Dimensions of Parts:
The dimensions of the positions of the wall fixation screws (bolts) of the wall adapter are
described
The center of the wall adapter
(central axis)
490
765
(unit: mm)
885 (minimum) -1245 (maximum)
850
1160 (minimum) -1520 (maximum)
1125
142
100
100
142
6
100
Projector bottom surface
(including the legs)
100
Central axis
NP02WK
NP03WK
