Installation and Maintenance
Instructions
Swing Gate Operator
Model SW420
Doc 01-G0610
Rev A

Advertisement

Table of Contents

Troubleshooting

loading
Need help?

Need help?

Do you have a question about the LiftMaster Professional SW420 and is the answer not in the manual?

Questions and answers

Summary of Contents for Chamberlain LiftMaster Professional SW420

  • Page 1 Installation and Maintenance Instructions Swing Gate Operator Model SW420 Doc 01-G0610 Rev A...
  • Page 2: Table Of Contents

    Contents Contents General Information ______________________________________________________ 4 Parts Supplied _______________________________________________________________________ 4 Model Classifications _________________________________________________________________ 4 Specifications _______________________________________________________________________ 5 Safety Information ________________________________________________________ 6 Safety Instructions____________________________________________________________________ 6 Safety Precautions for Swing Gates and Ornamental “Grill Type” Gates _________________________ 8 Preparing the Installation __________________________________________________ 9 Pre-Installation Check List _____________________________________________________________ 9 Wiring Specifications _________________________________________________________________ 9 Operator Preparation _________________________________________________________________ 10...
  • Page 3: Contents

    5. Gear Reducer_____________________________________________________________________ 30 General Reference Information_________________________________________________________ 30 Features and Program Troubleshooting review ____________________________________________ 30 Parts List – SW420 _______________________________________________________ 31 Warranty Policy__________________________________________________________ 33 IMPORTANT! Please leave this manual at the job site, preferably with the end user or facility manager. Read and follow all instructions.
  • Page 4: General Information

    General Information Parts Supplied There are two cartons for the standard model SW420. The large carton contains the powerhead unit and small parts. The long thin carton contains the two pieces of the control arm. In addition, if the pedestal mount option was ordered, a third carton containing the pedestal and associated hardware is included.
  • Page 5: Specifications

    General Information Specifications Power: 115vac. Or 230vac. 60 hz. 6.5 amps @ 115v. 3.3 amps @ 230v. Motor: Perm. Split cap. Speed – 1000 rpm RECOMMENDED CAPACITIES Current – 5.2A @ 115v. GATE WT. GATE WIDTH MAX. STARTS/HR. 2.6A @ 230v. 300 lbs.
  • Page 6: Safety Information

    Safety Information Safety Information Vehicular gate systems provide convenience and security. Gate systems are comprised of many component parts. The gate operator is only one component. Each gate system is specifically designed for an individual application. Gate operating system designers, installers and users must take into account the possible hazards associated with each individual application.
  • Page 7 Safety Information Adjust clutch or load sensing device to minimum force setting. Do not overtighten clutch or adjust force setting above minimum. Install controls where user cannot touch gate while operating controls. Install two or more warning signs on the gate to alert persons in the area of automatic gate operation.
  • Page 8: Safety Precautions For Swing Gates And Ornamental "Grill Type" Gates

    Safety Information Safety Precautions for Swing Gates and Ornamental “Grill Type” Gates ENTRAPMENT ZONES Pedestrians must stay clear of the gate path, particularly the area where the gate can trap them, as shown in Figure 2. 01-G0610F3 Figure 2 Gate edges and/or photo-electric beams must be incorporated into the swing gate system to assist in the protection of people who may come near the gate operating system.
  • Page 9: Preparing The Installation

    Preparing the Installation Preparing the Installation Pre-Installation Check List Check the gate. It MUST operate smoothly and freely. If necessary, lubricate the hinges, adjust or repair the gate prior to operator installation. The gate MUST be level. Double check the size and weight of the gate to make sure that it is proper for this application. If wiring has already been installed, check to make sure it meets the following specifications.
  • Page 10: Operator Preparation

    There is mixed voltage in this box, both line voltage, and control voltage 24 VAC. Select the preferred method of electrical wire entry. The SW420 is provided with (6) holes in the bottom of the chassis for electrical entry. Power supply wiring will be routed to the large double gang electrical box on the left side of the operator.
  • Page 11: Installation

