speed by half. Gloss mode is not available when Labels and Transparency is selected as the paper type setting.
Page 117 Copies (Number of copies) You can set the number of copies of each page to be printed for the current interface. In the Page Setting menu, press to select Copies. Press [OK]. The Copies screen appears. Copies: (1 - 999) /255-copies Use the arrow keys to set the number of copies.
Page 118 Wide A4 (Wide A4 pitch) Turn this to On to increase the maximum number of characters that can be printed in a line for an A4 page (78 characters at 10 pitch) and Letter size page (80 characters at 10 pitch). This setting is only effective in PCL 6 emulation.
Page 119 TIFF/JPEG Size (Adjusting the TIFF/JPEG file print out size) Use this setting to select the printing method used when TIFF or JPEG files are printed directly. In the Page Setting menu, press to select TIFF/JPEG Size. Press [OK]. The TIFF/JPEG Size screen appears. TIFF/JPEG Size: The options available in TIFF/JPEG Size are as follows: 1 *Paper Size...
Page 120: Network (Network Settings)
Network (Network settings) This printer supports TCP/IP and TCP/IP (IPv6) protocols. IP is an abbreviation for Internet Protocol. This printer routinely uses the TCP/IP (IPv4) protocol, but provides a separate setting for the next- generation IP, IPv6. TCP/IP (IPv4) uses 32-bit IP addresses, but the rapid growth in the number of Internet users has resulted in a shortage of IP addresses.
Page 121 TCP/IP (Enable/Disable TCP/IP) The TCP/IP system refers to the Internet system, which has a 5-layer structure consisting of the interface layer, link layer, network (IP) layer, transport (TCP/UDP) layer and application layer. The interface layer is a key layer in the TCP/IP system that provides an abstracted interface that is not dependent on the link (communication line: frame relay or Ethernet, etc.) to the IP module (IP layer).
Page 122 DHCP (DHCP setting) DHCP (Dynamic Host Configuration Protocol) is the protocol that assigns the information required to establish a network connection when a host attempts to connect to the network (Internet). This information includes the IP address of the local node and the default router (the router in the host's own network system) and the DNS (Domain Name System) server.
Page 123 Subnet Mask (Subnet mask setting) The subnet mask is a way of augmenting the network address section of an IP address. A subnet mask represents all network address sections as 1 and all host address sections as 0. The number of bits in the prefix indicates the length of the network address.
Page 124 Press [OK]. The Default Gateway screen appears. Default Gateway: a b /123.145.167.123- Use the arrow keys to set the default gateway. Press to increase or decrease, respectively, the value at the blinking cursor. You can set any value between 000 and 255. to move the cursor right and left.
Page 125 IPv6 Setting (TCP/IP IPv6 settings) This selects the settings for TCP/IP (IPv6). TCP/IP (IPv6) is based on the current Internet protocol, TCP/IP (IPv4). IPv6 is the next-generation Internet protocol and expands the available address space, which resolves the problem of the lack of addresses under IPv4, while also introducing other improvements such as additional security functionality and the capacity to prioritize data transmission.
Page 126 RA(Stateless) (RA (Stateless) setting) The IPv6 router communicates (transmits) information such as the global address prefix using ICMPv6. This information is the Router Advertisement (RA). ICMPv6 stands for Internet Control Message Protocol, and is a IPv6 standard defined in the RFC 2463 "Internet Control Message Protocol (ICMPv6) for the Internet Protocol Version 6 (IPv6) Specification".
Page 127: Device Common (Selecting/Setting The Common Device)
Device Common (Selecting/Setting the common device) Selects/sets all the functions in this printer. The options available in Device Common are as follows: • Language (Selecting the message language) • Buzzer (Alarm (Buzzer) setting) • RAM Disk Setting (Using the RAM disk) •...
Page 128 The optional languages are as follows: Optional language Message display Turkish Türkçe Greek Ελληνικά Polish Polski Czech Hungarian Magyar Finnish Suomi Hebrew Arabic Swedish Svenska Danish Dansk Norwegian Norsk Romanian If you are using one of the optional languages, it is displayed in place of Português.
Page 129 Key Confirmation (Key confirmation tone setting) When On is selected in this setting, a tone sounds each time a key is used. The default setting is On. In the Buzzer menu screen, press to select Key Confirmation. Press [OK]. The Key Confirmation screen appears. Key Confirmation: a b 2 *On Press...
