  • Page 1 RS720Q-E9-RS8 2U Rackmount Server User Guide...
  • Page 2 ASUSTeK COMPUTER INC. (“ASUS”). ASUS provides this manual “as is” without warranty of any kind, either express or implied, including but not limited to the implied warranties or conditions of merchantability or fitness for a particular purpose. In no...

  • Page 3: Table Of Contents

    Storage devices..................2-9 Expansion slots ..................2-11 2.6.1 The PCI Express riser card ............2-11 2.6.2 Installing an ASUS HFI-OMNI 100G LAN card ......2-14 2.6.3 Installing Mezzanine cards ............2-17 2.6.4 Configuring an expansion card ..........2-18 Backplane and Mid Plane cabling ............2-19 Removable/optional components ............
  • Page 4 Mid Plane jumper ..................4-17 Chapter 5: BIOS Setup Managing and updating your BIOS ............5-2 5.1.1 ASUS CrashFree BIOS 3 utility........... 5-2 5.1.2 ASUS EZ Flash Utility ..............5-3 5.1.3 BUPDATER utility ............... 5-4 BIOS setup program .................. 5-6 5.2.1...
  • Page 5 Contents 5.4.7 APM ..................5-16 5.4.8 PCI Subsystem Settings ............5-17 5.4.9 Network Stack Configuration............. 5-21 5.4.10 CSM Configuration ..............5-22 5.4.11 NVMe Configuration ..............5-23 5.4.12 USB Configuration ..............5-23 5.4.13 Vcore Adjust ................5-24 5.4.14 iSCSI Configuration ..............5-24 5.4.15 Intel(R) Virtual RAID on CPU ............
  • Page 6 ..........7-8 ® Installing the Intel I350-AM2/I210 Gigabit Adapters driver ....7-10 VGA driver installation ................7-13 ® Intel Rapid Storage Technology enterprise 5.0 installation ....7-15 Appendix Z11PH-D12 block diagram ..................A-2 ASUS contact information ..................A-3...

  • Page 7: Notices

    (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. CAN ICES-3(A)/NMB-3(A) REACH Complying with the REACH (Registration, Evaluation, Authorization, and Restriction of Chemicals) regulatory framework, we publish the chemical substances in our products at ASUS REACH website at http://csr.asus.com/english/REACH.htm.

  • Page 8: Safety Information

    Safety information Electrical Safety • Before installing or removing signal cables, ensure that the power cables for the system unit and all attached devices are unplugged. • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.

  • Page 9: Australia Statement Notice

    If you require assistance please call ASUS Customer Service 1300 2787 88 or visit us at https://www.asus.com/support...

  • Page 10: About This Guide

    About this guide Audience This user guide is intended for system integrators, and experienced users with at least basic knowledge of configuring a server. Contents This guide contains the following parts: Chapter 1: Product Introduction This chapter describes the general features of the server, including sections on front panel and rear panel specifications.
  • Page 11 Refer to the following sources for additional information, and for product and software updates. ASUS Control Center (ACC) user guide This manual tells how to set up and use the proprietary ASUS server management utility. ASUS websites The ASUS websites worldwide provide updated information for all ASUS hardware and...

  • Page 13: Chapter 1: Product Introduction

    Chapter 1: Product Introduction Product Introduction This chapter describes the general features of the chassis kit. It includes sections on front panel and rear panel specifications.

  • Page 14: System Package Contents

    4 x System Fans (80mm x 38mm) 4 x System Fans (80mm x 38mm) 8 x Hot-swap 2.5” Storage Bays 8 x Hot-swap 2.5” Storage Bays 1 x ASUS RS720Q-E9-RS8 Series Support DVD (includes User Guide) 8 x CPU Heatsinks 1 x Bag of Screws Accessories...

  • Page 15: Serial Number Label

    Please take note of the product’s serial number. The Serial number contains 12 characters such as xxS0xxxxxxxx similar to the figure shown below. You need to provide the correct serial number to the ASUS Technical Support team member if you need assistance or, when requesting support.

  • Page 16: System Specifications

    System specifications The ASUS RS720Q-E9-RS8 Series is a 2U server system featuring the ASUS Z11PH-D12 ® ® Server Board. The server supports Intel Xeon processor Scalable family plus other latest technologies through the chipsets onboard. RS720Q-E9-RS8 RS720Q-E9-RS8-S Model Name 2 x Socket P0 (LGA 3647) per Node ®...
  • Page 17 Linux Enterprise Server CentOS OS support Ubuntu VMware Citrix XenServer * Please find the latest OS support from http://www.asus.com/ Regulatory Compliance BSMI, CE, C-TICK, FCC (ClassA) 800mm x 444mm x 88mm(2U) Dimension 31.5" x 17.48" x 3.46" Gross Weight Kg 41.5 kg...

  • Page 18: Front Panel Features

    Front panel features The barebone server displays easily accessible features such as the power and reset buttons, LED indicators, and optical drive. Refer to the Front panel LEDs section for the LED descriptions. PORT80 PORT80 PORT80 PORT80 Turn off the system power and detach the power supply before removing or replacing any system component.

  • Page 19: Rear Panel Features

    When installing only two nodes, install the nodes to node slot number 1 and 3 or number 2 and 4. Z11PH-D12 (Node) DM management LAN port* LAN port 2 USB 3.0 ports Power button LAN port 1 Q-Code/Port 80 LED This port is for ASUS ASMB9-iKVM controller and for technicians only. RS720Q-E9-RS8 Series...

  • Page 20: Internal Features

    System fan (SYS_FAN2) System fan (SYS_FAN3) System fan (SYS_FAN4) BP_FAN1 (top) and BP_FAN2 (bottom) SATA/NVMe Mid-plane (for RS720Q-E9-RS8) or SATA/SAS/NVMe Mid-plane (for RS720Q-E9-RS8-S) ASUS Z11PH-D12 Server Board Power supply and power fan Ensure that the air duct is positioned on the gaps between the memory slots.

