DLP Cinema
Projector
®
User's Manual
DLP Cinema
Projector Head
®
NP-02HD
Light Module
NP-24LU01/NP-20LU01/NP-18LU01
Model No.
NP-02HD
NP-24LU01 / NP-20LU01 / NP-18LU01

Advertisement

Table of Contents
loading

Related Manuals for NEC DLP Cinema NP-02HD

Summary of Contents for NEC DLP Cinema NP-02HD

  • Page 1 DLP Cinema Projector ® User’s Manual DLP Cinema Projector Head ® NP-02HD Light Module NP-24LU01/NP-20LU01/NP-18LU01 Model No. NP-02HD NP-24LU01 / NP-20LU01 / NP-18LU01...

  • Page 2: Important Information

    Important Information Precautions: Please read this manual carefully before CAUTION using your NP-02HD and keep the manual handy for future reference. Use of controls or adjustments of procedures other than The NP-02 (projector head), NP-24LU01 / NP-20LU01 / those specified herein may lead to hazardous laser radi- NP-18LU01 (light module), NP-NC2402ML / NP-NC2002ML ation exposure.
  • Page 3 MAINTAIN AND SERVICE OF THE PRODUCT IS ONLY 2. Do not place any objects, which are easily affected by TO BE HANDLED BY NEC AUTHORIZED TECHNICIANS. heat, in front of the projector lens. Doing so could lead to the object melting from the heat that is emitted from the light output.
  • Page 4 Important Information For C2 connection, turn off the projector, shut down the Power Supply AC power to the projector and the light using a circuit 1. Consult your dealer for installing the power cable to the breaker, and contact your dealer/distributor. projector.
  • Page 5 Important Information CAUTION 1. Do not shut down AC power to the projector under the following conditions. Doing so can damage the projector. • While projecting images • While cooling after the power is turned off. (The STATUS indicator LED blinks in orange while the fan is rotating, and “cooling...” is displayed on the LCD screen.
  • Page 6 Email Address: contact@goldenduckgroup.com Fax Line: +49 89 99699 500 Email Address: info@nec-displays.com WEB Address: http://www.nec-display-solutions.com In North America Company Name: NEC Display Solutions of America, Inc. Address: 3250 Lacey Rd, Ste 500 Downers Grove, IL 60515 U.S.A. Telephone: +1 800-632-4662 Email: techsupport@necdisplay.com...
  • Page 7 Important Information Label Information Label A Label A: Lamp Warning Label...
  • Page 8 Important Information Label C Label B Label D Label E • Label B Laser Explanatory Label • Label C...
  • Page 9 Important Information • Label D • Label E...
  • Page 10 Important Information Radiation Range of Emitted Light by the Projector (HD: Hazard Distance) • The below table describes the radiation range of emitted light by the projector that is classified as Risk Group 3 (RG3) of IEC62471-5 First edition 2015. • The below table describes the radiation range of emitted light by the projector that is classified as Risk Group 3 (RG3) of IEC62471:2006.(for USA).
  • Page 11 Important Information CAUTION Please heed all precaution for safety. To install the projector • For planning the layout of the projector, make sure to take safety measures instructed on the installation manual. • In order to refuse danger, install either a wall outlet within easy reach for pulling out the power plug in emergency or a device as a breaker to shut down the power supply to the projector.

  • Page 12: Table Of Contents

    Table of Contents Important Information ..............2 1. What’s in the Box? and the Names of the Projector Parts ..14 1-1. Features ..........................14 1-2. What’s in the Box? ......................16 1-3. Names of the Projector Parts ....................17 2. Installation and Connection ............23 2-1.
  • Page 13 6. Appendix .................. 60 6-1. Troubleshooting .........................60 6-2. Indicator display list ......................61 6-3. Operation using an HTTP browser ..................64 6-4. Writing of the log file (Save Information) ................66 6-5. Outline Drawing ........................69 6-6. Specifications ........................70 6-7. Pin Assignment and Functions of Terminal ..............71 6-8.