Page 130 Error (Error tone setting) When On is selected in this setting, a tone sounds when a problem such as running out of paper or a paper jam occurs during printing. The default setting is On. In the Buzzer menu screen, press to select Error.
Page 131: Ram Disk Size
RAM Disk Setting (Using the RAM disk) The RAM disk is a memory space shared within the printer memory that can temporarily store print jobs. The stored print job can then be used to print multiple copies of the job reducing the total amount of time required to print the whole job.
Page 132 RAM Disk Mode (Setting the RAM disk) Selecting On in this setting enables the RAM disk. In the RAM Disk Setting menu, press to select RAM Disk Mode. Press [OK]. The RAM Disk Mode screen appears. RAM Disk Mode: 1 *Off Press to select whether the RAM disk is enabled.
Page 133: Hard Disk
Format Hard Disk When an optional hard disk is inserted into the printer for the first time, it must be formatted before use. This menu is displayed only when the optional hard disk is installed on the printer. Note If the optional hard disk is installed in the printer, the Job Box will be available.
Page 134: Memory Card
Format Mem. Card (Formatting the memory card) The printer is equipped with a slot for a memory card. For details about the handling of the memory card, refer to Formatting the Memory Card on page A-9. A new memory card must be formatted before it can be used in the printer. Formatting allows data to be written to the memory card.
Page 135: Paper Mismatch
Error Handling (Error detection setting) This specifies the settings for the detection methods used for duplex printing errors and for paper size and paper type errors when the paper source is fixed. The options available in Error Handling are as follows: •...
Page 136 Paper Mismatch (Detection settings for paper size/type errors when the paper source is fixed) Select Continue in this setting if you want to continue printing even if the paper size or type you specified is different from the fixed paper source, or select Display Error to have the paper feed error displayed.
Page 137: Timer Setting
Timer Setting This specifies timer-related settings such as the automatic form-feed timeout and the timeout settings for Auto Sleep. The options available in Timer Setting are as follows: • Err. Clear Timer (Setting the error clear time) • Sleep Timer (Sleep timer timeout time) •...
Page 138 In the Timer Setting menu, press to select Sleep Timer. Press [OK]. The Sleep Timer screen appears. Sleep Timer: (1 - 240) /45-min. Use the arrow keys to set the sleep time. Press to increase or decrease, respectively, the value at the blinking cursor.
Page 139 Use the arrow keys to set the form feed timeout delay. Press to increase or decrease, respectively, the value at the blinking cursor. to move the cursor right and left. Press [OK]. The form feed timeout setting is stored and the Timer Setting menu reappears.
Page 140 Auto Sleep (Setting the sleep timer) The printer has a sleep timer that is used to conserve power when the printer is not printing, processing, or receiving data. The default setting is Refer to Sleep Timer (sleep timer setting) above to set the time until the printer switches to Auto Sleep mode.
Page 141: Security (Security Function Setting)
Security (Security function setting) The security functions can be set up to protect printer operation and the print data. IMPORTANT To specify the Security function settings, you must enter an administrator ID and password. For information on how to set the administrator ID and password, refer to Administrator (Administrator settings) on page 4-103.
Page 142: Frame Type
Network Security (Network security setting) Use this procedure to specify the security settings for each of the network protocols used. IMPORTANT Check with your network administrator when selecting network settings. The options available in Network Security are as follows: • Netware (NetWare setting) •...
Page 143 Off/On (NetWare operation setting) Select whether or not to use NetWare. The default setting is Off. In the NetWare menu, press to select Off/On. Press [OK]. The Off/On screen reappears. Off/On: 1 *Off Press to select whether NetWare is enabled. Press [OK].
Page 144 AppleTalk (AppleTalk setting) AppleTalk is a communications protocol used primarily on Macintosh computers and also refers to the Mac OS network functions. AppleTalk assigns 24-bit network addresses (a 16-bit network section and an 8-bit node address) that are used to identify devices (computers, printers, etc.) on the network.
Page 145 SSL Setting (SSL Server setting) SSL (Secure Sockets Layer) refers to a protocol used to encrypt information sent and received over a network. SSL can currently be used to encrypt data such as the WWW or FTP files widely used on the Internet so that privacy-related information, credit card numbers, corporate secrets and other confidential information can be sent and received safely.