  • Page 21: Led Information

    A hardware monitor event is indicated No LAN connection LAN LEDs Blinking LAN is transmitting or receiving data LAN connection is present Location switched is pressed Location LED Normal status (Press the location switch again to turn off.) RS720Q-E9-RS8 Series...

  • Page 22: Lan (Rj-45) Leds

    1.7.2 LAN (RJ-45) LEDs LAN port LED indications ACT/LINK Activity/Link LED Speed LED SPEED Status Description Status Description No link 10 Mbps connection GREEN Linked ORANGE 100 Mbps connection BLINKING Data activity GREEN 1 Gbps connection LAN port 1.7.3 HDD status LEDs Status LED Active LED HDD LED...
  • Page 23 Memory Init. MRC Progress Memory Init. Done MRC Progress Other config. After RC end Progress Memory already installed. Progress CPU Init. Progress CPU Init. Progress CPU Init. Progress DXE Initial Program Load(IPL) (continued on the next page) RS720Q-E9-RS8 Series 1-11...
  • Page 24 Q-Code table Action PHASE POST CODE TYPE DESCRIPTION Progress DXE Core Started Progress DXE NVRAM Init. Progress SB run-time init. Progress DXE CPU Init Progress NB Init. DXE(Driver Progress NB Init. Execution Progress NB Init. Environment) phase Progress SB Init. Progress SB Init.

  • Page 25: Chapter 2: Hardware Information

    Chapter 2: Hardware Information Hardware Information This chapter lists the hardware setup procedures that you have to perform when installing or removing system components.

  • Page 26: Removing The Server Node

    Removing the server node Remove the screw located on the node latch. Hold the server node lever and press the green node latch. Firmly pull the server node out of the server chassis. When installing only two nodes, install the nodes to node slot number 1 and 3 or number 2 and 4.

  • Page 27: Air Duct

    Air Duct The RS720Q-E9-RS8 series server system comes with a motherboard fan air duct to enable better air flow inside the motherboard while the system is running. Removing the air duct Remove the screws securing the air duct in place.

  • Page 28: Central Processing Unit (Cpu)

    Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components. ASUS will shoulder the cost of repair only if the damage is shipment/ transit-related.
  • Page 29 CPU Carrier into the socket to prevent damaging the CPU pins on the socket. The heatsink for RS720Q-E9-RS8 Series differs between CPU1 and CPU2, please refer to the illustration below for more information on the heatsink and the corresponding CPU socket.
  • Page 30 Twist each of the four screws with a screwdriver just enough to attach the heatsink to the motherboard. When the four screws are attached, tighten them one by one in the sequence 1, 2 then 3, 4 as shown on the heatsink to completely secure the heatsink. •...

  • Page 31: System Memory

    GB, 128 GB LRDIMMS 3DS into the DIMM sockets using the memory configurations in this section. • Refer to ASUS Server AVL for the updated list of compatible DIMMs. • Always install DIMMs with the same CAS latency. For optimum compatibility, it is recommended that you obtain memory modules from the same vendor.
  • Page 32 To install two or more DIMMs, refer to the user guide bundled in the motherboard package. • Refer to www.asus.com for qualified vendor lists of the memory modules. Removing a DIMM from a single clip DIMM socket Press the retaining clip outward to unlock the DIMM.

  • Page 33: Storage Devices

    Orient and place the storage device into the tray. Ensure that the storage device is fitted firmly inside the drive tray and that the four screws of the storage device matches the four screw holes of the drive tray. RS720Q-E9-RS8 Series...
  • Page 34 Align and insert the 2.5-inch storage device and drive tray assembly into the drive bay. Repeat steps 1-6 to install the other 2.5-inch storage devices. 2-10 Chapter 2: Hardware Information...

  • Page 35: Expansion Slots

    Remove the screw securing the riser card to the chassis. Firmly hold the riser card then pull it up to detach it from the PCI Express x16 slot on the motherboard. Ensure to remove the riser card from the air duct when removing the riser card. RS720Q-E9-RS8 Series 2-11...
  • Page 36 Remove the screw from the metal bracket on the riser card, then remove the metal brackets from the riser card. Prepare the expansion card. Before installing an expansion card, read the documentation that came with it and ensure to make the necessary hardware settings. Align and insert the golden finger connectors of the expansion card to the PCI-E slot connector on the riser card as shown.
  • Page 37 Align and insert the riser card and expansion card assembly into the PCI-E slot on the motherboard. The expansion card fits in one orientation only. If it does not fit, try reversing it. Secure the riser card with the screw that you removed earlier in step 1. RS720Q-E9-RS8 Series 2-13...

  • Page 38: Installing An Asus Hfi-Omni 100G Lan Card

    When you install an Intel Xeon Skylake-F product family series processor to CPU1, you can install a ASUS HFI-OMNI card to the x16 slot on the riser card and enjoy all the benefits of ® the 100G Intel Omni-Path Architecture.
  • Page 39 Connect the internal OMNI-PATH cable (A) and the OMNIP cable to the ASUS HFI- OMNI card (B), install the ASUS HFI-OMNI card into the x16 slot on the riser card (C), then secure it with the screw (D). PCIE x16 slot...
  • Page 40 Ensure the OMNIP cable is organized so that it fits through the cable hole on the air duct. Refer to the illustration below for more details. Align and insert the riser card and ASUS HFI-OMNI card assembly into the PCI-E slot on the motherboard.

  • Page 41: Installing Mezzanine Cards

    Mezzanine card into the OCP connector on the motherboard. Ensure that the stand screws on the motherboard is aligned and matched to the screw holes of the Mezzanine card. OCP connector stand screws Secure the Mezzanine card with four bundled screws. RS720Q-E9-RS8 Series 2-17...