  • Page 14: What's In The Box? And The Names Of The Projector Parts

    ® Complies with the strict projection standards defined by the Digital Cinema Initiatives (DCI) industry group in the United States using leading imaging technology of NEC. It also supports 3D projection and high frame rates (HFR). • Employs a long life laser light source The projector employs a newly developed laser light source offering excellent reliability and redundancy. Since the laser light source has a long life (approx.
  • Page 15 1. What’s in the Box? and the Names of the Projector Parts (3) Frequently used titles can be registered in preset buttons The projector has been equipped with 8 preset buttons that make it easy to select registered title (input signal). To this projector, 100 titles at most can be registered (input signal registration).

  • Page 16: What's In The Box

    1. What’s in the Box? and the Names of the Projector Parts 1-2. What’s in the Box? Check the content of the accessories. 1-2-1. Projector  Projector  Service door key x 2  Keys for administrator x 2  Plate Inlet φ35 ...

  • Page 17: Names Of The Projector Parts

    1. What’s in the Box? and the Names of the Projector Parts 1-3. Names of the Projector Parts 1-3-1. Front of the projector 1. LIGHT status indicator Displays the status of the light source. The indicators turn on when the light source is on and turn off when the light source is off (See page 63).
  • Page 18 1. What’s in the Box? and the Names of the Projector Parts 9. Remote interlock connector (inside the main unit's side panel) This port is for safely using the laser in this device. It is used to externally control the laser illumination in the projector. Consult with your dealer/distributor about using this. 10.
  • Page 19 1. What’s in the Box? and the Names of the Projector Parts 1-3-3. Bottom of the projector 1. Handle (4 locations) Handles for moving the projector. 2. Level adjusters (in 4 positions) In the ordinary installation, you can adjust the projector inclination at 4 positions. 3.
  • Page 20 1. What’s in the Box? and the Names of the Projector Parts 1-3-4. Connection terminals 1. Service terminal (REMOTE) (Stereo mini) This terminal is used for service purpose only. 2. Ethernet port (LAN) (RJ-45) The port for interfacing with an image signal server or controlling the projector from a PC via a network. Connect the projector and the PC with a commercially available Ethernet cable (10/100/1000Base-T).
  • Page 21 1. What’s in the Box? and the Names of the Projector Parts 1-3-5. Control panel 1. LCD screen The LCD screen displays menus and setting values for the projector operations. 2. /// (UP/DOWN/LEFT/RIGHT) buttons Press these buttons to select a menu item while a menu is displayed. 3. MENU button Press this button to display the menu for various settings and adjustments.
  • Page 22 1. What’s in the Box? and the Names of the Projector Parts 12. Play/pause button (planned to be supported in a future update) This button is operable when the media block is installed in the projector. Press this button to play or pause the image contents. 13.

  • Page 23: Installation And Connection

    Installation and Connection 2-1. Steps for setting up and connecting Use the following steps for setting up your projector: • Step 1 Setup the screen and projector. (Contact your dealer to carry out the setup.) • Step 2 Connect the power cable to the projector. (See page 24) • Step 3 Connect cables to the image input terminals.

  • Page 24: Connecting The Power Cable

    2. Installation and Connection 2-2. Connecting the Power Cable Consult your dealer for installing the power cable to the projector. If AC power is supplied to the projector and light with one power cable (C1 connection), it is not necessary to connect the cable to the projector power supply.
  • Page 25 2. Installation and Connection Connect the AC power supply cable. Connect the AC power supply cable to the projector. AC input Connect the AC power supply cable to the projector Connect the power plug to the electrical outlet. This completes the connection of the AC power supply cable.
  • Page 26 2. Installation and Connection Attaching the power cable stopper To prevent the power cable from accidently removing from the AC IN of the projector, attach the supplied power cable stopper to clamp the power cable. CAUTION • To prevent the power cable from coming loose, make sure that all the prongs of the power cable are fully inserted into the AC IN terminal of the projector before using the power cable stopper to fix the power cable.
  • Page 27 2. Installation and Connection Slide the clamper unit to the base of the power cord. The position of the clamper unit can be adjusted by pulling the tab in the direction of the arrow. After adjusting the position of the clamper unit, release the tab to fix the clamper unit in place. knob Pull the band to fasten the power cord.
  • Page 28 2. Installation and Connection Removing the power cable from the power cable stopper Pull the knob of each clamper to remove the two bands. knob knob band CAUTION The projector may become hot temporarily when the power is turned off or if the AC power is disconnected while the projector is projecting.