    Installation Installation Select the type of mounting desired. The Model is designed for post mounting as factory standard, but may either be pad mounted or pedestal mounted if provided with either the optional pad mount or pedestal mount accessory kit. Post Mount Installation Locate mounting posts according to the The operator cabinet may be installed either...
  • Page 12 Installation 01-G0610F6 SW420 POST SW420 POST PARALLEL MOUNT PERPENDICULAR MOUNT Figure 5 REAR OF CABINET SPECIAL BOLT USE TOOL PROVIDED (11-2754) TO INSERT SPECIAL NUT IN REAR HOLES. 01-G0610F7 Figure 6 Doc 01-G0610 Rev A...
  • Page 13: Pad Mount Installation

    Bolt the (2) pad mount brackets to the bottom Refer to Figure of the SW420 with the hardware provided. After the concrete has set, secure the It is very important that the operator be level operator to the pad.
  • Page 14: Pedestal Mount Installation

    HINGE PIN HINGE PIN PIVOT PIVOT FENCE LINE FENCE LINE GATE GATE PEDESTAL 24” DEEP IN-GROUND MINIMUM SW420 PEDESTAL SW420 PEDESTAL PERPENDICULAR MOUNT PARALLEL MOUNT NUT TYP. (8X) 01-G0610F8 BOLT TYP. (4X) FROM BRACKET TO PEDESTAL Figure 8 Doc 01-G0610...
  • Page 15: Control Arm Assembly

    Installation Control Arm Assembly Assemble the control arm to the operator hub. See Figure Push up the manual release pin (80-2752) from below the hub and through the control arm. Then retain in place with the clevis pin (80-2753). Using the 3/8” washers (80-206-65), take up any play A cotter pin (86-HP-4) keeps the between the clevis pin and the top of the control arm.
  • Page 16 Installation 85-FW-38S 01-G0610F10 Figure 9 01-G0610F11 Figure 10 Doc 01-G0610 Rev A...
  • Page 17: System Features

    System Features System Features 01-G0610F12 Figure 11: SW420 CONTROLLER Visible/Audible Devices ACTIVITY LED Steady indication when gate is at either open or close limit. 1 flash per second when gate is off a limit in normal operation. 2 flashes per second when entrapment level one has occurred.
  • Page 18: Obstruction Sensing

    System Features CLOSE SINGLE BUTTON SELECT The single button (programmable) control can be programmed to either function as a single button or to function as a close button only. DIGITAL MICROPROCESSOR This is the main circuit board for the operator. It contains all the logic and intelligence for the system.
  • Page 19: Programming

    Programming Programming 01-G0610F13 Figure 13: Main Control Board Switch #1: Operator Programming Refer to Table 5. POLE #1: SINGLE/CLOSE BUTTON ON = Close button only OFF = Open/Close button POLE #2: RIGHT HAND / LEFT HAND ON = Left Hand (hate will open to the left) OFF = Right Hand (gate will open to the right—inside of fence looking out) POLE #3: WARNING DEVICE...
  • Page 20: Switch #2: Timer To Close

    Programming POLE POLE POLE POLE TOTAL TIME WARNING TOTAL TIME WARNING DEVICE DISABLED DEVICE ENABLED DISABLED DISABLED 1 SEC. 4 SEC. 13 SEC. 16 SEC. 26 SEC. 2 SEC. 40 SEC. 43 SEC. 52 SEC. 55 SEC. 65 SEC. 68 SEC. 78 SEC.
  • Page 21: Limit Switch Adjustments

    Limit Switch Adjustments Limit Switch Adjustments CAUTION Never place hands or tools inside operator or near drive mechanism unless power is off. Before turning on electrical power, disconnect the extension arm from gate bracket so that the gate is no longer connected to the operator.
  • Page 22 Limit Switch Adjustments Press the CLOSE button or connect terminals #3 & #1 or #3 & The control arm should start #2, depending on which installation you have (left or right hand to move in the direction that opening). The OPEN/CLOSE button is a constant pressure would close the gate if it function.
  • Page 23 Limit Switch Adjustments 12 Fine tune both the open and close limit switch settings by using Rotating cam away from the the OPEN, CLOSE and STOP buttons to move the gate and by limit switch increases gate rotating the limit collars slightly to allow more or less gate travel.
  • Page 24: Controls And Accessory Installation

