Intel Desktop Board D845GVSR Technical Product Specification
4.4.4.1

Primary/Secondary IDE Master/Slave Submenus

To access these submenus, select Advanced on the menu bar, then IDE Configuration, and then the
master or slave to be configured.
Maintenance
There are four IDE submenus: primary master, primary slave, secondary master, and secondary
slave. Table 55 shows the format of the IDE submenus. For brevity, only one example is shown.
Table 55. Primary/Secondary IDE Master/Slave Submenus
Feature
Drive Installed
Type
Maximum Capacity
LBA/Large Mode
86
Main
Advanced
PCI Configuration
Boot Configuration
Peripheral Configuration
IDE Configuration
Primary IDE Master
Primary IDE Slave
Secondary IDE Master
Secondary IDE Slave
Diskette Configuration
Event Log Configuration
Video Configuration
USB Configuration
Chipset Configuration
Options
No options
• Auto (default)
• User
No options
• Disabled
• Auto (default)
Security Power
Description
Displays the type of drive installed.
Specifies the IDE configuration mode for IDE devices.
User allows capabilities to be changed.
Auto fills-in capabilities from ATA/ATAPI device.
Displays the capacity of the drive.
Selects the translation mode for the IDE hard disk.
(This item is read-only unless Type is set to User.)
Boot Exit
continued
