Important
Please read PRECAUTIONS, this User's Manual, Setup Guide and
Specifications Sheet (separate volumes) carefully to familiarize yourself with
safe and effective usage.
• Please read the Setup Guide (separate volume).
• Please read the Specifications Sheet for details on the specifications of
the monitor.
• The latest User's Manual is available for download from our site:
http://www.eizo.com
Advertisement
Table of Contents
Related Manuals for Eizo FlexScan EV2303W
Summary of Contents for Eizo FlexScan EV2303W
- Page 1 Specifications Sheet (separate volumes) carefully to familiarize yourself with safe and effective usage. • Please read the Setup Guide (separate volume). • Please read the Specifications Sheet for details on the specifications of the monitor. • The latest User’s Manual is available for download from our site: http://www.eizo.com...
- Page 2 EIZO NANAO CORPORATION’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.
-
Page 3: Notice For This Monitor
Notice for this monitor This product is suited to creating documents, viewing multimedia content, and other general purposes. This product has been adjusted specifically for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as specified in the specifications. This product may not be covered by warranty for uses other than those described in this manual. - Page 4 Cleaning Attention • Never use any solvents or chemicals, such as thinner, benzene, wax, alcohol, and abrasive cleaner, which may damage the cabinet or LCD panel. NOTE • Optional ScreenCleaner is recommended for cleaning the panel surface. [LCD Panel] • Clean the LCD panel with a soft cloth such as cotton cloth or lens cleaning paper. •...
-
Page 5: Table Of Contents
[Information] ..6 -16 Enabling/Disabling DDC/CI communication [DDC/CI] ... 7 -17 Setting Power Indicator ON/OFF [Power Indicator] ... 7 -18 Setting Language [Language] ... 7 -19 Setting EIZO logo display ON/OFF ..7 -0 Resuming the Default Setting [Reset] ... 8 ● To reset color adjustment values ... 28 ● To reset all adjustments to the factory default settings ... - Page 6 CONTENTS Chapter Reference ... -1 Attaching an Arm ... - Attaching the FlexStand ..6 - Folding the TriStand ... 7 - Folding the TriStand ... 8 - Glossary ... 0 -6 Preset Timing ... FCC Declaration of Conformity ... Hinweise zur Auswahl des richtigen Schwenkarms für Ihren Monitor .. Hinweis zur Ergonomie .. CONTENTS...
-
Page 7: Chapter 1 Features And Overview
Chapter 1 Features and Overview Thank you very much for choosing an EIZO color LCD monitor. 1-1 Features • 20” wide format LCD (EV2023W)/23” wide format LCD (EV2303W) • Applicable to the resolution of 1600 × 900 (EV2023W)/Applicable to the resolution of 1920 × 1080 (EV2303W) •... -
Page 8: Controls And Functions
Stereo mini jack Security lock slot Stand Cable holder Speaker Headphone jack * ScreenManager is an EIZO’s nickname of the Adjustment menu. See ® Chapter 1 Features and Overview Detects the movement of a person in front of the monitor. EcoView Sense function (page 22). Detects ambient brightness. Auto EcoView function... -
Page 9: Functions And Basic Operation
1- Functions and Basic Operation To adjust the screen and color Main menu (Refer to page 1 for operation) [At analog signal input] [At digital signal input] • The Adjustment menu and the FineContrast mode name cannot be displayed at the same time. FineContrast mode Color Adjustment Simple Adjustment [FineContrast mode] This function allows easy selection of a desired mode from five modes according to monitor application. Brightness and volume direct menu Brightness and Volume Adjustment to display the adjustment menu. - Page 10 To use the monitor with low power consumption Main menu (Refer to page 1 for operation) [At analog signal input] [At digital signal input] • The Adjustment menu and the EcoView menu cannot be displayed at the same time. • EcoView menu is temporarily displayed when the power of the monitor is turned on. EcoView menu Setting On/Off for the EcoView function (power saving function) This monitor is equipped with the EcoView function for power saving.