  • Page 29: Connecting The Image Input Terminals

    2. Installation and Connection 2-3. Connecting the image input terminals The video input ports that can be used with the IMB are as follows. Refer to the instruction manual of the IMB for details on con- necting the video input ports with external equipment. NP-90MS02 HDMI input port 3G SDI input port...

  • Page 30: Projection Of Images (Basic Operation)

    Projection of Images (Basic Operation) 3-1. Steps of projecting images • Step 1 Turn on the power to the projector. (See page 31) • Step 2 Select the title of input signal. (See page 33) • Step 3 Adjust the position and size of the projected screen. (See page 34) • Step 4 Turn off the power to the projector.

  • Page 31: Turning Your Projector On

    3. Projection of Images (Basic Operation) 3-2. Turning your projector on Preparation: • Connect the power cable to the projector (see page 24). • Supply AC power to the projector. • Turn off the main power switch to the projector when supplying or cutting AC power to the projector. NOTE Supplying or shutting down the AC power while the main power switch is on will damage the projector. • Turning on and off the projector involves a two-step operation;...
  • Page 32 3. Projection of Images (Basic Operation) If KEY LOCK is on, press the KEY LOCK button for one second or longer. KEY LOCK becomes off. The KEY LOCK button indicator turns off and buttons on the control panel become operable. (See page 38) Press the POWER button on the control panel of your projector three seconds or longer.

  • Page 33: Selecting The Title Of Input Signal

    3. Projection of Images (Basic Operation) 3-3. Selecting the title of input signal This projector allows you to select pre-registered title (input signal) using the preset buttons on the control panel (up to 16 titles). Request your dealer/distributor for details on registering and changing titles. This section explains the steps for selecting registered titles.

  • Page 34: Adjusting The Position And The Size Of Projected Screen

    3. Projection of Images (Basic Operation) 3-4. Adjusting the position and the size of projected screen 3-4-1. Displaying the test pattern Press the MENU button, or select a test pattern from preset buttons (button <1> to <8>). If you register the test patterns to the preset buttons (<1> to <8> buttons), select the test pattern according to “3-3. Selecting the title of input signal (See page 33)”.
  • Page 35 3. Projection of Images (Basic Operation) Display on the LCD the name of the test pattern to be projected, then press the ENTER button. The test pattern is displayed. To cancel the test pattern display, select the title of the signal to project or select the “OFF” test pattern. 3-4-2.
  • Page 36 3. Projection of Images (Basic Operation) 3-4-3. Adjustment of the size (zoom) and focus of the projected screen Press the MENU button. Press the LEFT/RIGHT button to display “Configuration” on the LCD screen. Press the DOWN button. Press the LEFT/RIGHT button to display “Lens Control” on the LCD screen. Press the DOWN button.
  • Page 37 3. Projection of Images (Basic Operation) 3-4-4. Adjusting the brightness of the projected screen (Light output) If the internal temperature within the projector rises due to the temperature in the room being high, the light output NOTE may be automatically reduced. This is called “Thermal Protection Mode (Down Light Power)”. When the projector is in the Thermal Protection Mode, the picture brightness decreases slightly.

  • Page 38: Preventing Misoperations

    3. Projection of Images (Basic Operation) 3-5. Preventing misoperations Buttons on the control panel can be locked (KEY LOCK) to prevent misoperations. Buttons on the control panel do not function while KEY LOCK is on. KEY LOCK must be off to operate these buttons. • KEY LOCK is automatically turned on in the following cases.

  • Page 39: Turning On/Off The Light With The Projector Turned On

    3. Projection of Images (Basic Operation) 3-6. Turning on/off the light with the projector turned on 3-6-1. Turning off the light • Press the LIGHT ON/OFF button on the control panel for three seconds or longer. 3-6-2. Turning on the light • Press the LIGHT ON/OFF button on the control panel for three seconds or longer.