  • Page 42: Configuring An Expansion Card

    2.6.4 Configuring an expansion card After installing the expansion card, configure it by adjusting the software settings. Turn on the system and change the necessary BIOS settings, if any. See Chapter 5 for information on BIOS setup. Assign an IRQ to the card. Refer to the Standard Interrupt assignments table for more information.

  • Page 43: Backplane And Mid Plane Cabling

    Backplane and Mid Plane cabling RS720Q-E9-RS8-S Backplane Upper Mid Plane Lower Mid Plane RS720Q-E9-RS8 Series 2-19...
  • Page 44 Connect N4_MSASHD1 on the Backplane to N4_OCUSAS1 on the Upper Mid Plane Connect N3_MSASHD1 on the Backplane to N3_OCUSAS1 on the Lower Mid Plane Connect N2_MSASHD1 on the Backplane to N2_OCUSAS1 on the Upper Mid Plane Connect N1_MSASHD1 on the Backplane to N1_OCUSAS1 on the Lower Mid Plane Connect N4_OCUPCIE2 on the Backplane to N4_OCUPCIE2 on the Upper Mid Plane...
  • Page 45 RS720Q-E9-RS8 Backplane Upper Mid Plane Lower Mid Plane RS720Q-E9-RS8 Series 2-21...
  • Page 46 Connect N4_MSASHD1 on the Backplane to N4_OCUSATA1 on the Upper Mid Plane Connect N3_MSASHD1 on the Backplane to N3_OCUSATA1 on the Lower Mid Plane Connect N2_MSASHD1 on the Backplane to N2_OCUSATA1 on the Upper Mid Plane Connect N1_MSASHD1 on the Backplane to N1_OCUSATA1 on the Lower Mid Plane Connect N4_OCUPCIE2 on the Backplane to N4_OCUPCIE2 on the Upper Mid Plane...

  • Page 47: Removable/Optional Components

    System fan To replace a system fan: Loosen the four (4) screws on the top and the side of the top cover, then push the top cover towards the rear of the system and remove the top cover. RS720Q-E9-RS8 Series 2-23...
  • Page 48 Prepare a replacement fan of the same type and size. Disconnect the system fan cable from the fan connector on the Mid Plane. Lift the fan then set it aside. Repeat steps 3 to 4 to uninstall the other system fans. 2-24 Chapter 2: Hardware Information...

  • Page 49: Power Supply Module

    Hold the PSU lever, press the PSU latch (A) then carefully pull the PSU out of the system chassis (B). Prepare the replacement PSU. Align and insert the replacement PSU into the empty PSU bay until it clicks in place. RS720Q-E9-RS8 Series 2-25...
  • Page 50 • The system automatically combines the two power supply modules as a single one. The combined output power varies with input voltages. Refer to the table below for details. 1600W Input Voltage Max. Output Power (Watt) per PSU 200V-240Vac, 9.5A, 47-63Hz 1600W 2200W Input Voltage...

  • Page 51: Chapter 3: Installation Options

    Chapter 3: Installation Options Installation Options This chapter describes how to install the optional components and devices into the barebone server.

  • Page 52: Tool-Less Friction Rail Kit

    Tool-less Friction Rail Kit The tool less design of the rail kit allows you to easily install the rack rails into the server rack without the need for additional tools. The kit also comes with a metal stopping bracket that can be installed to provide additional support and stability to the server.
  • Page 53 (Optional) Use the rail screw and rail washer that comes with the kit to secure the rack rail to the rack post. A torque value of 14 kgf.cm is recommended for the rail screw. Perform steps 3 to 5 for the other rack rail. Ensure that the installed rack rails (left and right) are aligned, secured, and stable in place. RS720Q-E9-RS8 Series...

  • Page 54: Rail Kit Dimensions

    Lift the server chassis and insert into the rack rail. • Ensure that the rack rail cabinet and the rack posts are stable and standing firmly on a level surface. • We strongly recommend that at least two able-bodied persons perform the steps described in this guide. • We recommend the use an appropriate lifting tool or device, if necessary. Ensure to include the side knots on the two sides of the server in the rack rail holders. The illustrations shown above are for reference only.
  • Page 55 Chapter 4: Motherboard Information Motherboard Information This chapter includes the motherboard layout and brief descriptions of the jumpers and internal connectors.

  • Page 56: Motherboard And Mid Plane Layout

    Motherboard and Mid plane layout Z11PH-D12 Chapter 4: Motherboard Information...
  • Page 57 RS720Q-E9-RS8-S Mid Plane RS720Q-E9-RS8 Mid Plane RS720Q-E9-RS8 Series...

  • Page 58: Layout Contents

    4.1.1 Layout contents Jumpers Page Clear RTC RAM (CLRTC1) VGA controller setting (3-pin VGA_SW1) LAN controller setting (3-pin LAN_SW1, LAN_SW2) ME firmware force recovery setting (3-pin ME_RCVR1) DDR4 thermal event setting (3-pin DIMMTRIP1-2) BMC Setting (3-pin BMC_EN1) PMBus 1.2 PSU select jumper (3-pin SMART_PSU1) Chassis Intrusion (2-pin INTRUSION1) DMLAN setting (3-pin DM_IP_SEL1) 10.

  • Page 59: Jumpers

    Removing the cap will cause system boot failure! If the steps above do not help, remove the onboard battery and move the jumper again to clear the CMOS RTC RAM data. After the CMOS clearance, reinstall the battery. RS720Q-E9-RS8 Series...

  • Page 60: Vga Controller Setting (3-Pin Vga_Sw1)

    VGA controller setting (3-pin VGA_SW1) This jumper allows you to enable or disable the onboard VGA controller. Set to pins 1–2 to activate the VGA feature. LAN controller setting (3-pin LAN_SW1, LAN_SW2) ® These jumpers allow you to enable or disable the onboard Intel I210AT Gigabit LAN controllers.