- Page 11 Setting Language [Language] ● Locking Buttons ……………………… see ● Enabling/Disabling DDC/CI communication [DDC/CI] ……………………………… see ● Setting EIZO logo display ON/OFF … see Other Settings ● To set input signal selection [Input Signal] ……………………… see ● To change screen size [Screen Size] ……………………… see ●...
- Page 12 Basic operation of Adjustment menu [Displaying Adjustment menu and selecting function] (1) Press . The Main menu appears. (2) Select a function with (3) Select a function with (4) Adjust the selected item with [Exiting Adjustment menu] (1) Choose <Return> from the Sub menu and press (2) Choose <Exit> from the Main menu and press NOTE •...
-
Page 13: Chapter Settings And Adjustments
Chapter Settings and Adjustments -1 Utility Disk An “EIZO LCD Utility Disk” (CD-ROM) is supplied with the monitor. The following table shows the disk contents and the overview of the software programs. ● Disk contents and software overview The disk includes software programs for adjustment, and User's Manual. Refer to “Readme.txt” or the “read me” file on the disk for software startup procedures or file access procedures. -
Page 14: Screen Adjustment
5 “To adjust color gradation automatically [Range]”. Prepare the display pattern for the analog display adjustment. ■ For Windows PC Load the "EIZO LCD Utility Disk" to your PC, and then start the "Screen Adjustment Utility" from the menu window. If it cannot be started, open the screen adjustment pattern files. - Page 15 Perform the auto adjustment again with the analog screen adjustment pattern displayed. ● To adjust flickering, screen position, and screen size automatically [Screen] (1) Display Pattern 1 in full screen on the monitor using the “Screen Adjustment Utility” or the screen adjustment pattern files. (2) Choose <Screen> from the <Auto Adjustment> menu, and press The <Auto Adjustment> menu appears. (3) Choose <Execute>...
- Page 16 ● To correct screen position [Position] (1) Choose <Position> from the <Screen> menu, and press The <Position> menu appears. (2) Adjust the position with properly in the display area of the monitor, and press The adjustment is completed. Adjust the color gradation. ● To adjust color gradation automatically [Range] Every color gradation (0 to 255) can be displayed by adjusting the signal output level.
-
Page 17: Color Adjustment
- Color Adjustment ● To select the display mode (FineContrast mode) FineContrast allows you to select the best display mode easily according to the monitor’s application. FineContrast mode Mode Custom Available to change all setting values. Suitable for color matching with sRGB compatible sRGB peripherals. Suitable for displaying texts for word processing or Text spreadsheets. -
Page 18: To Perform Advanced Adjustments
● To perform advanced adjustments Independent setting and saving of color adjustment are available for each FineContrast mode. ● Adjustment items in each mode According to the FineContrast mode selected, the adjustable function differs. √ : Adjustment available −: Invalid for adjustment Icon Function Custom Brightness √ Contrast √... -
Page 19: To Adjust The Color Temperature [Temperature]
● To adjust the color temperature [Temperature] The color temperature can be adjusted. The color temperature is normally used to express the hue of “White” and/or “Black” by a numerical value. The value is expressed in degrees “K” (Kelvin). In the same way as the flame temperature, the image on the monitor is displayed reddish if the color temperature is low and is bluish if the color temperature is high. -
Page 20: To Adjust The Hue [Hue]
● To adjust the hue [Hue] This function allows you to adjust the hue. If you set the hue to a high value, the image turns greenish. If low, the image turns purplish. Adjustable range: -32 to 32 (1) Choose <Color> from the Adjustment menu, and press (2) Choose <Hue>... -
Page 21: Setting On/Off For Power Saving Mode [Power Save]
-6 Setting On/Off for Power Saving mode [Power Save] This function allows you to set the monitor into the power saving mode according to the PC status. When the monitor has shifted to the power saving mode, the images on the screen are not displayed. (1) Choose <PowerManager> from the Adjustment menu, and press (2) Choose <Power Save>... -
Page 22: Setting On/Off For The Automatic Brightness