Page 146 Press [OK]. The SSL server setting is set and the SSL menu reappears. Encryption (Encryption setting) Select the encryption method used on the SSL server. In the SSL menu, press to select Encryption. Press [OK]. The Encryption screen appears. Encryption: 3DES [ Complete] Press...
Page 147 IPP over SSL (SSL Server IPP over SSL setting) IPP over SSL is an encryption function that uses SSL for communications between users and servers in network printing. To use IPP over SSL, both server and client must support the protocol. The default setting is Off. In the SSL Setting menu, press to select IPP over SSL.
Page 148 Press [OK]. The IPSec screen appears. IPSec: 2 *On Press to select whether IPSec is enabled. Press [OK]. The IPSec setting is set and the Network Security menu reappears. I/F Block Set. (External interface block setting) You can use this to lock and thereby protect the interface. The options available in I/F Block Set.
Page 149 USB Device (USB interface setting) This locks and protects the USB interface. The default setting is Unblock. In the I/F Block Set. menu, press to select USB Device. Press [OK]. The USB Device screen appears. USB Device: 1 *Unblock Block Press to select whether a USB device is used.
Page 150: Job Account.set. (Job Account Setting)
Job Account.Set. (Job Account setting) Job Accounting is a function that allows the number of pages used by each department to be managed through the use of entered account IDs. To specify the Job Accounting settings, you must enter an administrator ID and password.
Page 151 Job Accounting (Job Accounting settings) This allows you to turn the Job Accounting function On and Off. In the Job Account.Set. selection menu, press to select Job Accounting. Press [OK]. The Job Accounting screen appears. Job Accounting: 1 *Off Press to select On or Off and then press [OK].
Page 152 Press [OK]. The Each Job Account menu appears with the Each Job Account: a b accounts with the highest numbers listed first. k 341736 k 00923022 k 12345678 Press to select an account and then press [OK]. The k 341736: Printed Pages/Counter Reset menu screen appears.
Page 153 Press [OK]. The reset confirmation menu screen appears. Reset counter. To proceed with resetting the counter, press [Yes] ([Left Select]). Are you sure? Completed. appears, the counter is reset and the Printed z k 341736 Pages/Counter Reset menu reappears. Pressing [No] ([Right Select]) returns you to the Printed Pages/ Counter Reset menu screen without resetting the counter.
Page 154 Press [Enter] ([Right Select]). Once the account has been added, k 1228: a list of selection options appears. Detail/Edit Delete Exit This message appears if the account ID has already been registered. This account ID is already registered. Detail/Edit (Checking/editing registered account ID settings) This procedure allows you to check or edit registered accounts.
Page 155 Enter the new account ID. Use to select a number and then press [OK] to enter the number. You can go back one character by pressing [Bckspace] ([Left Select]). This message appears if the account ID has already been registered. This account ID is already registered.
Page 156 To place color printing restrictions on this account, press Restrict.(Color): a b select Restrict.(Color) and then press [OK]. The 1 *Off Restrict.(Color)screen appears. Counter Limit • Off Reject Usage • Counter Limit • Reject Usage Press to select a setting and then press [OK]. When the Detail/Edit: setting has been completed, the Detail/Edit menu screen Account ID...
Page 157 Press to select Delete and then press [OK]. A confirmation Delete. screen appears. Are you sure? z k 1228 To proceed with deleting the account, press [Yes] ([Left Select]). Account. List: Completed. appears and the account is deleted. The Once deleting k 00122 of the account ends, the Account.
Page 158 Unknown ID Job (Operation settings for unknown account IDs) Use this procedure to specify whether print jobs from departments with unknown account IDs are permitted. In the Job Account.Set. selection menu, press to select Unknown ID Job. Press [OK]. The Unknown ID Job screen appears. Unknown ID Job: •...
Page 159: Administrator (Administrator Settings)
Administrator (Administrator settings) The Administrator setting is a function that identifies a user who can use the printer and manage other users. When using the Security and Job Accounting functions, the administrator ID and password set here are authenticated, and settings can be specified after they are properly authenticated.
Page 160 Press [OK]. The New ID screen appears. New ID: (1 - 16 digit) 0123456789 [Bckspace] [ Enter Enter the administrator ID to be registered. Use to select a number and then press [OK] to enter the number. You can go back one character by pressing [Bckspace] ([Left Select]).
