Intel Desktop Board D410PT Product Guide
Table 2. Intel Desktop Board D410PT Components
Label Description
A Back panel connectors
B Serial header (COM1)
C Serial port (COM 2)
D Chassis fan header
E Main power connector
F Standby power indicator
G Processor
H Channel A DIMM 0
I Channel A DIMM 1
J SATA 1
K SATA 0
L Front panel header
M Battery
N Intel NM10 Express Chipset
O USB front panel header
P PCI bus connector
Q USB front panel header
R Front panel audio header
S BIOS configuration jumper block