-8 Setting On/Off for the automatic brightness adjustment function [Auto EcoView] The sensor on the front side of the monitor detects the environmental brightness to adjust the screen brightness automatically and comfortably by using the Auto EcoView function. (1) Press The <EcoView> setting menu appears. (2) Choose "Auto EcoView" with (3) Select “On”... -
Page 23: Setting On/Off For The Power Saving Level
(1) Choose <PowerManager> from the Adjustment menu, and press (2) Choose <EcoView Sense> from the <PowerManager> menu, and press The <EcoView Sense> setting menu appears. (3) Select "Auto" or "Manual" with When selecting "Manual", select 1, 2 or 3 for the detection level of the sensor with (4) Press The setting is completed. -
Page 24: Screen Size Selection
-11 Screen Size Selection ● To change screen size [Screen Size] The image with the resolution other than the recommended resolution is displayed in full screen automatically. You can change the screen size by using <Screen Size> from <Others> menu. Menu Displays an image in full screen. Images are distorted in Full Screen some cases because the vertical rate is not equal to the (default setting) -
Page 25: Setting Adjustment Menu Display
-1 Setting Adjustment Menu Display ● To update menu settings [Menu Size/Menu Position/Menu Off Timer/Translucent] Menu Size Change the Adjustment menu size using the following procedure. (1) Choose <Others> from the Adjustment menu, and press (2) Choose <Menu Settings> from the <Others> menu, and press (3) Choose <Menu Size> from the <Menu Settings> menu, and press The <Menu Size>... -
Page 26: Setting Orientation
-1 Setting Orientation ● To set the orientation of the Adjustment menu [Orientation] This function allows you to change the orientation of the Adjustment menu when using the monitor screen in vertical display position. (1) Choose <Others> from the Adjustment menu, and press (2) Choose <Orientation> from the Others menu, and press The <Orientation>... -
Page 27: Enabling/Disabling Ddc/Ci Communication [Ddc
(1) Press to turn off the monitor. (2) Press down to turn on the monitor. holding The EIZO logo display setting is toggled by performing the operation in step 2. , and press , and press NOTE NOTE • You can check the DDC/CI setting in •... -
Page 28: Resuming The Default Setting [Reset]
-0 Resuming the Default Setting [Reset] There are two types of Reset. One is to reset the color adjustment only to the default settings, and the other is to reset all the settings to the default settings. ● To reset color adjustment values Only the adjustment values in the current FineContrast mode will revert to the default settings (factory settings). -
Page 29: Chapter Connecting Cables
Chapter Connecting Cables -1 Connecting Two PCs to the Monitor Two PCs can be connected to the monitor through the DVI-D and the D-Sub mini 15 pin connector on the back of the monitor. Connection examples DVI-D connector To PC 1 DVI-D connector Signal cable (Digital) FD-C39 ●... -
Page 30: To Set Input Signal Selection [Input Signal]
● To set input signal selection [Input Signal] The monitor recognizes the connector through which PC signals are input. When either PC is turned off or enters the power-saving mode, the monitor automatically displays signals of another PC. Priority setting Auto When either PC is turned off or enters the power- saving mode, the monitor automatically displays signals of another PC. -
Page 31: Chapter Troubleshooting
Chapter Troubleshooting If a problem still remains after applying the suggested remedies, contact your local dealer. • No-picture problems → See No.1 - No.2. • Imaging problems (digital input) → See No.3 - No.8. • Imaging problems (analog input) → See No.3 - No.12. •... - Page 32 Problems . Afterimages appear. 6. Green/red/blue/white dots or defective dots remain on the screen. 7. Interference patterns or pressure marks remain on the screen. 8. Noise appears on the screen. 9. Display position is incorrect. 10. Vertical bars appear on the screen or a part of the image is flickering. 11. Whole screen is flickering or blurring. 1. Upper part of the screen is distorted as shown below. 1. The <Smoothing> icon on the Adjustment menu <Screen> cannot be selected. 1. The adjustment menu does not appear. 1. The FineContrast mode is not displayed. 16. The auto adjust function does not work correctly. 17. No audio output. Chapter 4 Troubleshooting Possible cause and remedy • Use a screen saver or off timer function for a long-time image display.
- Page 33 Problems 18. (When using EcoView Sense) The images remains to be displayed when you move away from the monitor. The images does not reappear when you come near it. Possible cause and remedy • Check the setting environment of the monitor. EcoView Sense may not work correctly in the following environments. • There is something that reflects the light such as mirror or glass in front of the sensor. •...
-
Page 34: Chapter Reference
Chapter Reference -1 Attaching an Arm The stand can be removed and replaced with an arm (or another stand) to be attached to the monitor. Use an arm or stand of EIZO option. When using the monitor with "Portrait" position, change the position to "Landscape". Lay the LCD monitor on a soft cloth spread over on a stable surface with the panel surface facing down. Chapter 5 Reference Attention • When attaching an arm or stand, follow the instructions of their user’s... - Page 35 Remove the stand. ● FlexStand Remove the stand from the monitor while releasing the lock. ● TriStand Prepare a screwdriver. Loosen the screw securing the unit and the stand with the screwdriver. Attach the monitor to the arm or stand. Secure the monitor to the arm or stand using the screws specified in the user’s manual of the arm or stand.
-
Page 36: Attaching The Flexstand
- Attaching the FlexStand The once removed the FlexStand can be attached to the monitor again with the following procedures. Put the insertion part of the stand in the slot of the monitor. At the time, use as a guide that the marks (1) on the stand match to the screw holes (2) of the monitor. Attach the stand moving the monitor toward the stand. - Page 37 - Attaching the TriStand The once removed the TriStand can be attached to the monitor again with the following procedures. Lay the LCD monitor on a soft cloth spread over on a stable surface with the panel surface facing down. Put the insertion part of the stand in the slot of the monitor. Prepare a screwdriver. Press the upper part of the stand against the unit and tighten the screw with the screwdriver to fix the stand to the unit. Chapter 5 Reference...
-
Page 38: Folding The Tristand
- Folding the TriStand Perform the following procedures to remove the stand base and fold the stand when re-packing a monitor with a TriStand. Open the cable holder. Adjust the monitor to its lowest position, and insert a pin into the stand. Lay the LCD monitor on a soft cloth spread over on a stable surface with the panel surface facing down. Open the cover of stand base. Chapter 5 Reference... - Page 39 Rotate the stand base in a counterclockwise direction while holding down the protrusion, and then remove the stand base. Chapter 5 Reference...
-
Page 40: Glossary
- Glossary Clock The analog input monitor needs to reproduce a clock of the same frequency as the dot clock of the graphics system in use, when the analog input signal is converted to a digital signal for image display. This is called clock adjustment. - Page 41 sRGB (Standard RGB) International standard for “color reproduction and color space” among peripheral devices (such as monitors, printers, digital cameras, scanners). sRGB allows Internet users to closely match colors as a simple color matching means for the Internet use. Temperature Color temperature is a method to measure the white color tone, generally indicated in degrees Kelvin. The screen becomes reddish at a low temperature, and bluish at a high temperature, like the flame temperature.
-
Page 42: Preset Timing
-6 Preset Timing The following table shows factory preset video timing (for analog signal only). Mode Dot clock VGA 640×480@60Hz 25.2 MHz VGA TEXT 28.3 MHz 720×400@70Hz VESA 640×480@73Hz 31.5 MHz VESA 640×480@75Hz 31.5 MHz VESA 800×600@56Hz 36.0 MHz VESA 800×600@60Hz 40.0 MHz VESA 800×600@72Hz 50.0 MHz VESA 800×600@75Hz... -
Page 43: Fcc Declaration Of Conformity
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord - Shielded Signal Cable (enclosed) This Class B digital apparatus complies with Canadian ICES-003. - Page 44 Hinweise zur Auswahl des richtigen Schwenkarms für Ihren Monitor Dieser Monitor ist für Bildschirmarbeitsplätze vorgesehen. Wenn nicht der zum Standardzubehör gehörige Schwenkarm verwendet wird, muss statt dessen ein geeigneter anderer Schwenkarm installiert werden. Bei der Auswahl des Schwenkarms sind die nachstehenden Hinweise zu berücksichtigen: Der Standfuß...
