Intel Corporation by going to the World Wide Web site at: http://www.intel.com/ or by calling 1-800-548-4725. Intel, the Intel logo, and Intel Atom are trademarks of Intel Corporation in the U. S. and other countries. * Other names and brands may be claimed as the property of others.
The suitability of this product for other PC or embedded non-PC applications or other environments, such as medical, industrial, alarm systems, test equipment, etc. may not be supported without further evaluation by Intel. Document Organization The chapters in this Product Guide are arranged as follows:...
Page 4
Intel Desktop Board D410PTL Product Guide Terminology The table below gives descriptions to some common terms used in the product guide. Term Description Gigabyte (1,073,741,824 bytes) Gigahertz (one billion hertz) Kilobyte (1024 bytes) Megabyte (1,048,576 bytes) Mbit Megabit (1,048,576 bits)
1 Desktop Board Features Desktop Board Components.................11 Processor......................13 System Memory....................13 Integrated Graphics Subsystem ................14 ® Intel NM10 Express Chipset ................14 Operating System Support ..................14 Onboard Audio Subsystem ..................14 Legacy Input/Output (I/O) Controller ..............16 LAN Subsystem ....................16 USB 2.0 Support ....................17 SATA Interface ....................17...
Page 6
Intel Desktop Board D410PTL Product Guide 3 Updating the BIOS ® Updating the BIOS with the Intel Express BIOS Update Utility.........45 Updating the BIOS with the Iflash Memory Update Utility .........46 Obtaining the BIOS Update File ..............46 Using the Iflash Memory Update Utility ............46 Recovering the BIOS ...................47...
Page 7
11. Location of the Chassis Fan Header ..............35 12. Connecting a Power Supply Cable ..............36 13. BIOS Configuration Jumper Block..............37 14. Removing the Battery ...................43 15. Intel Desktop Board D410PTL China RoHS Material Self Declaration Table.....58 Tables 1. Feature Summary..................9 2. Intel Desktop Board D410PTL Components............12 3.
1 Desktop Board Features ® This chapter briefly describes the main features of Intel Desktop Board D410PTL. Table 1 summarizes the features of the Desktop Board. Table 1. Feature Summary Form Factor Mini-ITX ([170 millimeters [6.7 inches] x 170 millimeters [6.7 inches]) ®...
Page 10
Intel Desktop Board D410PTL Product Guide For more information on Intel Desktop Board D410PTL consult the following online resources: To find information Visit this World Wide Web site: about… Intel Desktop Board http://www.intel.com/products/motherboard/D410PTL/index.htm D410PTL Desktop Board Support http://www.intel.com/support/motherboards/desktop Available configurations http://www.intel.com/products/motherboard/D410PTL/index.htm...
Desktop Board Features Desktop Board Components Figure 1 shows the location of the major components on Intel Desktop Board D410PTL. Figure 1. Intel Desktop Board D410PTL Components...
Intel Desktop Board D410PTL Product Guide Table 2. Intel Desktop Board D410PTL Components Label Description Back panel connectors Chassis fan header Main power connector Standby power indicator Processor Channel A DIMM 0 Channel A DIMM 1 SATA 1 SATA 0...
Desktop Board Features Processor Intel Desktop Board D410PTL includes a passively-cooled, single-core Intel Atom processor with integrated graphics and memory controller. The processor is soldered to the Desktop Board and is not customer upgradeable. NOTE The board is designed to be passively cooled in a properly ventilated chassis. Chassis venting locations are recommended above the processor heatsink area for maximum heat dissipation effectiveness.
Supports analog displays up to 2048 x 1536 at 75 Hz refresh (QXGA) ® Intel NM10 Express Chipset The Intel NM10 Express Chipset is a centralized controller for the board’s I/O paths. For more information about the Intel NM10 Express Chipset, go to http://www.intel.com/products/chipsets/index.htm?iid=prod+prod_chipset. Operating System Support The following Microsoft* operating systems are fully supported by the Desktop Board: •...
Desktop Board Features The front/back panel audio connectors are configurable through the audio device drivers. Table 3 lists the supported functions of the front panel and back panel jacks. Table 3. Audio Jack Support Audio Jack Line Line/ Rear Out Microphone Headphones Front Out...