    Controls and Accessory Installation Controls and Accessory Installation See wiring diagram for more information. See Wiring Specifications on p. 9 for wiring distances and wire gauge information. All inputs are normally open and momentary, except the stop (NC), and emergency close and emergency open (constant pressure).
  • Page 25: Manual Operation

    Manual Operation Manual Operation To operate the gate manually, disconnect the control arm from the drive hub by removing the hairpin cotter and then the clevis pin and allowing the manual release pin to drop down through the hub. The arm should now be free and the gate can be opened and closed normally.
  • Page 26: Required Maintenance

    Required Maintenance Required Maintenance Normal Usage Check at least once every (#) of months ITEM ACTION Internal speed Check for proper operation sensor External safety Check for proper operation systems Gate caution Make sure they are present signs Sprockets & pulleys Check for set screw tightness Gate Inspect for wear or damage...
  • Page 27: Troubleshooting

    Troubleshooting Troubleshooting When troubleshooting, one of the first things to do is try to isolate the problem area. The five (5) main areas to check out are: Power Accessories Operator’s Primary Voltage Operator’s Low Voltage Gear Reducer 1. Power Always use extreme caution! Some possible symptoms of power problems include: The obvious one is –...
  • Page 28: Accessories

    Troubleshooting 2. Accessories Add-on accessories can create many of the problems that are credited to the operator. Many applications have more than one accessory item attached to the operator and some of these items even draw their power from the operator. Some of the symptoms that can show up because of accessories: The operator won’t close.
  • Page 29: Low Voltage Circuit

    Troubleshooting If there is power, then check for it at the transformer primary terminals. If there is voltage at the switch and none at the transformer, then you probably have a bad power disconnect and it should be replaced. If the problem is thought to be the motor, it is recommended that it be replaced. It is possible that the thermal overload inside the motor has overheated.
  • Page 30: Gear Reducer

    Troubleshooting 5. Gear Reducer If physical signs show a seal has broken in the gear reducer, it may be necessary to replace the reducer. When replacing the gear reducer oil, use Mobil1 10W-30 synthetic oil or equivalent. The oil level for the gear reducer allows gear to be dipped but not submerged in oil. DO NOT overfill gear reducer oil reservoir.
  • Page 31: Parts List - Sw420

    Parts List – SW420 Parts List – SW420 12-10715 07-2704 10-2701-T 07-2703 82-PX10-26 82-PX08-10T 24-24-1 24-24-1 12-10715 10-2705-T 01-G0610F18 Figure 19 Doc 01-G0610 Rev A...
  • Page 32 Parts List – SW420 Part # Description Qty. Part # Description Qty. 02-041-SP STOP BUTTON 80-1002 6-32 TINNERMAN NUT 07-2703 80-10026 3/8 x .010 SHIM (N) 07-2704 EXTENSION ARM 80-206-10 1-1/2 x 1.03 x .015 SPACER 07-2705 ARM STOP 80-206-11...
  • Page 33: Warranty Policy

    Warranty Policy Warranty Policy Seller warrants that the goods are free from defect in materials and/or workmanship for a period of one year from the date of shipment from the F.O.B. point. Goods returned to Seller for warranty repair within the warranty period, which upon receipt by Seller are confirmed to be defective and covered by this limited warranty, will be repaired or replaced (at Seller’s sole option) at no cost and returned pre- paid.
  • Page 34 LiftMaster. This documentation contains information proprietary to LiftMaster and such information may not be distributed without the prior written consent of LiftMaster. The software and firmware included in the LiftMaster product as they relate to this documentation are also protected by copyright and contain information proprietary to LiftMaster.
