  • Page 1 (separate volumes) carefully to familiarize yourself with safe and effective usage. • Please read to the Setup Guide for basic information ranging from connection of the monitor to a PC to using the monitor. • The latest User’s Manual is available for download from our site: http://www.eizo.com...
  • Page 2 EIZO NANAO CORPORATION’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.

  • Page 3: Notice For This Monitor

    Notice for this monitor This product is suited to creating documents, viewing multimedia content, and other general purposes. This product has been adjusted specifically for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as specified in the specifications. This product may not be covered by warranty for uses other than those described in this manual.

  • Page 4: To Use The Monitor Comfortably

    Cleaning Attention • Never use any solvents or chemicals, such as thinner, benzene, wax, alcohol, and abrasive cleaner, which may damage the cabinet or LCD panel. NOTE • Optional ScreenCleaner is recommended for cleaning the panel surface. [LCD Panel] • Clean the LCD panel with a soft cloth such as cotton cloth or lens cleaning paper. •...

  • Page 5: Table Of Contents

    [Information] ..9 -17 Enabling/Disabling DDC/CI communication ... 9 -18 Setting Power Indicator ON/OFF [Power Indicator] ... 9 -19 Setting Language [Language] ... 9 -0 Setting EIZO logo display ON/OFF ..0 -1 Resuming the Default Setting [Reset] ... 0 ● To reset color adjustment values ... 30 ● To reset all adjustments to the factory default settings ...
  • Page 6 CONTENTS Chapter  Troubleshooting .. Chapter  Reference ... 6 -1 How to Attach the Optional Arm ..6 - Attaching the FlexStand ..8 - Attaching the TriStand ... 9 - Folding the TriStand ... 0 5-5 Specifications ...  -6 Glossary ... 8 -7 Preset Timing ... 0 FCC Declaration of Conformity ... 1 Hinweise zur Auswahl des richtigen Schwenkarms für Ihren Monitor .. Hinweis zur Ergonomie .

  • Page 7: Chapter 1 Features And Overview

    2-11 “Setting On/Off for the power saving level indicator [EcoView Index]” • Brightness stabilization through dimming control Supports brightness adjustments over a wide range (EV2313W: 2-100%, EV2333W: 20-100%). Even when lowering brightness to its minimum value, a stable and accurate image will be maintained. Even during use in an extremely dark place, the brightness can be adjusted to a level which is gentle and comfortable to the eye.
  • Page 8 Reference values: – EV2313W Maximum power consumption: 32W (Luminance Max., at default settings) Standard power consumption: 16W (100VAC, Luminance 120cd/m Standard power consumption: 16W (200VAC, Luminance 120cd/m – EV2333W Maximum power consumption: 42W (Luminance Max., at default settings) Standard power consumption: 25W (100VAC, Luminance 120cd/m...

  • Page 9: Cover

    Stereo mini jack Security lock slot Stand Cable holder Speaker Headphone jack * ScreenManager is an EIZO’s nickname of the Adjustment menu. See ® Detects the movement of a person in front of the monitor. EcoView Sense function (page 25). Detects ambient brightness. Auto EcoView function...

  • Page 10: Compatible Resolutions/Frequencies

    1- Compatible Resolutions/Frequencies The monitor supports the following resolutions. Analog Input (D-Sub) Resolution 640 × 480 (VGA, VESA) 720 × 400 (VGA TEXT) 800 × 600 (VESA) 1024 × 768 (VESA) 1152 × 864 (VESA) 1280 × 960 (VESA) 1280 × 1024 (VESA) 1280 ×...

  • Page 11: Functions And Basic Operation

    1- Functions and Basic Operation To adjust the screen and color Main menu (Refer to page 1 for operation) [At analog signal input] [At digital signal input] • The Adjustment menu and the FineContrast mode name cannot be displayed at the same time. FineContrast mode Color Adjustment Simple Adjustment [FineContrast mode] This function allows easy selection of a desired mode from five modes according to monitor application. Brightness and volume direct menu Brightness and Volume Adjustment Press...
  • Page 12 To use the monitor with low power consumption Main menu (Refer to page 1 for operation) [At analog signal input] [At digital signal input] • The Adjustment menu and the EcoView menu cannot be displayed at the same time. • EcoView menu is temporarily displayed when the power of the monitor is turned on. EcoView menu Setting On/Off for the EcoView function (power saving function) This monitor is equipped with the EcoView function for power saving.
  • Page 13 Setting Language [Language] ● Locking Buttons ……………………… see ● Enabling/Disabling DDC/CI communication ………………………………………… see ● Setting EIZO logo display ON/OFF … see Other Settings ● To change screen size [Screen Size] ……………………… see ● To adjust brightness of non-display area [Border Intensity] …………………… see ●...