  • Page 61: Me Firmware Force Recovery Setting (3-Pin Me_Rcvr1)

    ME firmware force recovery setting (3-pin ME_RCVR1) This jumper allows you to quickly recover the Intel Management Engine (ME) firmware when it becomes corrupted. DDR4 thermal event setting (3-pin DIMMTRIP1-2) These jumpers allow you to enable or disable DDR4 DIMM thermal sensing event pin. RS720Q-E9-RS8 Series...

  • Page 62: Bmc Setting (3-Pin Bmc_En1)

    BMC Setting (3-pin BMC_EN1) This jumper allows you to enable or disable the ASMB9. PMBus 1.2 PSU select jumper (3-pin SMART_PSU1) This jumper allows you to select PSU PMBus version. Chapter 4: Motherboard Information...

  • Page 63: Chassis Intrusion (2-Pin Intrusion1)

    CHASSIS# and GND pin by jumper cap to disable the function. DMLAN setting (3-pin DM_IP_SEL1) This jumper allows you to select the DMLAN setting. Set to pins 2-3 to force the DMLAN IP to static mode (IP=10.10.10.10, submask=255.255.255.0). RS720Q-E9-RS8 Series...

  • Page 64: Pch_Mfg Setting (3-Pin Pch_Mfg1)

    PCH_MFG setting (3-pin PCH_MFG1) This jumper allows you to update the BIOS ME block. 4-10 Chapter 4: Motherboard Information...

  • Page 65: Internal Connectors

    Serial port connector (10-1 pin COM1) This connector is for a serial (COM) port. Connect the serial port module cable to this connector, then install the module to a slot opening at the back of the system chassis. RS720Q-E9-RS8 Series 4-11...

  • Page 66: Omnip Connector (24-Pin Omnip1)

    OMNIP connector (24-pin OMNIP1) This connector allows you to provide sideband signals from the fabric CPU to a HFI-OMNI supported ASUS card. VROC_KEY connector (4-pin VROC_KEY1) This connector allows you to connect a KEY module to enable CPU RAID functions with Intel CPU RSTe.

  • Page 67: Vga Connector (16-1 Pin Vga_Hdr1)

    VGA connector (16-1 pin VGA_HDR1) This connector supports the VGA High Dynamic-Range interface. Mezzanine PCI card connectors (MEZZPCIE1; MEZZPCIE2) The MEZZPCIE1, MEZZPCIE2, and MEZZKR1 connectors support Open Compute Project (OCP) cards. RS720Q-E9-RS8 Series 4-13...

  • Page 68: Power Connector

    Power connector This power connector connects to the Mid Plane. 4-14 Chapter 4: Motherboard Information...

  • Page 69: Internal Leds

    The green heartbeat LED blinks per second to indicate that the ASMB9 is working normally. • The heartbeat LED functions only when you enable the ASUS ASMB9. • Every time after the AC power is replugged, you have to wait for about 30 seconds for the system to power up.

  • Page 70: Message Led (Mesled1)

    Message LED (MESLED1) This onboard LED lights up to red when there is temperature warning or a BMC event log is generated. Location LED (LOCLED1) This onboard LED lights up when the Location button on the server is pressed or when triggered by a system management software.

  • Page 71: Mid Plane Jumper

    Mid Plane jumper The illustration in this section may differ between models, but the location of the jumper remains the same. 12V_SEL1 jumper This jumper allows you to enhance the 12V standy when the system’s +12VSB is not enough. RS720Q-E9-RS8 Series 4-17...
  • Page 72 4-18 Chapter 4: Motherboard Information...

  • Page 73: Chapter 5: Bios Setup

    Chapter 5: BIOS Setup BIOS Setup This chapter tells how to change the system settings through the BIOS Setup menus. Detailed descriptions of the BIOS parameters are also provided.

  • Page 74: Managing And Updating Your Bios

    BIOS in the future. Copy the original motherboard BIOS using the BUPDATER utility. 5.1.1 ASUS CrashFree BIOS 3 utility The ASUS CrashFree BIOS 3 is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can update a corrupted BIOS file using a USB flash drive that contains the updated BIOS file.

  • Page 75: Asus Ez Flash Utility

    5.1.2 ASUS EZ Flash Utility The ASUS EZ Flash Utility feature allows you to update the BIOS without having to use a DOS-based utility. Before you start using this utility, download the latest BIOS from the ASUS website at www. asus.com. To update the BIOS using EZ Flash Utility: Insert the USB flash disk that contains the latest BIOS file into the USB port. Enter the BIOS setup program. Go to the Tool menu then select ASUS EZ Flash Utility.

  • Page 76: Bupdater Utility

    The BUPDATER utility allows you to update the BIOS file in the DOS environment using a bootable USB flash disk drive with the updated BIOS file. Updating the BIOS file To update the BIOS file using the BUPDATER utility: Visit the ASUS website at www.asus.com and download the latest BIOS file for the motherboard. Save the BIOS file to a bootable USB flash disk drive. Copy the BUPDATER utility (BUPDATER.exe) from the ASUS support website at support.asus.com to the bootable USB flash disk drive you created earlier. Boot the system in DOS mode, then at the prompt, type: BUPDATER /i[filename].CAP where [filename] is the latest or the original BIOS file on the bootable USB flash disk drive, then press <Enter>. A:\>BUPDATER /i[file name].CAP Chapter 5: BIOS Setup...
  • Page 77 The utility verifies the file, then starts updating the BIOS file. ASUS Tek. EzFlash Utility Current Platform New Platform Platform : Z11PH-D12 Platform : Z11PH-D12 Version : 0301 Version : 0304 Build date: 11/05/2017 Build date: 11/22/2017 Start Programming Flash. DO NOT SHUTDOWN THE SYSTEM!!! Write DO NOT shut down or reset the system while updating the BIOS to prevent system boot failure! The utility returns to the DOS prompt after the BIOS update process is completed.

