SpectraLink Link 3000 Technical Bulletin

Technical Bulletin 99-01
Bulletin #: CS-99-001
Software Version: None
Access Level: Reseller
Status: Approved
Date: March 16, 1999
---------------------------------------------------------------------------------------------------------------------
Title:

Setting up a CBL100.

Purpose:

The purpose of a CBL100 is to convert the customer's existing Link 2000
cabling to Link 3000 cabling.

Installation:

The CBL100 is the same size as the JPI300. It is 6" high by 19" wide. It
mounts either in a 19" rack or on a wall.
There are 2 groups on each CBL100. Each group takes 1 RIC cable and 2 LIC
cables and converts them to 3 Interface Module Cables. The RIC is a male
connector. The LICs are female connectors. The Interface Modules are male
connectors.

How it works:

The panel takes the RIC cable and the 2 LIC cables and splits it out to 3
Interface Module cables. Here is the break down of each group:
Interface Base Stations
Modules
INTF 1 RIC 1-6
INTF 2 RIC 7-12
INTF 3 RIC 13-18
THE INFORMATION PROVIDED IN THE SPECTRALINK TECHNICAL BULLETIN IS PROVIDED "AS IS" WITHOUT
WARRANTY OF ANY KIND. NO OBLIGATION OR LIABILITY WILL ARISE OUT OF, SPECTRALINK RENDERING
TECHNICAL OR OTHER ADVICE OR SERVICE IN CONNECTION HEREWITH.
C:\windows\TEMP\Technical bulletin 99-01.doc
Lines
LIC1 1-16
LIC1 17-24 and LIC2 1-8
LIC2 9-24
DISCLAIMER
Product Type: Link 3000
Hardware Revision: None
Originator: Matt Jerger
Approvers: John Elms, Gary Bliss
10/19/00