PCI bus power management ⎯ Supports ACPI technology ⎯ Supports LAN wake capabilities LAN drivers are available from Intel’s World Wide Web site at http://downloadcenter.intel.com/. Two LEDs are built into the RJ-45 LAN connector located on the back panel (see Figure 3).
Desktop Board Features Table 4 describes the LED states when the board is powered up and the LAN subsystem is operating. Table 4. LAN Status LEDs LED Color LED State Indicates Activity (A) Green Blinking LAN activity is occurring. 10 Mbits/s data rate is selected. Speed (B) Yellow 100 Mbits/s data rate is selected.
Intel Desktop Board D410PTL Product Guide BIOS The BIOS provides the Power-On Self-Test (POST), the BIOS Setup program, the PCI and IDE auto-configuration utilities, and the video BIOS. PCI Auto Configuration If you install a PCI add-in card in your computer, the PCI auto-configuration utility in the BIOS automatically detects and configures the resources (IRQs, DMA channels, and I/O space) for that add-in card.
Desktop Board Features ACPI ACPI gives the operating system direct control over the power management and Plug and Play functions of a computer. The use of ACPI with the Desktop Board requires an operating system that provides full ACPI support. Hardware Support Fan Header The Desktop Board has a 3-pin chassis fan header.
Intel Desktop Board D410PTL Product Guide Figure 4. Location of the Standby Power Indicator For more information on standby current requirements for the Desktop Board, refer to the Technical Product Specification on the Intel Desktop D410PTL web page at http://www.intel.com/products/motherboard/D410PTL/index.htm. Instantly Available PC Technology Instantly Available PC technology enables the board to enter the ACPI S3 (Suspend-to- RAM) sleep-state.
Desktop Board Features LAN Wake Capabilities The board’s LAN wake capabilities enable remote wake-up of the computer through a network. The LAN subsystem network adapter monitors network traffic at the Media Independent Interface. The board supports LAN wake capabilities with ACPI in the following ways: •...
Intel Desktop Board D410PTL Product Guide ENERGY STAR*, e-Standby, and ErP Compliance Intel Desktop Board D410PTL meets the ENERGY STAR requirements listed in Table 5 when used in corresponding system configurations. Table 5. ENERGY STAR Requirements Typical Electricity ENERGY STAR...
2 Installing and Replacing Desktop Board Components This chapter tells you how to: • Install the I/O shield • Install and remove the Desktop Board • Install and remove system memory • Connect SATA drives • Connect to internal headers •...
Page 24
All responsibility for determining the adequacy of any thermal or system design remains solely with the reader. Intel makes no warranties or representations that merely following the instructions presented in this document will result in a system with adequate thermal performance.
Installing and Replacing Desktop Board Components Installation Precautions When you install and test the Intel Desktop Board, observe all warnings and cautions in the installation instructions. To avoid injury, be careful of: • Sharp pins on connectors or headers •...
Intel Desktop Board D410PTL Product Guide Installing the I/O Shield The Desktop Board comes with an I/O shield. When installed in the chassis, the shield blocks radio frequency transmissions, protects internal components from dust and foreign objects, and promotes correct airflow within the chassis.
Refer to your chassis manual for instructions on installing and removing the Desktop Board. Figure 6 shows the location of the mounting screw holes for Intel Desktop Board D410PTL. Figure 6. Intel Desktop Board D410PTL Mounting Screw Holes...
Intel Desktop Board D410PTL Product Guide Installing DIMMs To make sure you have the correct DIMM, place it on the illustration in Figure 7 showing the DDR2 DIMM. All the notches should match the DDR2 DIMM. Figure 7. Use DDR2 DIMMs...
Page 29
Installing and Replacing Desktop Board Components 1. Observe the precautions in "Before You Begin" on page 23. 2. Turn off all peripheral devices connected to the computer. Turn off the computer and disconnect the AC power cord. 3. Remove the computer’s cover and locate the DIMM socket (see Figure 8). Figure 8.
Intel Desktop Board D410PTL Product Guide Removing DIMMs To remove a DIMM, follow these steps: 1. Observe the precautions in "Before You Begin" on page 23. 2. Turn off all peripheral devices connected to the computer. Turn off the computer.
Page 31
Installing and Replacing Desktop Board Components Figure 9. Connecting a Serial ATA Cable...