  • Page 78: Bios Setup Program

    <F5> and select Yes to load the BIOS default settings. • The BIOS setup screens shown in this section are for reference purposes only, and may not exactly match what you see on your screen. • Visit the ASUS website (www.asus.com) to download the latest BIOS file for this motherboard. The system then runs the power-on self-test or POST. While the tests are running, the BIOS beeps or additional messages appear on the screen. If you do not see anything within 30 seconds from the time you turned on the power, the system may have failed a power-on test.

  • Page 79: Bios Menu Screen

    Event Logs For changing the event log settings For changing the Server Mgmt settings Server Mgmt Security For changing the security settings Boot For changing the system boot configuration Tool For configuring options for special functions Save & Exit For selecting the exit options To select an item on the menu bar, press the right or left arrow key on the keyboard until the desired item is highlighted. RS720Q-E9-RS8 Series...

  • Page 80: Menu Items

    5.2.3 Menu items The highlighted item on the menu bar displays the specific items for that menu. For example, selecting Main shows the Main menu items. The other items (Advanced, Platform Configuration, Socket Configuration, Event Logs, Server Mgmt, Security, Boot, Tool, and Save & Exit) on the menu bar have their respective menu items. 5.2.4 Submenu items A solid triangle before each item on any menu screen means that the item has a submenu. To display the submenu, select the item then press <Enter>. 5.2.5 Navigation keys At the bottom right corner of a menu screen are the navigation keys for the BIOS setup program. Use the navigation keys to select items in the menu and change the settings. 5.2.6 General help At the top right corner of the menu screen is a brief description of the selected item.

  • Page 81: Main Menu

    Main menu When you enter the BIOS Setup program, the Main menu screen appears. The Main menu provides you an overview of the basic system information, and allows you to set the system date, time, language, and security settings. 5.3.1 System Date [Day xx/xx/xxxx] Allows you to set the system date. 5.3.2 System Time [xx:xx:xx] Allows you to set the system time. RS720Q-E9-RS8 Series...

  • Page 82: Advanced Menu

    Take caution when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. Optimized Performance Settings [Default] This option allows you to select a recommended BIOS setting to optimize performance. Asus Turbo Ratio Lock (ATRL) [Disabled] Allows you to keep the processor operating at the turbo highest frequency for maximum performance. Configuration options: [Disabled] [Enabled] 5-10 Chapter 5: BIOS Setup...

  • Page 83: Trusted Computing

    Allows you to enable or disable the ability of the system to hibernate (OS/Sleep State). Configuration options: [Disabled] [Enabled] This option may be not effective with some OS. 5.4.3 Smart Settings SMART Self Test [Enabled] Allows you to run SMART Self Test on all HDDs during POST. Configuration options: [Disabled] [Enabled] RS720Q-E9-RS8 Series 5-11...

  • Page 84: Super Io Configuration

    5.4.4 Super IO Configuration Serial Port 1 Configuration Allows you to set the parameters of Serial Port 1. Serial Port [Enabled] Allows you to enable or disable Serial Port. Configuration options: [Disabled] [Enabled] The following item appears only when you set Serial Port to [Enabled]. Change Settings [Auto] Allows you to choose the setting for Super IO device.
  • Page 85 Parity [None] A parity bit can be sent with the data bits to detect some transmission errors. [Mark] and [Space] parity do not allow for error detection. [None] None [Even] parity bit is 0 if the num of 1’s in the data bits is even [Odd] parity bit is 0 if num of 1’s in the data bits is odd [Mark] parity bit is always 1 [Space] parity bit is always 0 Stop Bits [1] Stop bits indicate the end of a serial data packet. (A start bit indicates the beginning.) The standard setting is 1 stop bit. Communication with slow devices may require more than 1 stop bit. Configuration options: [1] [2] RS720Q-E9-RS8 Series 5-13...
  • Page 86 Flow Control [Hardware RTS/CTS] Flow control can prevent data loss from buffer overflow. When sending data, if the receiving buffers are full, a “stop” signal can be sent to stop the data flow. Once the buffers are empty, a “start” signal can be sent to re-start the flow. Hardware flow control uses two wires to send start/stop signals. Configuration options: [None] [Hardware RTS/CTS] VT -UTF8 Combo Key Support [Enabled] This allows you to enable the VT -UTF8 Combination Key Support for ANSI/VT100 terminals. Configuration options: [Disabled] [Enabled] Recorder Mode [Disabled] With this mode enabled only text will be sent. This is to capture Terminal data. Configuration options: [Disabled] [Enabled] Legacy OS Redirection Resolution [80x24] This allows you to set the number of rows and columns supported on the Legacy OS. Configuration options: [80x24] [80x25] Putty Keypad [VT100] This allows you to select the FunctionKey and Keypad on Putty. Configuration options: [VT100] [LINUX] [XTERMR6] [SCO] [ESCN] [VT400] Redirection After BIOS POST [Always Enable] This setting allows you to specify if Bootloader is selected than Legacy console...

  • Page 87: Onboard Lan Configuration

    Out-of-Band Mgmt Port [COM1] Microsoft Windows Emergency Management Services (EMS) allow for remote management of a Windows Server OS through a serial port. Configuration options: [COM1] [COM2] Terminal Type [VT-UTF8] Microsoft Windows Emergency Management Services (EMS) allow for remote management of a Windows Server OS through a serial port. Configuration options: [VT100] [VT100+] [VT-UTF8] [ANSI] Bits per second [115200] Microsoft Windows Emergency Management Services (EMS) allow for remote management of a Windows Server OS through a serial port. Configuration options: [9600] [19200] [57600] [115200] Flow Control [None] Microsoft Windows Emergency Management Services (EMS) allow for remote management of a Windows Server OS through a serial port. Configuration options: [None] [Hardware RTS/CTS] [Software Xon/Xoff] 5.4.6 Onboard LAN Configuration Onboard I350 LAN Configuration Intel LAN1 Enable [Enabled] Allows you to enable or disable the Intel LAN. Configuration options: [Disabled] [Enabled] RS720Q-E9-RS8 Series 5-15...

