- Page 1 ES-3305P V3 / ES-3308P V3 Quick Installation Guide 03-2015 / v1.1...
-
Page 2: Product Introduction
PRODUCT INTRODUCTION Model: ES-3305P V3: 5-Port Fast Ethernet Desktop Switch ES-3308P V3: 8-Port Fast Ethernet Desktop Switch Package Contents Before you start using this switch, please check if there is anything missing in the package, and contact your dealer to claim the missing item(s): ... - Page 3 8-Port Fast Ethernet Desktop Switch: PWR LED LNK/ACT LEDs 1 - 8 LED Status: LED Name Light Description Status Switch is on Switch is off Corresponding port is connected LNK/ACT Corresponding port is not connected Flashing Corresponding port is active and transferring /receiving data.
- Page 4 Operating Environment This switch must be installed and operated within the limits of the specified operating temperature 0 - 40°C (32 - 104°F) and humidity (10 - 90% non-condensing). - Do not place objects on top of the unit. - Do not obstruct any vents at the sides of the unit. - Do not position the unit to any heating source such as a heater, radiator or in direct exposure to sun.
-
Page 5: Troubleshooting
Connecting the power Connect the power adapter to the power connector of the unit; the green power LED on the front panel should be lit. TROUBLESHOOTING 1. Power LED is not lit Check if the power cord is properly connected to the external power adapter and the power source. - Page 6 COPYRIGHT Copyright Edimax Technology Co., Ltd. all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission from Edimax Technology Co.,...
-
Page 7: Federal Communication Commission Interference Statement
Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 8 EU Declaration of Conformity English: This equipment is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC, 2009/125/EC, 2006/95/EC, 2011/65/EC. French: Cet équipement est conforme aux exigences essentielles et autres dispositions de la directive 1999/5/CE, 2009/125/CE, 2006/95/CE, 2011/65/CE. Czechian: Toto zařízení...
-
Page 9: Declaration Of Conformity
Declaration of Conformity We, Edimax Technology Co., Ltd., declare under our sole responsibility, that the equipment described below complies with the requirements of the European R&TTE directive. Equipment : 5 / 8-Port Fast Ethernet Desktop Switch Model No. : ES-3305P V3 / ES-3308P V3...
