Instructions for Using
B16350-R0-Ei2100 SERIES-U&C.qxd
18/9/08
3:46 PM
Page 1
230V~
MULTI-SENSOR FIRE ALARM
with Rechargeable Lithium Cell Back-up
Model: Ei2110
Contains vital information on unit operation and installation. Read and retain carefully.
If you are just installing this unit this leaflet MUST be given to the householder.
INSTALLER INSTRUCTIONS
Advertisement
Table of Contents
Related Manuals for Ei Electronics Ei2110
Summary of Contents for Ei Electronics Ei2110
- Page 1 230V~ MULTI-SENSOR FIRE ALARM with Rechargeable Lithium Cell Back-up Model: Ei2110 Contains vital information on unit operation and installation. Read and retain carefully. If you are just installing this unit this leaflet MUST be given to the householder. INSTALLER INSTRUCTIONS...
-
Page 2: Table Of Contents
B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 CONTENTS 1. QUICK GUIDE 1.1 INSTALLATION GUIDE 1.2 ALARM REMOVAL 2. MULTI-SENSOR FIRE ALARM FEATURES 3. HOW MANY ALARMS TO INSTALL 3.1 CATEGORIES OF SYSTEM 3.2 SELECTING ALARM TYPE 3.3 GRADE D, E & F SYSTEMS 4. POSITIONING ALARMS 4.1 LOCATIONS TO AVOID 5. -
Page 3: Quick Guide
B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 3:46 PM Page 3 INSTALL IN THE CENTRE OF CEILING AT LEAST 300mm FROM LIGHT FITTINGS & WALLS INTERCONNECT ALL ALARMS ENSURE MAINS POWER IS CORRECTLY CONNECTED TO L & N TERMINALS ON ALL INTERCONNECTED ALARMS - OTHERWISE UNITS WILL BE DAMAGED DO NOT FIT ACTUAL ALARMS UNTIL ALL BUILDING WORK IS COMPLETED TO AVOID CONTAMINATION. -
Page 4: Installation Guide
B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 3:46 PM Page 4 1.1 Installation Guide DECIDE ON CORRECT POSITION GREEN MAINS LIGHT PRESS AND HOLD THE TEST BUTTON ON THE ALARM. CHECK AS THE TAMPER-PROOF CATCH ENGAGES. SWITCH ON MAINS THE ALARM AND ANY INTERCONNECTED UNITS SOUND. -
Page 5: Alarm Removal
B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 3:46 PM Page 5 1.2 Alarm Removal LOCATE REMOVAL SLOT INSERT SCREWDRIVER LOCATE THE ARROW ON THE FRONT FACE OF THE ALARM. INSERT A FLAT-BLADED SCREWDRIVER HORIZONTALLY THE SLOT IS LOCATED DIRECTLY ABOVE THE ARROW. ABOUT 10mm INTO THE CENTRE OF THE REMOVAL SLOT REMOVE ALARM SLIDE ALARM OFF BASE WITH THE SCREWDRIVER STILL INSERTED, PUSH THE LOWER... -
Page 6: Multi-Sensor Fire Alarm Features
Page 6 2. MULTI-SENSOR FIRE ALARM FEATURES The state of the art EI2110 Multi-Sensor Fire Alarm, with its Heat enhanced Optical Smoke Sensor, has a significantly improved performance as described below. 1. Faster Response to a wider range of fires. -
Page 7: How Many Alarms To Install
B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 3:46 PM Page 7 4. Replace Alarm Indicator. If the optical sensor chamber becomes very heavily contaminated, the amber fault light will flash once every 40 seconds to inform the user. Action can then be taken to replace the unit, long before the contamination causes nuisance alarms. - Page 8 The Multi-Sensor Alarm can be installed for superior performance anywhere the regulations specify an Optical Smoke Alarm or an Ionisation Smoke Alarm. (The Ei2110 Multi-Sensor Fire Alarm can also be used and interconnected with an Ei166RC Optical Smoke Alarm or an Ei161RC Ionisation Smoke Alarm if necessary).
-
Page 9: Categories Of System
B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 3:46 PM Page 9 It is therefore recommended that a Fire Risk Assessment is undertaken. The Risk Assessment would be based on a combination of probabilities: - fire occurring - injury or death to occupant - system operating correctly with a fire - early detection and warning to occupants in the event of a fire. - Page 10 B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 MINIMUM PROTECTION for existing dwellings Minimum Protection LD3: Alarms in all hallways, stairways and circulation areas that form part of the escape routes from the dwelling. Multi-Sensor Fire Alarms located: on each storey every 7.5 m of hallways and escape routes within 3m of all bedroom doors (apart from toilets &...
- Page 11 B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 ADDITIONAL PROTECTION for new or materially altered dwellings or existing dwellings with poor structural fire precautions Additional Protection LD2: As LD3, but in addition alarms in all rooms or areas that present a high fire risk to occupants. Multi-Sensor Fire Alarms located: on each storey every 7.5 m of hallways and escape routes...
- Page 12 B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 OPTIMUM PROTECTION for dwellings where occupants may be at high risk (e.g. elderly) Optimum Protection LD1: As LD2, but in addition alarms should be located in all rooms and other areas of the dwelling. (apart from toilets or bathrooms) Multi-Sensor Fire Alarms located: on each storey every 7.5 m of hallways and escape routes...
