Connecting to the Serial Headers

Before connecting to the serial headers, observe the precautions in "Before You Begin"
on page 23. See Figure 10, B on page 32 for the location of the serial headers.
Table 8 shows the pin assignments for the serial headers.
Table 8. Serial Port Headers (COM 1 and COM 2)
Pin Signal Name
1 DCD (Data Carrier Detect)
3 TXD# (Transmit Data)
5 Ground
7 RTS (Request To Send)
9 RI (Ring Indicator)

Connecting to the Front Panel Header

Before connecting to the front panel header, observe the precautions in "Before You
Begin" on page 23. See Figure 10, C on page 32 for the location of the front panel
header.
Table 9 shows the pin assignments for the front panel header.
Table 9. Front Panel Header Signal Names
Pin Signal
Hard Drive Activity LED
1 HD_PWR
3 HDA#
Reset Switch
5 Ground
7 FP_RESET# In
9 +5 V
34
In/Out Description
Hard disk LED pull-
Out
up (330 Ω) to +5 V
Hard disk active
Out
LED
Ground
Reset switch
Power
Power
Pin Signal Name
2 RXD# (Receive Data)
4 DTR (Data Terminal Ready)
6 DSR (Data Set Ready)
8 CTS (Clear To Send)
10 Key (no pin)
Pin Signal
Power LED
2 HDR_BLNK_GRN
4 HDR_BLNK_YEL
On/Off Switch
6 SWITCH_ON#
8 Ground
Not Connected
10 N/C
In/Out Description
Front panel
Out
green LED
Front panel
Out
yellow LED
In Power switch
Ground
No pin