Page 161 When you have finished, press [Enter] ([Right Select]). The Confirm Password: P b Confirm Password menu screen appears. (0 - 16 digit) 0123456789 [Bckspace] [ Enter To confirm, re-enter the administrator password to be registered. Use to select a number and then press [OK] to enter the number. You can go back one character by pressing [Bckspace] ([Left Select]).
Page 162: Adjust/Maint. (Adjust/Maintenance Selection/Setting)
Adjust/Maint. (Adjust/Maintenance selection/ setting) Adjust/Maintenance is used to adjust the print quality and to carry out printer maintenance. The options available in Adjust/Maintenance are as follows: • ColorCalibration • Color Regist. Normal (Color registration [Standard]) • Color Regist. Detail (Color registration [Detailed]) •...
Page 163 Color Regist. Normal (Color registration [Standard]) When using the printer for the first time after set-up or after having moved it, or if printout of any color (magenta, cyan or yellow) is skewed, use this mode to correct the color registration on the operation panel. The options available in Registration Normal (Color registration [standard]) are as follows: •...
Page 164 Sample Color Registration Correction Chart [Normal] Color Registration Correction Chart MH-L MH-R CH-L CH-R YH-L YH-R 4-108 Using the Operation Panel...
Page 165 Adjust Magenta (Magenta correction) Corrects the registration for magenta (red). In the Adjust/Maint. menu screen, press to select Color Regist.. Press [OK]. The Color Regist. menu screen appears. Color Regist.: Press [Exit] ([Right Select]) to return to the standby screen. Normal Detail [ Exit...
Page 166 Adjust Cyan (Cyan correction) and Adjust Yellow (Yellow correction) These options correct the registration for cyan (blue) and yellow. In the Color Regist. Normal menu screen, press to select Adjust Cyan or Adjust Yellow. Press [OK]. The Adjust Cyan or Adjust Yellow screen appears. Adjust Cyan: (I - A, 0 - 9) H-L:/0- V: 0...
Page 167 Press to select Detail. Press [OK]. The Color Regist. Detail menu screen appears. Detail: Press [Exit] ([Right Select]) to return to the standby screen. Print Chart Adjust Magenta Adjust Cyan [ Exit Press to select Print Chart. Press [OK]. A confirmation screen appears. Print.
Page 168 Sample Color Registration Correction Chart [Detail] 4-112 Using the Operation Panel...
Page 169 Adjust Magenta (Magenta correction) Makes detailed corrections to the registration for magenta (red). In the Adjust/Maint. menu screen, press to select Color Regist.. Press [OK]. The Color Regist. menu screen appears. Color Regist.: Press [Exit] ([Right Select]) to return to the standby screen. Normal Detail [ Exit...
Page 170 Adjust Cyan (Cyan correction) and Adjust Yellow (Yellow correction) These options make detailed corrections to the registration for cyan (blue) and yellow. In the Color Regist. Detail menu screen, press to select Adjust Cyan or Adjust Yellow. Press [OK]. The Adjust Cyan or Adjust Yellow screen appears. Adjust Cyan: (I - A, 0 - 9) H-1:/0-H-2: 0 H-3: 0...
Page 171: Test Page
Service Setting (for Maintenance) The options available in Service are as follows: • Service Status (Printing the service status page) • Network Status (Printing the network status page) • Test Page (Printing the test page) • Maintenance (New Maintenance Kit replacement confirmation setting) •...
Page 172: Network Status
Network Status (Printing the network status page) The network status page contains detailed information on the network settings. This is primarily used for maintenance by service personnel, but it contains information that may also be useful to you. In the Service Setting menu, press to select Network Status.
Page 173 Maintenance (New Maintenance Kit replacement confirmation setting) This specifies the setting for confirmation of replacement with the new Maintenance Kit (resets the total number of Maintenance Kit print images). This is primarily used for maintenance by service personnel. Note The Maintenance menu is displayed only when Install MK appears.
Page 174 Drum (Drum/Refresh mode setting) This sets the refresh mode for the drum. When the printing quality declines, refreshing the drum can restore the printing quality. This is primarily used for maintenance by service personnel. In the Service Setting menu, press to select Drum.
Page 175: Maintenance
5 Maintenance This chapter contains explanations on the following topics: General Information Toner Container Replacement Replacing the Waste Toner Box Cleaning the Printer Maintenance...