-
Page 13: Selecting Alarm Type
B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 3.2 Selecting Alarm Type Multi-Sensor Fire Alarm & Heat Alarm Selection Locations & Performance Locations Hall, Corridors, Escape Routes Kitchens Living Rooms Bedrooms Shower / Bathroom Fire Response Slow Smouldering Fires (polyurethane foam, ignited bedding etc.) Fast Flaming Fires (flaming wood/plastic, oil, solvents, chip pans etc.) Temperature >58 Nuisance Alarm Immunity y... -
Page 14: Grade D, E & F Systems
B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 3:46 PM Page 14 1 Some Fire authorities (concerned with the slow response of Heat Alarms) advise that Smoke Alarms (or Multi-Sensor Alarms) should be fitted. This is acceptable according to BS 5839-6 provided there are clearly not going to be problems with nuisance alarms. Fit Heat Alarms only if nuisance alarms are very likely and it is acceptable that a warning will only be given by the Heat Alarm when there is a very significant flaming fire in the room. -
Page 15: Positioning Alarms
B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 - Individual dwellings units of two or more rooms in HMOs Check that a Grade D system is adequate for the dwelling into which the system is being installed. 4. POSITIONING ALARMS The locations must comply with applicable building regulations. Hot smoke rises and spreads out, so a central ceiling position is the preferred location. -
Page 16: Locations To Avoid
B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 Note: Ceiling mounting is recommended - do not wall mount alarms. Sloping Ceiling In areas with sloping or peaked ceilings install the alarm 900mm from the highest point measured horizontally (see Figure 2). This is because “dead air” at the apex may prevent smoke from reaching the unit. -
Page 17: Installation
B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 • Next to or directly above heaters or air conditioning vents, windows, wall vents etc. that can change the direction of airflow and cause rapid temperature fluctuations. • In very high or awkward areas (e.g. over stairwells) where it may be difficult to reach the unit (for testing, hushing etc.). - Page 18 B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 3:46 PM Page 18 fully cleaned. The wiring can be installed when appropriate. (Excessive dust and debris from building work can contaminate the optical sensor chamber or heat sensor and cause problems. It will also invalidate the guarantee). If it must be installed, first cover it completely, particularly around the edges, with a dust cover (eg.
-
Page 19: Mounting & Wiring Alarms
B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 3:46 PM Page 19 5.1 Mounting & Wiring Alarms 1. Select a location complying with the advice in previous sections (see pages 8-18). 2. Disconnect the AC mains supply from the circuit that is going to be used. 3. - Page 20 B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 The wiring must be connected to the terminal block on the mounting plate as follows: L: Live - connect to the house wires coloured brown or marked L. N: Neutral - connect to the house wires coloured blue or marked N. IC: Interconnect - see page 23 &...
- Page 21 B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 3:46 PM Page 21 Figure 4 4. If the mains wires are recessed, bring the wires through the rear hole in the mounting plate as shown in Figure 4. If the mains wires are being brought along the surface: (a) position the mounting plate so the cable trunking is as shown in Figure 4.
- Page 22 B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 3:46 PM Page 22 Figure 5 There are two other positions which are also suitable for the surface wiring to enter (and exit) the alarm, one next to the removable section and another directly opposite. 5. Carefully align the mounting plate and screw into place. Connect the wires to the terminal block.
-
Page 23: Interconnecting Alarms
ALARM” section on page 8 of the USER INSTRUCTIONS. 5.2 Interconnecting Alarms Note: A maximum of twelve Ei2110 Multi-Sensor Fire Alarms and/or Ei164RC Heat Alarms may be interconnected along with an Ei128R/Ei128RBU relay (see “ACCESSORIES” section on page 25). (Note the Multi-Sensor Fire Alarm Ei2110 can also be interconnected to Ei141/144/146/161RC/166RC Smoke/Heat Alarms if required). - Page 24 B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 and be readily accessible to all occupants so that the source of an alarm can be quickly identified. • All alarms must be cleaned and maintained regularly. • A qualified person must be on call to quickly remove any nuisance units (i.e. units with red light flashing rapidly) which are causing all the other alarms to sound.
-
Page 25: Accessories
B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 3:46 PM Page 25 Everybody may not be aware that they are being tested or that it is a nuisance alarm caused by cooking etc. Figure 6 Ensure the alarms operate correctly - see “TESTING & MAINTAINING YOUR ALARM”... - Page 26 This allows quick and easy installation as well as easy extension at a later date. The Ei2110 Multi-Sensor Fire Alarm (and Ei160RC Series Alarms) simply slide on to the Ei168RC RadioLINK Base. Each alarm in the system would need to be mounted on a RadioLINK Base.
- Page 27 B16350-R0-Ei2100 SERIES-U&C.qxd 18/9/08 3:46 PM Page 27...
- Page 28 18/9/08 3:46 PM Page 28 Aico Ltd. Mile End Business Park, Maesbury Rd, Oswestry, Shropshire SY10 8NN, U.K. Tel: 0870 758 4000 www.aico.co.uk Ei Electronics. Shannon, Co Clare, Ireland. Tel: 061 471277 www.eielectronics.com P/N B16350 Rev0 © Ei Electronics 2008...