  • Page 40: Turning Your Projector Off

    3. Projection of Images (Basic Operation) 3-7. Turning your projector off Press the POWER button on the projector control panel for three seconds or longer. The light is turned off, the POWER button indicator blinks green, and the STATUS indicator blinks orange (cooling state). The fan will continue to rotate while cooling, and the amount of time remaining for cooling is displayed on the LCD screen.
  • Page 41 3. Projection of Images (Basic Operation) Shut off the AC power supply to the main unit from the circuit breaker, etc. In the following instances, do not turn off the main power switch or disconnect the AC power. Doing so can damage NOTE the projector.

  • Page 42: Using Menus

    Using Menus 4-1. Basic operation with adjustment menus To adjust the projector, display the menu on the LCD screen of the projector control panel. 4-1-1. Screen display The menu display screen is composed of a menu display field (the upper two lines) and a setting item display field (the bottom two lines).
  • Page 43 4. Using Menus When not displaying menus, the following screen is normally displayed. When in standby When the projector is in a standby state (the main power switch in on), the following is displayed. When power is turned on When the power is turned on, the following is displayed. ←...
  • Page 44 4. Using Menus 4-1-2. Operating menus Preparation: Turn your projector on. (See page 31) Press the MENU button on the control panel of your projector. The menu is displayed in the LCD screen. Press the LEFT/RIGHT buttons to display “Information.” At each press of the LEFT/RIGHT buttons, the display will cycle as “Title Select”...
  • Page 45 4. Using Menus Press the DOWN button. The submenu “BIOS” another rank lower than “Model” is displayed. Press the LEFT/RIGHT button to select the submenu “Release Package.” At each press of the LEFT/RIGHT button, the display will cycle as “Model” ←→ “Serial No.” ←→ “Release Package” ←→ “Kernel”...
  • Page 46 4. Using Menus 4-1-3. How to enter alphanumeric characters Alphanumeric characters are entered for items, such as the log file of the specified period is written to USB memory. (See page 66) Characters can be entered by pressing numeric buttons on the control panel on this projector. Move right and left Delete entered characters Enter characters...

  • Page 47: Table Of Adjustment Menus

    4. Using Menus 4-2. Table of adjustment menus Menus in parentheses are menus for our service personnel. Normally, these menus cannot be used. Reference Main menu Submenu Description page Title Select “Title Memory Name” Selects the title of the signal to be projected. TEST Pattern Selects the test pattern to be projected.
  • Page 48 4. Using Menus Reference Main menu Submenu Description page Information Light Light Output Displays the light module's brightness (output) setting value. Model Displays the light module's model name. Displays the serial number of the light module. Lens Type This function cannot be used. Preset Button Preset Button 1–16 Displays the titles which are assigned to the preset buttons (<1>...

  • Page 49: Title Select

    4. Using Menus 4-3. Title Select 4-3-1. Title select (Title Memory) Selects the title of the signal to be projected. You can register up to 100 titles. You can also assign registered titles to the preset buttons (<1> to <8> buttons) on the projector’s control panel and call them up directly using those buttons.

  • Page 50: Configuration

    4. Using Menus 4-4. Configuration Please request your dealer/distributor to perform the settings. 4-4-1. Light Setup Adjust Adjusts the light output (brightness). ← Displays the current output power value (%) when the light rated output is 100%. 4-4-2. Lens Control Adjust the position, size, and focus of the projected screen.
  • Page 51 4. Using Menus 4-4-4. Installation Lens Type This function cannot be used. Lens Calibrate Performs calibration on lenses that support the lens memory function. Once you have attached a lens that supports the lens memory function, always execute calibration. This menu item is available only when the projector power is turned on and you are logged into the projector with Advanced User or higher privileges.