  • Page 14: Basic Operation Of Adjustment Menu

    Basic operation of Adjustment menu [Displaying Adjustment menu and selecting function] (1) Press . The Main menu appears. (2) Select a function with (3) Select a function with (4) Adjust the selected item with [Exiting Adjustment menu] (1) Choose <Return> from the Sub menu and press (2) Choose <Exit> from the Main menu and press NOTE •...

  • Page 15: Chapter  Settings And Adjustments

    Chapter  Settings and Adjustments -1 Utility Disk An “EIZO LCD Utility Disk” (CD-ROM) is supplied with the monitor. The following table shows the disk contents and the overview of the software programs. ● Disk contents and software overview The disk includes software programs for adjustment, and User's Manual. Refer to “Readme.txt” file on the disk for software startup procedures or file access procedures.

  • Page 16: Screen Adjustment

    When the screen is displayed correctly, go to step 5 “To adjust color gradation automatically [Range]”. Prepare the display pattern for the analog display adjustment. Load the “EIZO LCD Utility Disk” to your PC, and then open the “Screen adjustment pattern files”. Chapter 2 Settings and Adjustments...

  • Page 17: To Eliminate Vertical Bars [Clock]

    Perform the auto adjustment again with the analog screen adjustment pattern displayed. ● To adjust flickering, screen position, and screen size automatically [Screen] (1) Display Pattern 1 of the “Screen adjustment pattern files” in full screen on the monitor. (2) Choose <Screen> from the <Auto Adjustment> menu, and press The <Auto Adjustment> menu appears. (3) Choose “Execute” with Flickering, screen position, and screen size are corrected by the auto- adjustment function.

  • Page 18: To Correct Screen Position [Position]

    ● To correct screen position [Position] (1) Choose <Position> from the <Screen> menu, and press The <Position> menu appears. (2) Adjust the position with properly in the display area of the monitor, and press The adjustment is completed. Adjust the color gradation. ● To adjust color gradation automatically [Range] Every color gradation (0 to 255) can be displayed by adjusting the signal output level.

  • Page 19: Color Adjustment

    - Color Adjustment ● To select the display mode (FineContrast mode) FineContrast allows you to select the best display mode easily according to the monitor’s application. FineContrast mode Mode Custom Available to change all setting values. Suitable for color matching with sRGB compatible sRGB peripherals. Suitable for displaying texts for word processing or Text spreadsheets.

  • Page 20: To Perform Advanced Adjustments

    ● To perform advanced adjustments Independent setting and saving of color adjustment are available for each FineContrast mode. ● Adjustment items in each mode According to the FineContrast mode selected, the adjustable function differs. √ : Adjustment available −: Invalid for adjustment Icon Function Custom √ Brightness √...

  • Page 21: To Adjust The Contrast [Contrast]

    ● To adjust the contrast [Contrast] The luminance of the screen is adjusted by varying the video signal level. Adjustable range: 0 to 100% (1) Choose <Color> from the Adjustment menu, and press (2) Choose <Contrast> from the <Color> menu, and press The <Contrast> adjustment menu appears. (3) Adjust the contrast with The adjustment is completed.

  • Page 22: To Adjust The Color Saturation [Saturation]

    ● To adjust the color saturation [Saturation] This function allows you to adjust the saturation of the color on the monitor. Adjustable range: -128 to 127 (1) Choose <Color> from the Adjustment menu, and press (2) Choose <Saturation> from the <Color> menu, and press The <Saturation> adjustment menu appears. (3) Adjust the saturation of the color with The adjustment is completed.

  • Page 23: Adjusting Volume [Volume]

    - Adjusting Volume [Volume] This function allows you to adjust volume up or down. Adjustable range: 0 to 30 (1) Choose <Sound> from the Adjustment menu, and press (2) Choose <Volume> from the <Sound> menu, and press The volume adjustment menu appears. (3) Adjust the volume with The adjustment is completed.

  • Page 24: Turning Off The Monitor Automatically [Off Timer]

    ■ Analog input This monitor complies with the VESA DPM standard. [Power Saving System] Operating Power saving STAND-BY SUSPENDED ■ Digital input • DVI This monitor complies with the DVI DMPM standard. • DisplayPort This monitor complies with the DisplayPort Standard V1.1a. [Power Saving System] The monitor enters the power saving mode in five seconds in connection with the PC setting.