Page 176: Toner Container Replacement
General Information This chapter describes basic maintenance tasks you can perform on the printer. You can replace the following component according to the printer’s display: • Toner Kits • Waste Toner Box Also, the following parts need periodic cleaning: • Paper Transfer Unit Note Information Collection on Memory Chips - The memory chip attached to the toner container is designed to improve convenience for the end user;...
Page 177: Toner Kits
Toner Kits For best results, we recommend that you only use genuine Kyocera Mita Parts and Supplies. The toner kits are supplied in 4 different colors: cyan, magenta, yellow and black. A new toner kit for each color contains the following items: •...
Page 178: Replacing The Toner Container
IMPORTANT Kyocera Mita Corporation is not liable against any damages or problems arising from the use of toner containers other than those designated as original Kyocera Mita toner containers. For optimum performance, it is also recommended to use only the Kyocera Mita toner containers which are specifically intended for use in your country or region.
Page 179 Put the old toner container in the plastic bag (contained in the toner Plastic Bag kit) and discard it later according to the local code or regulations for waste disposal. Take the new toner container out of the toner kit. Shake the new toner container 5 or 6 times as shown in the figure in order to distribute the toner evenly inside the container.
Page 180: Replacing The Waste Toner Box
Replacing the Waste Toner Box Replace the waste toner box when the Check waste toner box. Message is displayed. A new waste toner box is included with the toner kit. The waste toner box needs to be replaced before the printer will operate.
Page 181: Cleaning The Printer
Open the cap of the new waste toner box. New Waste Toner Box Insert the new waste toner box as shown in the figure. When the box is set correctly, it will snap into place. New Waste Toner Box Make sure that the waste toner box is correctly inserted and close the left cover.
Page 182: Cleaning The Printer
Cleaning the Printer The paper transfer unit should be cleaned each time the toner container and waste toner box are replaced. To maintain optimum print quality, it is also recommended that the inside of the printer be cleaned once a month as well as when the toner container is replaced.
Page 183 Wipe away the paper dust on the registration roller, the paper ramp and paper guide using the cleaning cloth. Paper Transfer Unit Duplex Unit Dry Cloth Paper Ramp Transfer Belt (Black) Registration Roller (Metal) Transfer Roller (Black) Paper guide Note Be careful not to touch the black transfer roller and black transfer belt during cleaning as this may adversely affect print quality.
Page 184 5-10 Maintenance...
Page 185: Troubleshooting
6 Troubleshooting This chapter contains explanations on the following topics: General Guidelines Print Quality Problems Error Messages Clearing Paper Jams 6-15 If a problem cannot be corrected, contact your service technician. Troubleshooting...
Page 186: General Guidelines
General Guidelines The table below provides basic solutions for problems you may encounter with the printer. We suggest you consult this table to troubleshoot the problems before calling for service. Symptom Check Items Corrective Action Print quality is not good. Refer to Print Quality Problems on page 6-3.
Page 187: Print Quality Problems
Print Quality Problems The tables and diagrams in the following sections define print quality problems and the corrective action you can conduct to solve the problems. Some solutions may require cleaning or replacing parts of the printer. If the suggested corrective action will not solve the problem, call for service.
Page 188 Printed Results Corrective Action Black or white vertical streaks Refresh drum. Perform the following procedures on the operation panel and try cleaning the drum surface using the printer's built-in cleaning system. In the mode selection menu, press [ ] or [ ] to select Adjust/ Maint..
Page 189: Error Messages
Error Messages The following table lists errors and maintenance messages that you can be dealt with by yourself. If Machine failure. Call service. appears, turn off the printer, disconnect the power cord, and contact your service technician. or Error occurred. Turn Machine failure.
Page 190 Message Corrective Action Displayed when data is being canceled. Canceling... The corresponding paper cassette is not installed. Install the cassette. The cassette number can be 1 (topmost) to 5 (bottom). Cassette# not loaded. This message is displayed when a paper lift error has occurred in the paper source's cassette.
Page 191: Close Top Cover
Message Corrective Action The left cover of the printer is open. Close the left cover. Close left cover. The top cover of the printer is open. Close the printer top cover. Close top cover. This message is displayed when Remove Memory was selected while a USB memory was being used.
Page 192 Message Corrective Action This message is displayed when the Job Accounting function is enabled and an attempt has been made to exceed the print limit set for each account. To return Job Accounting the printer to the print-ready status, press [OK]. restriction exceeded.