  • Page 52: Title Setup

    4. Using Menus 4-5. Title Setup Sets the title to be assigned to the preset buttons (<1> to <8> buttons) (up to 16 titles). Request your dealer/distributor to perform the settings. 4-6. Information Displays the hours of light use, the version information and error codes. 4-6-1.
  • Page 53 4. Using Menus 4-6-4. Usage Displays information related to the projector usage, such as the usage time of the projector, light, air filters, and fan, and information about the light replacement cycle. ← Selects the item to display. ← Displays information about the selected item. Displays the usage time of the projector.
  • Page 54 4. Using Menus 4-6-6. Version Displays version information about the projector, optional boards, and IMB. System Displays the version information of the projector. ← Selects the item to display. ← Displays the version information. ・ Model ・ Slave Firmware ・ Serial No. ・...
  • Page 55 4. Using Menus 4-6-8. Setup Date Displays the date when the projector was set up (starting date of the warranty period). ← Displays the date when the projector was set up (starting date of the warranty period). 4-6-9. Option Status Displays the link status of the device mounted in slot on the projector.

  • Page 56: Maintenance Of Your Projector

    Maintenance of Your Projector Please request your dealer to perform cleaning of the projector inside. NOTE 5-1. Cleaning the Cabinet WARNING Please do not use a spray containing flammable gas to remove dust attached to the cabinet, etc. Doing so may result in fires. Be sure to always check that the AC power supply of the projector is disconnected before carrying out maintenance of the projector.

  • Page 57: Cleaning The Lens

    5. Maintenance of Your Projector 5-2. Cleaning the Lens Clean the lens the same way as with camera lens (using a commercially available camera blower or cleaning paper for glasses). Take care not to damage the lens when cleaning. WARNING • Do not look into the light module while the projector is ON.
  • Page 58 5. Maintenance of Your Projector To remove the front air filter, pull the filter cover in the direction of the arrow. To install, insert the catches in the filter cover into the grooves in the lens cover, close the cover, then push it in. Groove Catches Grips...
  • Page 59 5. Maintenance of Your Projector Attach the metal filter. (1) Insert the three catches on the metal filter into the grooves in the panel. (2) Bend the metal filter a little and insert the three pro- jecting parts on the opposite side into the grooves in Groove the panel, one by one.

  • Page 60: Appendix

    Appendix 6-1. Troubleshooting Before asking for repair, please check your connection, settings and operation once again. If the trouble cannot be corrected, please contact your dealer/distributor for instructions or repair. 6-1-1. Problems and where to check Problem Check these items The projector cannot be turned on.

  • Page 61: Indicator Display List

    6. Appendix 6-2. Indicator display list See the descriptions below when the buttons on the control panel or the STATUS indicator on the rear of the projector is lit or blink- ing. The projector also has a warning function that uses a buzzer. KEY LOCK button POWER button DOUSER button...
  • Page 62 6. Appendix 6-2-3. POWER button Indicator condition Projector condition Note The projector power supply is off. Blinking light Orange While the projector software is starting Wait for a moment. Green Preparing to turn power on/cooling fan rotating Wait for a moment. (cycles of 1) (Note (State from turning the power off to entering standby mode).
  • Page 63 6. Appendix 6-2-6. STATUS indicator LIGHT status indicator SYSTEM status indicator SYSTEM status indicator Indicator condition Projector condition Note Main power is off. Blinking light Green The projector is getting ready to turn on. Wait for a moment. The douser is closed. The light is off.

  • Page 64: Operation Using An Http Browser

    - the projector's host name is registered on the domain name server - the projector's IP address and host name have been added to the “HOSTS” file on the computer (Example 1) When the projector's host name is set to “pj.nec.co.jp” To access the HTTP server function, enter “http://pj.nec.co.jp/index.html” in the address or URL input field. (Example 2) When the projector's IP address is “192.168.10.10” To access the HTTP server function, enter “http://192.168.10.10/index.html” in the address or URL input field.
  • Page 65 6. Appendix 6-3-4. Structure of the HTTP server Power Controls the power to your projector. • On: Turns the power on. • Off: Turns the power off. Light Turn the light on/off. • On: Turns the light on. • Off: Turns the light off. Title List Displays titles set in the projector (such as input port, screen type, and title).