  • Page 88: Apm

    The following item appears only when you set Intel LAN1 Enable to [Enabled]. Intel LAN ROM Type [PXE] Allows you to select the Intel LAN ROM type. Configuration options: [Disabled] [PXE] [iSCSI] ® Due to Intel limitations, both Intel LAN ROM Type options should be the same when [PXE] or [iSCSI] is selected. Intel LAN2 Enable [Enabled] Allows you to enable or disable the Intel LAN. Configuration options: [Disabled] [Enabled] The following item appears only when you set Intel LAN2 Enable to [Enabled]. Intel LAN2 ROM Type [Disabled] Allows you to select the Intel LAN ROM type.

  • Page 89: Pci Subsystem Settings

    This option enables or disables SIngle Root IO Virtualization Support if the system has SRIOV capable PCIe devices. Configuration options: [Disabled] [Enabled] PCI Express Settings PCI Express Device Register Settings Relaxed Ordering [Enabled] This option allows you to enable or disable PCI Express Device Relaxed Ordering. Configuration options: [Disabled] [Enabled] Extended Tag [Disabled] This option allows Device to use an 8-bit Tag field as a requester when set to Enabled. Configuration options: [Disabled] [Enabled] RS720Q-E9-RS8 Series 5-17...
  • Page 90 No Snoop [Enabled] This option allows you to enable or disable PCI Express Device No Snoop option. Configuration options: [Disabled] [Enabled] Maximum Payload [Auto] This option allows you to set the Maximum Payload of PCI Express Device or allow System BIOS to select the value. Configuration options: [Auto] [128 Bytes] [256 Bytes] [512 Bytes] [1024 Bytes] [2048 Bytes] [4096 Bytes] Maximum Read Request [Auto]...
  • Page 91 Configuration options: [Disabled] [Enabled] Atomic0p Egress Blocking [Disabled] If supported by hardware and set to Enabled, outbound Atomic0p Requests via Egress Ports will be blocked. Configuration options: [Disabled] [Enabled] IDO Request Enable [Disabled] If supported by hardware and set to Enabled, this permits setting the number of ID- Based Ordering (IDO) bit (Attribute[2]) requests to be initiated. Configuration options: [Disabled] [Enabled] IDO Completion Enable [Disabled] If supported by hardware and set to Enabled, this permits setting the number of ID- Based Ordering (IDO) bit (Attribute[2]) requests to be initiated. Configuration options: [Disabled] [Enabled] LTR Mechanism Enable [Disabled] If supported by hardware and set to Enabled, this enables the Latency Tolerance Reporting (LTR) Mechanism. Configuration options: [Disabled] [Enabled] End-End TLP Prefix Blocking [Disabled] If supported by hardware and set to Enabled, this function will block forwarding of TLPs containing End-End TLP Prefixes. Configuration options: [Disabled] [Enabled] RS720Q-E9-RS8 Series 5-19...
  • Page 92 PCI Express GEN2 Device Register Settings Target Link Speed [Auto] If supported by hardware and set to Force to X.X GT/s, for Downstream Ports, this sets an upper limit on Link operational speed by restricting the values advertised by the Upstream component in its training sequences. When Auto is selected HW initialized data will be used. Configuration options: [Auto] [Force to 2.5 GT/s] [Force to 5.0 GT/s] [Force to 8.0 GT/s] Clock Power Management [Disabled] If supported by hardware and set to Enabled, the device is permitted to use CLKREQ# signal for power management of Link clock in accordance to protocol defined in appropriate form factor specification. Configuration options: [Disabled] [Enabled] Compliance SOS [Disabled] If supported by hardware and set to Enabled, this will force LTSSM to send SKP Ordered Sets between sequences when sending Compliance Pattern or Modified Compliance Pattern. Configuration options: [Disabled] [Enabled] Hardware Autonomous Width [Enabled] If supported by hardware and set to Disabled, this will disable the hardware’s ability to change link width except for width size reduction for the purpose of correcting unstable link operation.

  • Page 93: Network Stack Configuration

    Ipv6 PXE Support [Disabled] Enables or disables the Ipv6 PXE Boot Support. If disabled, Ipv6 PXE boot option will not be created. Configuration options: [Disable] [Enable] Ipv6 HTTP Support [Disabled] Enables or disables the Ipv6 HTTP Boot Support. If disabled, Ipv6 PXE boot option will not be created. Configuration options: [Disable] [Enable] PXE boot wait time [0] Set the wait time to press ESC key to abort the PXE boot. Use the <+> or <-> to adjust the value. The values range from 0 to 5. Media detect count [1] Set the number of times presence of media will be checked. Use the <+> or <-> to adjust the value. The values range from 1 to 50. RS720Q-E9-RS8 Series 5-21...

  • Page 94: Csm Configuration

    5.4.10 CSM Configuration CSM Support [Enabled] This option allows you to enable or disable CSM Support. Configuration options: [Disabled] [Enabled] The following items appear only when you set CSM Support to [Enabled]. GateA20 Active [Upon Request] This allows you to set the GA20 option. [Upon Request] GA20 can be disabled using BIOS services.

  • Page 95: Nvme Configuration

    USB Mass Storage Driver Support [Enabled] Allows you to enable or disable the USB Mass Storage driver support. Configuration options: [Disabled] [Enabled] Mass Storage Devices Allows you to select the mass storage device emulation type for devices connected. Configuration options: [Auto] [Floppy] [Forced FDD] [Hard Disk] [CD-ROM] RS720Q-E9-RS8 Series 5-23...