Intel Desktop Board D410PTL Product Guide Connecting to the Internal Headers Before connecting cables to the internal headers, observe the precautions in "Before You Begin" on page 23. Figure 10 shows the location of the board’s internal headers. Figure 10. Internal Headers...
Figure 10, A shows the location of the front panel audio header. The front panel audio header can be used for both Intel HD Audio and AC ‘97 Audio. Table 6 shows the pin assignments for the Intel HD Audio and Table 7 shows the pin assignments for AC ‘97 Audio.
Intel Desktop Board D410PTL Product Guide Connecting to the Front Panel Header Before connecting to the front panel header, observe the precautions in "Before You Begin" on page 23. See Figure 10, C on page 32 for the location of the front panel header.
Installing and Replacing Desktop Board Components Connecting a Chassis Fan Figure 11 shows the location of the chassis fan header. Connect the chassis fan cable to this header. Figure 11. Location of the Chassis Fan Header...
Intel Desktop Board D410PTL Product Guide Connecting the Power Supply Cable CAUTION Failure to use an appropriate power supply to the Desktop Board may result in damage to the board or the system may not function properly. Figure 12 shows the location of the power connector.
Installing and Replacing Desktop Board Components Setting the BIOS Configuration Jumper NOTE Always turn off the power and unplug the power cord from the computer before changing a jumper. Moving the jumper with the power on may result in unreliable computer operation.
Intel Desktop Board D410PTL Product Guide Table 10. Jumper Settings for the BIOS Setup Program Modes Jumper Setting Mode Description Normal (default) (1-2) The BIOS uses the current configuration and passwords for booting. Configure (2-3) After the Power-On Self-Test (POST) runs, the BIOS displays the Maintenance Menu.
Installing and Replacing Desktop Board Components 12. To restore normal operation, place the jumper on pins 1-2 as shown below. 13. Replace the cover, plug in the computer, and turn on the computer. Replacing the Battery A coin-cell battery powers the Desktop Board’s real-time clock and CMOS memory. When the computer is not plugged into a wall socket, the battery has an estimated life of three years.
Page 40
Intel Desktop Board D410PTL Product Guide VORSICHT Bei falschem Einsetzen einer neuen Batterie besteht Explosionsgefahr. Die Batterie darf nur durch denselben oder einen entsprechenden, vom Hersteller empfohlenen Batterietyp ersetzt werden. Entsorgen Sie ver- brauchte Batterien den Anweisungen des Herstellers entsprechend.
Page 41
Installing and Replacing Desktop Board Components AWAS Risiko letupan wujud jika bateri digantikan dengan jenis yang tidak betul. Bateri sepatutnya dikitar semula jika boleh. Pelupusan bateri terpakai mestilah mematuhi peraturan alam sekitar tempatan. OSTRZEŻENIE Istnieje niebezpieczeństwo wybuchu w przypadku zastosowania niewłaściwego typu baterii. Zużyte baterie należy w miarę...
Page 42
Intel Desktop Board D410PTL Product Guide OСТОРОГА Використовуйте батареї правильного типу, інакше існуватиме ризик вибуху. Якщо можливо, використані батареї слід утилізувати. Утилізація використаних батарей має бути виконана згідно місцевих норм, що регулюють охорону довкілля.
Installing and Replacing Desktop Board Components 1. Observe the precautions in "Before You Begin" (see page 23). 2. Turn off all peripheral devices connected to the computer. Disconnect the computer’s power cord from the AC power source (wall outlet or power adapter). 3.
Power-On Self-Test (POST) memory test begins and before the operating system boot begins. This chapter tells you how to update the BIOS by either using the Intel Express BIOS Update utility or the Iflash Memory Update utility, and how to recover the BIOS if an update fails.
You can obtain either of these files through your computer supplier or by navigating to the Intel Desktop Board D410PTL page at http://www.intel.com/support/motherboards/desktop. Navigate to the Intel Desktop D410PTL page, click “[view] Latest BIOS updates,” and select the Iflash BIOS Update utility file. CAUTION Do not interrupt the process or the system may not function properly.
