- Page 1 16-Port 10/100Mbps Smart Switch (VLAN, Trunking & Fiber Option) ES-3116RE+ User’s Manual...
-
Page 2: Fcc Class B Certification
FCC Class B Certification This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: 1.This device may not cause harmful interference, and 2.This device must accept any interference received, including interference that may cause undesired operation. Warning! This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 3 It’s rackmount design that can be mounted on the industrial standard 19 inches rack in the enterprise wiring center. This switch supports both full & half duplex on all ports which are able to provide 200Mbps of bandwidth to the connected devices, with auto-negotiation providing smooth migration from Ethernet to Fast Ethernet.
-
Page 4: Features And Specifications
Comply with IEEE 802.3 10BaseT and IEEE 802.3u 100BaseTX Standards. Provide 16 UTP ports with 10/100Mbps Auto-Negotiation. Provide one uplink port which can connect to another hub/switch using a normal UTP cable One 100Mbps Fiber-SC/ST module option (Support Full/Half Duplex) Support IEEE 802.3x compliant full-duplex flow control, half-duplex flow control Full wire speed on every port. - Page 5 Trunking : 2 groups N-Way Auto-Negotiation : on all ports Full-Duplex / Half-Duplex : on all ports Switch LED : Power Port LEDs : Link/Activity, 100M, Collision/Full-Duplex Power : 100~240V AC, full range internal power Emission : FCC Class B , CE Mark , C-tick...
-
Page 6: Package Contents
3. Package Contents One Fast Ethernet Switch One Power Cord One User’s manual Rackmount accessories... -
Page 7: Physical Description
LED/Button Panel Normal : 100Mbps Setup : Port Power LED Normal : Link / Activity Setup : Status RJ-45 Connectors Power Connector Normal : Full Duplex / Collision Setup : Group Setup Functions AC 100-240V POWER Power Switch Setup Buttons... - Page 8 (2) LED System FUL/COL ( Fu ll D up lex/ C o l lis io n) LNK/ACT Normal (Link /Ac tivity) Port (100Mbps) Setup Status Setup Function FULL/HALF Power 100M Group Port Status VLAN TRUNK 10/100M SAVE Status Description Power is supplied No Power Collision detected in this segment...
-
Page 9: Installation
LNK/ACT LED should be lit. An uplink port is located right next to the 16th port of this switch. The uplink port is a shared port with the 16th port but provides the MDI connecting to another hub/switch using regular straight-through cables. -
Page 10: Advance Configuration
Each VLAN you configure behaves as an isolated broadcast domain just as if it were a separate switch. There is no communication between ports on the separate VLANs unless the VLANs are connected by an external router. - Page 11 Step 4. Press the Set button to assign the selected port to the VLAN group. After you press Set button ,the selected port LED will switch between on and off. If the selected port LED is on, the selected port is added to the VLAN group.
-
Page 12: Port Trunking Configuration
1.2Gbps Trunk 800Mbps Trunk Port trunking Configuration This switch provides two Port trunking groups listed in following table. Group Mode The following instructions describe how to configure port trunking. Note : 1.Trunking port work in 100M full-duplex. 2.The trunking ports must be configured to the same VLAN group. - Page 13 After you press Set button ,the selected port’s Full (Group) LED and Half (Status) LED will switch between on and off. If the selected port Full LED is on and Half LED is off, the select port is force to Full Duplex. If the...
- Page 14 Half Duplex. If the selected port Full LED is on and Half LED is on, the select port is set to auto negotiation. Step 4. Press the Function button until the SAVE LED is on. Step 5. Press the Set button to save the setting. Step 6.
-
Page 15: Troubleshooting
1. Power LED is not lit Check if the power cord is properly connected to the power outlet and the hub. Make sure the power switch on the hub is turned ON. 2. 100M Link is not lit when connect to 100Mbps device Check the power switch of the network device attached to the switch;...