  • Page 96: Vcore Adjust

    5.4.13 Vcore Adjust CPU1 / CPU2 Configuration options: [AUTO] [0.3438] [0.3320] [0.3203] [0.3086] [0.3008] [0.2969] [0.2852] [0.2734] [0.2617] [0.2500] [0.2383] [0.2266] [0.2148] [0.2031] 5.4.14 iSCSI Configuration Allows you to configure the iSCSi parameters. 5.4.15 Intel(R) Virtual RAID on CPU Allows you to configure the view the RAID volumes and VMD controllers on the system. 5-24 Chapter 5: BIOS Setup...

  • Page 97: Platform Configuration Menu

    DeepSx Power Policies [Disabled] Allows you to configure the DeepSx Mode configuration. Configuration options: [Disabled] [Enabled in S5] [Enabled in S4 and S5] GP27 Wake From DeepSx [Disabled] Allows you to enable or disable GP27 Wake From DeepSx. Configuration options: [Disabled] [Enabled] PCI Express Configuration PCI-E ASPM Support (Global) [L1 Only] Allows you to select ASPM support for all downstream devices. Configuration options: [Per individual port] [L1 Only] PCH DMI ASPM [Platform-POR] Allows you to configure the PCH DMI ASPM. Configuration options: [Platform-POR] [ASPM L1] [Disabled] RS720Q-E9-RS8 Series 5-25...
  • Page 98 USB Configuration USB Precondition [Disabled] Allows you to enable or disable precondition work on USB host controller and root ports for faster enumeration. Configuration options: [Disabled] [Enabled] XHCI Manual Mode [Disabled] This option is used by validation. Configuration options: [Disabled] [Enabled] The following items appear only when XHCI Manual Mode is set to [Enabled]. Trunk Clock Gating (BTCG) [Enabled] Allows you to enable or disable BTCG. Configuration options: [Disabled] [Enabled] Enable USB 3.0 pins [Disable all pins] Allows you to enable or disable USB 3.0 pins or on a per pin basis.

  • Page 99: Miscellaneous Configuration

    Displays the Server ME Technology parameters on your system. Navigate to the second page of the screen to see the rest of items in this menu by pressing the Up or Down arrow keys. To quickly go to the last item of the second page, press the Page Down button. Press the Page Up button to go back to the first item in the first page. RS720Q-E9-RS8 Series 5-27...

  • Page 100: Runtime Error Logging

    5.5.4 Runtime Error Logging Displays the Server ME Technology parameters on your system. System Errors [Enabled] This item allows you to enable or disable System Errors. Configuration options: [Disabled] [Enabled] The following item is configurable only when System Errors is set to [Enabled]. Whea Settings Whea Support [Enabled] This item allows you to enable or disable the WHEA support. Configuration options: [Disabled] [Enabled] 5-28 Chapter 5: BIOS Setup...

  • Page 101: Socket Configuration Menu

    Navigate to the second page of the screen to see the rest of items in this menu by pressing the Up or Down arrow keys. To quickly go to the last item of the second page, press the Page Down button. Press the Page Up button to go back to the first item in the first page. Hyper-threading [ALL] [Enabled] This item allows a hyper-threading processor to appear as two logical processors, allowing the operating system to schedule two threads or processors simultaneously. Configuration options: [Disabled] [Enabled] RS720Q-E9-RS8 Series 5-29...
  • Page 102 Execute Disable Bit [Enabled] XD can prevent certain classes of malicious buffer overflow attacks when combined with a supporting OS (Windows Server 2003 SP1, Windows XP SP2, SuSE Linux 9.2, Redhat Enterprise 3 Update 3). Configuration options: [Disabled] [Enabled] Enable Intel(R) TXT [Disabled] Forces the XD feature log to always return 0 when disabled. Configuration options: [Disabled] [Enabled] VMX [Enabled] Enables the Vanderpool Technology. Takes effect after reboot. Configuration options: [Disabled] [Enabled] Enable SMX [Disabled] Enables the Safer Mode Extensions. Configuration options: [Disabled] [Enabled] Hardware Prefetcher [Enabled] This Item allows you to turn on/off the mid level cache(L2) streamer prefetcher. Configuration options: [Disabled] [Enabled] Adjacent Cache Prefetch [Enabled] This Item allows you to turn on/off prefetching of adjacent cache lines. Configuration options: [Disabled] [Enabled] DCU Streamer Prefetcher [Enabled] This Item allows you to enable or disable prefetcher of next L1 data line.

  • Page 103: Common Refcode Configuration

    This item displays information about the UPI status. Link Speed Mode [Fast] This item allows you to select the UPI link speed as either the fast mode or slow mode. Configuration options: [Slow] [Fast] Link Frequency Select [Auto] This item allows for selecting the UPI link frequency. Configuration options: [Auto] [9.6 GB/s] [10.4 GB/s] [Use Per Link Setting] Link L0p Enable [Auto] Configuration options: [Disabled] [Enabled] [Auto] Link L1 Enable [Auto] Configuration options: [Disabled] [Enabled] [Auto] Stale AtoS [Disabled] Configuration options: [Disabled] [Enabled] [Auto] LLC dead line alloc [Enabled] Configuration options: [Disabled] [Enabled] [Auto] RS720Q-E9-RS8 Series 5-31...

  • Page 104: Memory Configuration

    5.6.4 Memory Configuration Enforce POR [Auto] Allows you to enforce POR restrictions for DDR4 frequency and voltage programming. Configuration options: [Auto] [POR] [Disabled] Memory Frequency [Auto] Allows you to select the memory frequency setting. Configuration options: [Auto] [2133] [2400] [2666] Data Scrambling for DDR4 [Auto] Allows you to enable or disable data scrambling. Configuration options: [Auto] [Disabled] [Enabled] Memory Topology Displays memory topology with DIMM population information.