CD-ROM drive connected to the SATA interface USB removable drive (a USB Flash Drive, for example) USB diskette drive (with a 1.44 MB diskette) USB hard disk drive NOTE For more information about BIOS update and recovery, go to http://support.intel.com/support/motherboards/desktop/sb/CS-022312.htm.
A Board Status and Error Messages This appendix describes status and error messages generated by the Desktop Board’s BIOS. The BIOS indicates these error messages with front-panel Power LED blink codes, speaker beep codes, and by displaying text on the video monitor. BIOS Beep Codes The BIOS uses audible beep codes to signal status messages and error messages indicating recoverable errors that occur during the POST.
Intel Desktop Board D410PTL Product Guide BIOS Front-panel Power LED Blink Codes The BIOS also blinks the front-panel power LED to signal status messages and error messages indicating certain recoverable errors that occur during the POST. The blink codes are listed in Table 13.
• Electromagnetic Compatibility (EMC) regulations • Product certifications Safety Standards Intel Desktop Board D410PTL complies with the safety standards stated in Table 15 when correctly installed in a compatible host system. Table 15. Safety Standards Regulation Title CSA/UL 60950-1, First Information Technology Equipment –...
European Union Declaration of Conformity Statement ® We, Intel Corporation, declare under our sole responsibility that the product Intel Desktop Board D410PTL is in conformity with all applicable essential requirements necessary for CE marking, following the provisions of the European Council Directives 2004/108/EC (EMC Directive) and 2006/95/EC (Low Voltage Directive).
The following information is provided to address worldwide product ecology concerns and regulations. Recycling Considerations As part of its commitment to environmental responsibility, Intel has implemented the ® Intel Product Recycling Program to allow retail consumers of Intel’s branded products to return used products to selected locations for proper recycling.
Page 54
Français Dans le cadre de son engagement pour la protection de l'environnement, Intel a mis en œuvre le programme Intel Product Recycling Program (Programme de recyclage des produits Intel) pour permettre aux consommateurs de produits Intel de recycler les produits usés en les retournant à...
Page 55
Regulatory Compliance Portuguese Como parte deste compromisso com o respeito ao ambiente, a Intel implementou o Programa de Reciclagem de Produtos para que os consumidores finais possam enviar produtos Intel usados para locais selecionados, onde esses produtos são reciclados de maneira adequada.
FLI is acceptable because of the RoHS "flip chip" or "die bump" interconnect exemption. Intel Desktop Board D410PTL is a lead-free second level interconnect product. Table 16 shows the lead-free second level interconnect marks as they appear on the board and accompanying collateral. These marks are based on JEDEC standard J-STD-609, “Marking and Labeling of Components, PCBs and PCBAs to Identify Lead,...
The EFUP for Intel Desktop Boards has been determined to be 10 years. The EFUP for Intel Desktop Board D410PTL is shown in Table 17. Table 17. China RoHS Environmentally Friendly Use Period Mark...
Intel Desktop Board D410PTL Product Guide The China MII also stipulates that a material Self Declaration Table (SDT) must be included in a product’s user documentation. The SDT for Intel Desktop Board D410PTL is shown in Figure 15. Figure 15. Intel Desktop Board D410PTL China RoHS Material...
Regulatory Compliance EMC Regulations Intel Desktop Board D410PTL complies with the EMC regulations stated in Table 18 when correctly installed in a compatible host system. Table 18. EMC Regulations Regulation (Class B) Title FCC 47 CFR Part 15, Title 47 of the Code of Federal Regulations, Part 15, Subpart B, Subpart B Radio Frequency Devices.
Intel Desktop Board D410PTL Product Guide Korean Class B statement translation: This is household equipment that is certified to comply with EMC requirements. You may use this equipment in residential environments and other non-residential environments. Ensure Electromagnetic Compatibility (EMC) Compliance...
Regulatory Compliance Product Certifications Board-Level Certification Markings Intel Desktop Board D410PTL has the product certification markings shown in Table 19. Table 19. Product Certification Markings Description Mark UL joint US/Canada Recognized Component mark. Includes adjacent UL file number for Intel Desktop Boards: E210882.
Intel Desktop Board D410PTL Product Guide Chassis and Component Certifications Ensure that the chassis and certain components; such as the power supply, peripheral drives, wiring, and cables; are components certified for the country or market where used. Agency certification marks on the product are proof of certification. Typical...
