Layout contents
Jumpers
1.
Clear RTC RAM (CLRTC1)
2.
VGA controller setting (3-pin VGA_SW1)
3.
DDR3 voltage control setting (4-pin LVDDR3_SEL1,
LVDDR3_SEL2)
4.
LAN controller setting (3-pin LAN_SW1, LAN_SW2)
5.
Chassis intrusion connector (2-pin CHASSIS)
6.
Force BIOS recovery setting (3-pin RECOVERY1)
7.
IPMI setting (3-pin IPMI_SEL1)
Internal connectors
1.
Serial ATA connectors (7-pin SATA1–6)
2.
USB connectors (5-1 pin USB3; A-Type USB4)
3.
Thermal sensor cable connectors (3-pin TR1, TR2)
4.
Front fan connectors (4-pin FRNT_FAN1–4)
5.
LPC debug card connector (14-1 pin LPC1)
6.
Serial General Purpose Input/Output connector (8-1 pin SGPIO1,
SGPIO2)
7.
BMC header (BMC_FW1)
8.
Power Supply SMBus connectors (6-1 pin JP1, JP2)
9.
Proprietary power connectors (20-pin PWR1, 20-pin PWR2,
4-pin EZ_PLUG1)
10.
HDD status indicator header (9-1 pin HSATAT1)
11.
Hard disk activity LED connector (4-pin HDLED1)
12.
Internal VGA Header (10-1 pin VGA_HDR1)
13.
Auxiliary panel connector (20-pin AUX_PANEL1)
14.
System panel connector (20-pin PANEL1)
Internal LEDs
1.
Standby power LED
2.
CPU warning LED (ERR_CPU1, ERR_CPU2)
3.
BMC LED (BMC_LED1)
4-4
Chapter 4: Motherboard information
Page
4-5
4-6
4-6
4-7
4-7
4-8
4-8
Page
4-9
4-10
4-10
4-11
4-12
4-12
4-13
4-13
4-14
4-15
4-15
4-16
4-17
4-18
Page
4-19
4-19
4-20