Page 193 Message Corrective Action Current print processing cannot continue because of occurrence of KPDL error which is categorized by ##. To print out an error report, display KPDL Error KPDL error. Rpt. from the menu system, and select On. Press [OK] to resume printing. You Press [OK].
Page 194 Displayed when the installed toner is the original Kyocera Mita product. Original toner installed. A paper jam has occurred. The location of the paper jam is indicated in place of the #’s.
Page 195: Clean The Printer
When the printer detects that the top tray is empty Top tray is full of again, the printer will continues printing into the top tray. paper. Remove the paper. Displayed when the installed toner is not the original Kyocera product. Install original Kyocera toner. Unknown toner installed. Troubleshooting...
Page 196 Message Corrective Action This message is displayed if the installed toner container's regional specification does not match the printer's. Unknown toner Install the specified toner container. installed. PC [C][M][Y][K] An error has occurred in the USB memory device. To return the printer to the print-ready status, press [OK].
Page 197: Incorrect Password
Message Corrective Action The password does not match the password set. Enter the correct password. For more information, refer to Job Accounting (Job Accounting settings) on Incorrect password. page 4-95. Troubleshooting 6-13...
Page 198: Storage Error Codes
Storage Error Codes Hard Disk Errors Code Meaning Hard disk format error. If this error recurs even if the power has been turned off and then on, reformat the hard disk. The disk system is not installed. Recheck the requirements for using the system and the devices.
Page 199: Clearing Paper Jams
Clearing Paper Jams If the paper jammed in the paper transport system, or no paper sheets were fed at all, the Paper jam message appears and the location of the paper jam (the component where the paper jam has occurred) is also indicated.
Page 200: General Considerations For Clearing Jams
Reference Paper Jam Message Description Page Paper is jammed at the optional page 6-19 paper feeder’s cassette #. Paper jammed in cassette #. [ Help General Considerations for Clearing Jams Bear in mind the following considerations when attempting jam removal: CAUTION When pulling the paper, pull it gently so as not to tear it.
Page 201 Remove the jammed paper. Paper Jam in Printer Paper is jammed at the paper cassette or inside the printer. Remove the jammed paper using the procedure given below. CAUTION The fuser unit inside the printer is hot. Do not touch it with your hands as it may result in burn injury.
Page 202 If the paper has jammed inside the fuser unit, as shown in B, open the fuser cover and remove the paper by pulling its edge. Fuser Cover If the paper has jammed inside the duplex unit, as shown in C, lift the duplex unit and remove the paper by pulling it up from the edge.
Page 203 Paper Jam at Cassette 2 (to 5) Paper is jammed in the optional cassette. Remove the jammed paper using the procedure given below. Pull out the optional cassette and remove the jammed paper. Troubleshooting 6-19...
Page 204 6-20 Troubleshooting...
Page 205: Appendix
Appendix This chapter lists the provides details of the available interfaces and describes the optional hardware that can be installed on the printer and shows the printer's specifications. Interface USB Interface Network Interface About the Options Expansion Memory Modules General Description of Options Specifications A-12 For availability of the options, consult your service technician.
Page 206: Interface
Interface This chapter explains the signals used in the printer's USB, and network interfaces. It also lists pin assignments, signal functions, timings, connector specifications, and voltage levels. • USB Interface • Network Interface USB Interface This printer supports the Hi-Speed USB. USB (Universal Serial Bus) interface specifications and interface signals are as follows.
Page 207: Network Interface
Network Interface Features Automatic IP Address Resolution This feature is compatible with the DHCP/DHCPv6 protocol and allows the printer to automatically receive IP addresses from the DHCP/DHCPv6 server. Management using Web Browsers HTTP pages are incorporated in to the interface, so that a web browser can be used to monitor and change a range of settings.
Page 208 Operation Environment 10 to 35 °C (50 to 95 °F), 20-80 % RH (condensation-free) EMI Countermeasures VCCI Class B, FCC Class B (U.S.), CE (Europe) IMPORTANT When IPv6 functions are used, the devices used on the network (routers, PCs, etc) must support IPv6.
