Allied Telesis AT-RG613 AT-RG613 SERIES Specification Sheet

AT-RG613 SERIES
Residential Gateways
AT-RG613TX-xx
Residential gateway, 3 x 10/100TX LAN,
2 x FXS, 1 x 100TX WAN port
AT-RG613SH-xx
Residential gateway, 3 x 10/100TX LAN,
2 x FXS, 1 x 100FX SH dual fiber WAN port
AT-RG613LH-xx
Residential gateway, 3 x 10/100TX LAN,
2 x FXS, 1 x 100FX LH dual fiber WAN port
AT-RG613BD-xx
Residential gateway, 3 x 10/100TX LAN,
2 x FXS, 1 x 100FX single fiber BiDi WAN port
AT-RG613BD-10 Bundled
Residential gateway, 3 x 10/100TX LAN,
2 x FXS, 1 x 100FX single fiber BiDi WAN port
With Single-Fiber passive wall outlet & fiber
splice kit.
THE RESIDENTIAL GATEWAY
Providing powerful Layer 3 capabilities as well as
an enhanced VoIP feature-set the AT-RG600 Series
enters the marketplace as a new family of residen-
tial gateways from Allied Telesyn.
VLAN OPERATION WITH INTEGRAL
4-PORT SWITCH (1 X WAN, 3 X LAN)
An evolution of the successful AT-RG200 Series,
the AT-RG600 Residential Gateways support up to
16 port-based, IEEE 802.1Q-tagged VLANs across
its 3 x 10/100Mbps and 1 x 100Mbps WAN
switch ports.This potent combination provides
wirespeed Layer 2 switching between VLANs in
addition to high-performance Layer 3 routing
between VLANs in one highly cost-effective unit.
FIREWALL
The AT-RG600 Series protects customer-networks
using integral Stateful Inspection Firewalls with
NAT and Denial of Service intrusion detection and
blocking. Additionally, each VLAN can be config-
ured to be external, internal, or a DMZ. With the
Virtual Server features, Web or e-mail servers can
sit beyond the NAT and appear to be present on
the public interface.The AT-RG600 Series NAT
supports the most popular protocols and applica-
tions including NetMeeting (H.323 and SIP), IPSec,
and PPTP.
PORT RATE-LIMITING
The AT-RG600 Series provides the option to limit
the egress and ingress bandwidth of each port and
queue traffic with a granularity of 32kbps.This fea-
ture allows service operators to offer differentiat-
ed services to each customer while protecting its
network from malicious packet-flooding.
VOICE OVER IP (VOIP)
The AT-RG600 series offers a choice of Voice over
IP signaling methods—including H.323, SIP, and
MGCP with the NCS 1.0 profile.This multiple pro-
tocol support delivers maximum flexibility for
service providers, allowing them to provide IP
telephony services based on cost and feature-set,
rather than being limited by the protocol.
VIDEO STREAMING
Video streaming offers unique features that opti-
mize the delivery of video content to customers—
including VLAN, IGMP snooping, and proxying.The
AT-RG600 Series supports full IGMP snooping
capabilities (v1/v2) and individual LAN ports can
receive different multicast transmissions, whether
movies or TV channels.The AT-RG600 Series
snoops IGMP packets in-transit to determine the
destination-port for the particular multicast data.
This process results in high-quality, high-bandwidth
video streaming that does not affect Internet surf-
ing or IP telephony on adjacent ports.
RESIDENTIAL GATEWAYS
KEY FEATURES
• 3 x 10/100TX Ethernet ports
• 2 x FXS ports for Analog Telephones/Fax
• 100Mbps (copper or fiber) WAN interface
• Tagged-based VLAN (IEEE 802.1Q)
• Layer 2 & Layer 3 QoS
• IGMP snooping & proxying
• PPPoE protocol support
• UPnP IGD profile support & NAT traversal
• DHCP client, server & relay support
• Stateful Inspection Firewall
• Network Address Translations (NAT)
• H.323, SIP or MGCP VoIP protocol support
• G.711, G.726, G.729 & G.723 (optional)
• T.38 fax operation
• External AC power supply
• Optional External battery backup
• ZTC,Web GUI, SNMP, serial & Telnet CLI for
management & configuration