  • Page 25: Shifting To The Power Saving Mode When A Person Leaves The Monitor [Ecoview Sense]

    -10 Shifting to the power saving mode when a person leaves the monitor [EcoView Sense] The sensor on the front side of the monitor detects the movement of a person by using the EcoView Sense function. When a person moves away from the monitor, it shifts to the power saving mode automatically and does not display the images on the screen to reduce the power consumption.

  • Page 26: Setting On/Off For The Power Saving Level Indicator [Ecoview Index]

    -11 Setting On/Off for the power saving level indicator [EcoView Index] By using the EcoView Index function, the indicator that shows the level of power saving appears at the time of turning on the monitor, adjusting the brightness or switching the FineContrast mode. The power saving ratio comes to high as the indicator level meter lights towards right.

  • Page 27: To Adjust Brightness Of Non-Display Area [Border Intensity]

    ● To adjust brightness of non-display area [Border Intensity] A border (black area with no image) around the image appears in the “Normal” or “Enlarged” mode. (1) Choose <Others> from the Adjustment menu, and press (2) Choose <Border Intensity> from the <Others> menu, and press The <Border Intensity> menu appears. (3) Adjust border intensity with The border intensity adjustment is completed.

  • Page 28: Setting Orientation

    Menu Off Timer Set the menu display time using the following procedure. Adjustment range: Disable, Enable (15, 30, 45, 60s) (1) Choose <Others> from the Adjustment menu, and press (2) Choose <Menu Settings> from the <Others> menu, and press (3) Choose <Menu Off Timer> from the <Menu Settings> menu, and press The <Menu Off Timer>...

  • Page 29: Displaying Monitor Information [Information]

    -16 Displaying Monitor Information [Information] This function allows you to display the input signal status, current resolution and model name. Information 1/3 : Input signal status, resolution and H/V frequency Information 2/3 : Enable/Disable setting for DDC/CI Information 3/3 : Model name, serial number and usage time (1) Choose <Information>...

  • Page 30: Setting Eizo Logo Display On/Off

    (2) Press down to turn on the monitor. holding The EIZO logo display setting is toggled by performing the operation in step 2. -1 Resuming the Default Setting [Reset] There are two types of Reset. One is to reset the color adjustment only to the default settings, and the other is to reset all the settings to the default settings.

  • Page 31: Chapter  Connecting Cables

    Chapter  Connecting Cables -1 Connecting More than Two PCs to the Monitor More than two PCs can be connected to the monitor through the D-Sub mini 15 pin, the DVI-D and the DisplayPort connector on the back of the monitor. Connection examples DisplayPort D-Sub mini DVI-D connector connector 15-pin Connector Digital(DVI) Digital(DisplayPort)

  • Page 32: To Switch The Input Signal

    ● To switch the input signal The input signal switches each time When the signal is switched, the active input port name appears at the top right corner of the screen. ● To set input signal selection [Input Signal] Setting Auto The monitor recognizes the connector through which PC signals are input. When a PC is turned off or enters the powersaving mode, the monitor automatically displays another signal.

  • Page 33: Chapter  Troubleshooting

    Chapter  Troubleshooting If a problem still remains after applying the suggested remedies, contact your local dealer. • No-picture problems → See No.1 - No.2. • Imaging problems (digital input) → See No.3 - No.8. • Imaging problems (analog input) → See No.3 - No.11. •...
  • Page 34 Problems . Afterimages appear. 6. Green/red/blue/white dots or defective dots remain on the screen. 7. Interference patterns or pressure marks remain on the screen. 8. Noise appears on the screen. 9. Display position is incorrect. 10. Vertical bars appear on the screen or a part of the image is flickering. 11. Whole screen is flickering or blurring. 1. The <Smoothing> icon on the Adjustment menu <Screen> cannot be selected. 1. The adjustment menu does not appear. 1. The FineContrast mode is not displayed. 1. The auto adjust function does not work correctly. 16. No audio output. Chapter 4 Troubleshooting Possible cause and remedy • Afterimages are particular to LCD monitors. Avoid displaying the same image for a long time.
  • Page 35 Problems 17. (When using EcoView Sense) The images remains to be displayed when you move away from the monitor. The images does not reappear when you come near it. Possible cause and remedy • Check the setting environment of the monitor. EcoView Sense may not work correctly in the following environments. • There is something that reflects the light such as mirror or glass in front of the sensor. •...

  • Page 36: Chapter  Reference

    Chapter  Reference -1 How to Attach the Optional Arm An optional arm (or an optional stand) can be attached by removing the stand section. Please refer to our web site for the corresponding optional arm (or optional stand). http://www.eizo.com When using the monitor with "Portrait" position, change the position to "Landscape". Lay the LCD monitor on a soft cloth spread over on a stable surface with the panel surface facing down. Chapter 5 Reference Attention •...

  • Page 37: Remove The Stand

    Remove the stand. ● FlexStand Remove the stand from the monitor while releasing the lock. ● TriStand Prepare a screwdriver. Loosen the screw securing the unit and the stand with the screwdriver. Attach the monitor to the arm or stand. Secure the monitor to the arm or stand using the screws specified in the user’s manual of the arm or stand.

  • Page 38: Attaching The Flexstand

    - Attaching the FlexStand The once removed the FlexStand can be attached to the monitor again with the following procedures. Put the insertion part of the stand in the slot of the monitor. At the time, use as a guide that the marks (1) on the stand match to the screw holes (2) of the monitor. Attach the stand moving the monitor toward the stand.

  • Page 39: Attaching The Tristand

    - Attaching the TriStand The once removed the TriStand can be attached to the monitor again with the following procedures. Lay the LCD monitor on a soft cloth spread over on a stable surface with the panel surface facing down. Put the insertion part of the stand in the slot of the monitor. Prepare a screwdriver. Press the upper part of the stand against the unit and tighten the screw with the screwdriver to fix the stand to the unit. Chapter 5 Reference...

  • Page 40: Folding The Tristand

    - Folding the TriStand Perform the following procedures to remove the stand base and fold the stand when re-packing a monitor with a TriStand. Open the cable holder. Adjust the monitor to its lowest position, and insert a pin into the stand. Lay the LCD monitor on a soft cloth spread over on a stable surface with the panel surface facing down. Open the cover of stand base. Chapter 5 Reference...
  • Page 41 Rotate the stand base in a counterclockwise direction while holding down the protrusion, and then remove the stand base. Chapter 5 Reference...

  • Page 42: Specifications

    5-5 Specifications EV1W LCD Panel Dot Pitch Horizontal Scan Frequency Vertical Scan Frequency Resolution Max. Dot Clock Max. Display Color Display Area (H × V) Power Supply Power Screen Display On Consumption Power saving mode Power button Off Main Power switch Off Input Signal Connector Analog Input Signal (Sync) Analog Input Signal (Video)
  • Page 43 Mass Main unit (including FlexStand) Main unit (including TriStand) Main unit (without stand) Approx. 3.6 kg (7.9 lbs.) Movable range FlexStand TriStand Environmental Temperature Conditions Humidity Pressure EVW LCD Panel Dot Pitch Horizontal Scan Frequency Vertical Scan Frequency Resolution Max. Dot Clock Max.
  • Page 44 Video Signal Memory Audio Output Line input Plug & Play Dimensions Main unit (Width) × (including FlexStand) (Height) × Main unit (Depth) (including TriStand) Main unit (without stand) 547 mm (21.5 inch) × 332 mm (13.1 inch) × 47.5 mm (1.87 inch) Mass Main unit (including FlexStand)

  • Page 45: Chapter 5 Reference

    Outside Dimensions EV1W • FlexStand 465(18.3) SWIVEL 547(21.5) 17.6(0.69) 511.8(20.1) 17.6(0.69) PIVOT 200(7.9) • TriStand 465(18.3) SWIVEL 547(21.5) 17.6(0.69) 511.8(20.1) 263(10.4) 179.9(7.1) TILT 195.5(7.7) 12.4(0.49) 56.1(2.21) 221(8.7) 216(8.5) 236(9.3) 190(7.5) 142.5(5.6) TILT 12.4(0.49) 57.6(2.27) φ200 (7.9) unit : mm (inch) unit : mm (inch) Chapter 5 Reference...
  • Page 46 EVW • FlexStand 465(18.3) SWIVEL 547(21.5) 17.6(0.69) 511.8(20.1) 17.6(0.69) PIVOT 200(7.9) • TriStand 465(18.3) SWIVEL 547(21.5) 17.6(0.69) 511.8(20.1) Chapter 5 Reference 266(10.5) 183.4(7.2) TILT 199(7.8) 12.4(0.49) 52.6(2.07) 216(8.5) 221(8.7) 236(9.3) 193(7.6) 146(5.7) TILT 12.4(0.49) 54.1(2.13) φ200 (7.9) unit : mm (inch) unit : mm (inch)
  • Page 47 Green video ground Blue video ground Ground Pin No. Signal Ground ML Lane1+ ML Lane0- Ground ML Lane0+ CONFIG1 CONFIG2 EIZO ScreenCleaner PP200 Pin No. Signal T.M.D.S. Data0- T.M.D.S. Data0+ T.M.D.S. Data0/5 Shield T.M.D.S. Clock shield T.M.D.S. Clock+ T.M.D.S. Clock- (NC*: No Connection) Pin No.

  • Page 48: Glossary

    -6 Glossary Clock The analog input monitor needs to reproduce a clock of the same frequency as the dot clock of the graphics system in use, when the analog input signal is converted to a digital signal for image display. This is called clock adjustment.
  • Page 49 Range Adjustment Range adjustment controls the signal output levels to display every color gradation. It is recommended that range adjustment be made before color adjustment. Resolution The LCD panel consists of numerous pixels of specified size, which are illuminated to form images. This monitor consists of 1920 horizontal pixels and 1080 vertical pixels.

  • Page 50: Preset Timing

    -7 Preset Timing The following table shows factory preset video timing (for analog signal only). Mode Dot clock VGA 640×480@60Hz 25.2 MHz VGA TEXT 28.3 MHz 720×400@70Hz VESA 640×480@73Hz 31.5 MHz VESA 640×480@75Hz 31.5 MHz VESA 800×600@56Hz 36.0 MHz VESA 800×600@60Hz 40.0 MHz VESA 800×600@72Hz 50.0 MHz VESA 800×600@75Hz...

  • Page 51: Fcc Declaration Of Conformity

    Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord - Shielded Signal Cable (enclosed) This Class B digital apparatus complies with Canadian ICES-003.

  • Page 52: Hinweise Zur Auswahl Des Richtigen Schwenkarms Für Ihren Monitor

    Hinweise zur Auswahl des richtigen Schwenkarms für Ihren Monitor Dieser Monitor ist für Bildschirmarbeitsplätze vorgesehen. Wenn nicht der zum Standardzubehör gehörige Schwenkarm verwendet wird, muss statt dessen ein geeigneter anderer Schwenkarm installiert werden. Bei der Auswahl des Schwenkarms sind die nachstehenden Hinweise zu berücksichtigen: Der Standfuß...
  • Page 53 EV1W 本标识根据「电子信息产品污染控制管理办法」 ，适用于在中华人民共和国销售的电子信息产品。标识中央的 数字为环保使用期限的年数。只要您遵守该产品相关的安全及使用注意事项，在自制造日起算的年限内，不会 产生对环境污染或人体及财产的影响。上述标识粘贴在机器背面。 • 有毒有害物质或元素的名称及含量 部件名称 铅 （Pb） 印刷电路板 × 机箱 ○ 液晶显示器 × 其他 × ○： 表示该有毒有害物质在该部件所有均质材料中的含量均在 SJ/T 11363-2006 规定的限量要求以下。 ×： 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T 11363-2006 规定的限量要求。 ( 企业可在此处 , 根据实际情況对上表中打“×” 的技术原因进行进一步说明 ) 关于电子信息产品污染控制标识 有毒有害物质或元素 汞 镉 （Hg） （Cd） （Cr（VI）...
  • Page 54 EVW 本标识根据「电子信息产品污染控制管理办法」 ，适用于在中华人民共和国销售的电子信息产品。标识中央的 数字为环保使用期限的年数。只要您遵守该产品相关的安全及使用注意事项，在自制造日起算的年限内，不会 产生对环境污染或人体及财产的影响。上述标识粘贴在机器背面。 • 有毒有害物质或元素的名称及含量 部件名称 铅 （Pb） 印刷电路板 × 机箱 ○ 液晶显示器 × 其他 × ○： 表示该有毒有害物质在该部件所有均质材料中的含量均在 SJ/T 11363-2006 规定的限量要求以下。 ×： 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T 11363-2006 规定的限量要求。 ( 企业可在此处 , 根据实际情況对上表中打“×” 的技术原因进行进一步说明 ) 关于电子信息产品污染控制标识 有毒有害物质或元素 汞 镉 （Hg） （Cd） （Cr（VI）...