Page 209: About The Options
About the Options This printer has the following options available to satisfy your printing requirements. For instructions on installing individual options, refer to the documentation included with the option. Some options are explained in the following sections. Paper Feeder PF-500/ PF-510 Base CA-500 USB memory Memory Card (CF)
Page 210: Expansion Memory Modules
Expansion Memory Modules The printer's main controller board has a memory slot into which you can plug in optional memory modules (dual in line memory modules). You can increase the printer's memory up to 1280 MB by plugging in the optional memory modules.
Page 211 Installing the Memory Modules IMPORTANT Remove any USB memory that is attached to the printer's USB memory slot. Power off the printer and unplug the printer power cord. Unscrew two screws at the back of the main controller board. Pull out the main controller board gently. Main Controller Board Remove the memory module from its package.
Page 212 Checking Expansion Memory After installing expansion memory, use the following method to check that it is correctly installed. In the Report Print menu, press to select Status Page. Press [OK]. A confirmation message is displayed. Press [Yes] ([Left Select]). Accepted. appears and the printer Print.
Page 213: General Description Of Options
General Description of Options Memory Card The printer is equipped with a slot for a memory card with the maximum size of 4 GB. A memory card is useful for storing fonts, macros, and overlays. Reading the Memory Card Once inserted in the printer’s slot, the contents of the memory card can be read from the operation panel or automatically when you power on or reset the printer.
Page 214 PF-510 : Paper size : Envelope Monarch, Envelope #10, Envelope #9, Envelope #6, Envelope DL, Envelope C5, A5, B5, ISO B5, A4, Executive, Letter, Legal, OufukuHagaki, Oficio II, Statement, Folio, Youkei 2, Youkei 4, 16K and Other (92 x 162 mm to 216 x 356 mm) Paper type : Plain, Preprinted, Labels, Bond, Recycled, Rough, Letterhead, Color, Prepunched, Cardstock, Envelope, Coated, Thick, High quality, CUSTOM 1 (to 8)
Page 215 USB Memory USB memory is a type of simple, highly portable flash memory that plugs into the USB memory slot. Files stored in USB memory can be printed by plugging the USB memory into the printer and then specifying the desired file names from the operation panel.
Page 216: Specifications
Specifications Note Specifications are subject to change without notice. Item Description Printing Method Electrophotographic four color (CMYK) printing using tandem (4) drum system Printing Speeds A4,B5,A5: 35 ppm Letter: 37 ppm Legal: 30 ppm Duplex Printing Speed A4,B5,A5,Letter: 35 ppm Legal: 30 ppm Resolution 600 dpi...
Page 217 Item Description † Paper Types Cassette Plain, Preprinted, Bond, Recycled, Rough, Letterhead, Color, Prepunched, High (Optional Paper quality, and CUSTOM 1 (to 8) Feeder PF-500) Cassette Plain, Preprinted, Labels, Bond, Recycled, Rough, Letterhead, Color, (Optional Paper Feeder Prepunched, Envelope, Cardstock, Coated, Thick, High quality, and CUSTOM 1 PF-510) (to 8) MP Tray...
Page 218 A-14...
Page 219: Glossary
Glossary Additional memory An additional memory (optional) is used for increasing the memory capacity of this machine. For DIMM that can be used in this machine, contact your service technician. AppleTalk AppleTalk offers file sharing and printer sharing and it also enables you to utilize application software that is on another computer on the same AppleTalk network.
Page 220: Printer Driver
KPDL KPDL is Kyocera’s implementation of the PostScript page description language Level3. MP Tray This tray is used instead of the cassette when printing on envelopes, postcards, transparency sheets, and labels.
Page 221: Subnet Mask
Sleep mode This mode is provided to save power. It is activated when the machine is not used for a preset period of time. In this mode, power is reduced to the minimum. The default setting can be changed. Status page This lists machine conditions, such as the machine’s memory, the total number of prints and paper source settings.
Page 222 Glossary-4...
Page 223: Index
Index Administrator....... . . 4-103 Indicator ....... . 1-4, 4-5 Appendix.
Page 224 ........6-16 Message Display ......1-4, 4-3 MP Tray .
Page 225 ........4-17 Print .
Page 226 Index-4...
Page 227 We recommend the use of our own brand supplies. We will not be liable for any damage caused by the use of third party supplies in this machine.
Page 229 2009 is a trademark of Kyocera Corporation...
Page 230 MEMO...
Page 231 MEMO...
Page 232 Rev. 1 2009.9 Printed in China 302HG56011...

This manual is also suitable for:
