Operating system
Windows Server® 2003 Standard, Enterprise
of Web Edition
Windows XP Home Edition or Professional
Windows Vista®
Red Hat® Enterprise Linux 3, 4, and 5
Sun® Solaris TM 9 and 10
Novell® SUSE® Linux® Enterprise 9 and 10
Fedora Core 6, 7, and 8
Mac OS® X Tiger (10.4+)
*Requires Firefox® 1.5 or later
To log in to the remote OBWI:
Launch a web browser.
1.
NOTE:
address.
Example: https://[XXX.XX.XX.XX]
In the address bar of the browser, enter the IP address or host name assigned to the switch you want
2.
to access.
Examples: https://XXX.XX.XX.XX or https://hostname
NOTE:
When the browser connects to the switch, enter your username and password.
3.
Select Login. The remote OBWI appears.
4.
Connecting to the remote OBWI through a firewall
Any console switch installation that uses the remote OBWI for outside access must have four ports opened
in a firewall.
TCP port number
22
80
443
2068
In some configurations, the workstation is located outside of the firewall and the console switch is inside
the firewall. To configure the firewall, forward ports 22, 80, 443, and 2068 from the external interface to
If you are working in IPv6 mode, you must include square brackets around the IP
The default username is Admin with no password.
Function
Used by SSH during serial sessions to an MPUIQ-SRL
module
Used for the initial downloading of the Video Viewer
(for downloading the Java™ applet)
Used by the web browser interface for managing the
switch and launching KVM sessions
Transmission of KVM session data or transmission of
video on switches
Browser:
Microsoft® Internet
Explorer® version 6.0
SP1 and later
Yes
Yes
Yes
No
No
No
No
No
Browser:
Mozilla Firefox® version
2.0 and later
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
*
Configuring the console switch 31