  • Page 66: Writing Of The Log File (Save Information)

    6. Appendix 6-4. Writing of the log file (Save Information) Log files saved on the main unit can be written to USB memory connected to the USB port of the main unit. To perform the writing of the log file, use the following procedure. Connect the USB memory to the USB port of the main unit.
  • Page 67 6. Appendix When “Manual” is selected, specify the log file writing period. For how to enter numerals, refer to “4-1-3. How to enter alphanumeric characters” (See page 48). If you press the ENTER button, the display advances to the following screen. ←...
  • Page 68 6. Appendix 6-4-1. Names of log files Written log files are saved with the following file names. (Model name)_(Serial Number)_YYMMDDHHmm.txt (Model name) This shows the model of projector. (Serial Number) This shows the serial number of projector. YYMMDDHHmm Shows the date/time when written. YY: Year (lower 2 digits) MM: Month (2 digits) DD: Date (2 digits)

  • Page 69: Outline Drawing

    6. Appendix 6-5. Outline Drawing 6-5-1. Projector Lens center Lens center Units: mm...

  • Page 70: Specifications

    6. Appendix 6-6. Specifications 6-6-1. Projector Model name DLP Cinema Projector Head : NP-02HD ® Light Module : NP-24LU01/NP-20LU01/NP-18LU01 Projection method 3 chip DLP Cinema method ® 0.98-inch DC2K chip Panel resolution 2048 x 1080 Light type Laser Diode Screen sizes Max.

  • Page 71: Pin Assignment And Functions Of Terminal

    6. Appendix 6-7. Pin Assignment and Functions of Terminal 6-7-1. PC CONTROL connector (RS-232) (D-sub 9 pin) This is an RS-232C interface for controlling the projector from a PC. The projector operates as a DCE (Data Communication Equipment), so use a straight cable when connecting to a PC. Pin No.
  • Page 72 6. Appendix 6-7-2. External control connector (GP I/O) (D-sub 37 pin) It is possible to control the projector with an external device and to control the external device from the projector using an external control connector (GPIO: General Purpose I/O Ports). Each pin is electrically separated from the projector internal circuits by a photo-coupler.
  • Page 73 6. Appendix Input Connector GP I/O Connector Inside Projector Resist = 390 Ω Ext_GPIN_P Pin No.: Voltage applied across the pins of Ext_GPIN_P and Ext_GPIN_N should be in the range from 3.3 Vdc to 10 Vdc. Recommended Operating Current: Absolute Maximum Rating: 23mA Ext_GPIN_N Pin No.: 20 21 23 23 24 25 26 27...
  • Page 74 6. Appendix • Timing chart of GPIO control Example of Select Preset Button Off at least 500 ms at least 500 ms approx. 200 ms 8-27 5-24/6-25/7-26 time Execute Select Preset Button Example for turning the image douser (Douser) on Off at least 500 ms at least 500 ms approx.
  • Page 75 6. Appendix Example of Light source On Off at least 500 ms at least 500 ms approx. 200 ms 5-24/6-25 7-26/8-27 time Execute Light source On Example for turning the power off Off at least 500 ms at least 500 ms approx.
  • Page 76 6. Appendix Output Connector GP I/O Connector Inside Projector Ext_GPOUT_P Ext_PROJ_GOOD_P Pin No.: 9 10 11 12 13 14 15 16 Absolute Maximum Rating: 50 mA Ext_GPOUT_N Ext_PROJ_GOOD_N Pin No.: 28 29 30 31 32 33 34 35 Photo-coupler • Using GPIO Control You can use GPIO control for the projector’s health check and error check.
  • Page 77 6. Appendix 6-7-3. 3D connector (D-sub 15 pin) This is used to connect a 3D image system to the projector. Pin view of a female connector Pin No. Signal Name Function +12V Supplies power (+12V) to the 3D image system GNDC Ground GNDC...

  • Page 78: Related Products List

    6. Appendix 6-8. Related products list Product name Model name Lens NC-60LS12Z Zoom lens 1.20〜1.81 NC-60LS14Z Zoom lens 1.40〜2.05 NC-60LS16Z Zoom lens 1.59〜2.53 NC-60LS19Z Zoom lens 1.90〜3.25 NC-60LS24Z Zoom lens 2.40〜3.90 NC-60LS39Z Zoom lens 3.90〜6.52 Integrated Media Server NP-90MS02-4K Projector Head NP-02HD Light Module Max.
  • Page 79 6. Appendix...
  • Page 80 © NEC Display Solutions, Ltd. 2019 Ver.1 05/19...