  • Page 105: Iio Configuration

    This option allows you to change the settings related to the PCI Express Ports. Intel® VT for Directed I/O (VT-d) Intel® VT for Directed I/O (VT-d) [Enabled] Allows you to enable or disable the Intel Virtualization Technology for Directed I/O. Configuration options: [Disabled] [Enabled] RS720Q-E9-RS8 Series 5-33...

  • Page 106: Advanced Power Management Configuration

    IIO-PCIE Express Global Options PCIE relaxed Ordering [Enabled] Allows you to enable or disable PCIE relaxed Ordering. Configuration options: [Disabled] [Enabled] 5.6.6 Advanced Power Management Configuration CPU P State Control Boot performance mode [Max Performance] Allows you to switch between Boot performance mode. Configuration options: [Max Performance] [Max Efficient] [Set by Intel Node Manager] Energy Efficient Turbo [Enabled] Allows you to enable or disable Energy Efficient Turbo.
  • Page 107 ENERGY_PERF_BIAS_CFG Mode [Balanced Performance] Configuration options: [Performance] [Balanced Performance] [Balanced Power] [Power] Dynamic Loadline Switch [Enabled] Configuration options: [Disabled] [Enabled] Workload Configuration [UMA] This option allows optimization for the workload characterization. Configuration options: [UMA] [NUMA] Averaging Time Window [17] This option is used to control the effective window of the average C0 an P0 time. Configuration options: [0] - [99] RS720Q-E9-RS8 Series 5-35...

  • Page 108: Event Logs Menu

    P0 TotalTimeThreshold Low [23] The HW switching mechanism DISABLES the performance setting (0) when the total P0 time is less than the threshold set. Configuration options: [0] - [99] P0 TotalTimeThreshold High [3a] The HW switching mechanism Enables the performance setting (0) when the total P0 time is greater than the threshold set. Configuration options: [0] - [99] Event Logs menu 5.7.1 Change Smbios Event Log Settings Press <Enter> to change the Smbios Event Log configuration. All values changed here do not take effect until computer is restarted. Enabling/Disabling Options Smbios Event Log [Enabled] Change this to enable or disable all features of Smbios Event Logging during boot.

  • Page 109: Server Mgmt Menu

    The following items are configurable only when OS Watchdog Timer is set to [Enabled]. OS Wtd Timer Timeout [10 minutes] Allows you to configure the length for the OS Boot Watchdog Timer. Configuration options: [5 minutes] [10 minutes] [15 minutes] [20 minutes] OS Wtd Timer Policy [Reset] This item allows you to configure the how the system should respond if the OS Boot Watch Timer expires. Configuration options: [Do Nothing] [Reset] [Power Down] 5.8.1 System Event Log Allows you to change the SEL event log configuration. All values changed here do not take effect until computer is restarted. Erase SEL [No] Allows you to choose options for erasing SEL. Configuration options: [No] [Yes, On next reset] [Yes, On every reset] When SEL is Full [Do Nothing] Allows you to choose options for reactions to a full SEL. Configuration options: [Do Nothing] [Erase Immediately] RS720Q-E9-RS8 Series 5-37...

  • Page 110: Bmc Network Configuration

    5.8.2 BMC network configuration The sub-items in this configuration allow you to configure the BMC network parameters. Navigate to the second page of the screen to see the rest of items in this menu by pressing the Up or Down arrow keys. To quickly go to the last item of the second page, press the Page Down button. Press the Page Up button to go back to the first item in the first page. IPV4 DM_LAN1/ Shared LAN Config Address source [Previous State] This item allows you to configure LAN channel parameters statistically or dynamically (by BIOS or BMC). Unspecified option will not modify any BMC network parameters during BIOS phase.

  • Page 111: View System Event Log

    Config Address source [Previous State] This item allows you to configure LAN channel parameters statistically or dynamically (by BIOS or BMC). Unspecified option will not modify any BMC network parameters during BIOS phase. Configuration options: [Previous State] [Static] [DynamicBmcDhcp] [DynamicBmcNonDhcp] 5.8.3 View System Event Log This item allows you to view the system event log records. RS720Q-E9-RS8 Series 5-39...

  • Page 112: Security Menu

    Security menu This menu allows a new password to be created or a current password to be changed. The menu also enables or disables the Secure Boot state and lets the user configure the System Mode state. Administrator Password To set an administrator password: 1. Select the Administrator Password item and press <Enter>. 2. From the Create New Password box, key in a password, then press <Enter>. 3. Confirm the password when prompted. To change an administrator password: 1.
  • Page 113 Secure Boot can be enabled if the system is running in User mode with enrolled platform Key (EPK) or if the CSM function is disabled. Configuration options: [Disabled] [Enabled] Secure Boot Mode [Custom] Allows you to set the Secure Boot selector. Configuration options: [Custom] [Standard] RS720Q-E9-RS8 Series 5-41...
  • Page 114 Key Management This item only appears when the item Secure Boot Mode is set to [Custom]. The Key Management item allows you to modify Secure Boot variables and set Key Management page. Provision Factory Defaults [Disabled] Allows you to provision factory default Secure Boot keys when the system is in Setup Mode. Configuration options: [Disabled] [Enabled] Install Factory Default keys This item will install all Factory Default keys. Reset to Setup Mode This item appears only when you load the default Secure Boot keys. This item allows you to clear all default Secure Boot keys. Enroll Efi Image This item will allow the image to run in Secure Boot mode. Save All Secure Boot Variables This item will ask you if you want to save all secure boot variables. Select Yes if you want to save all secure boot variables, otherwise select No.

  • Page 115: Boot Menu

    • To select the boot device during system startup, press <F8> when ASUS Logo appears. • To access Windows OS in Safe Mode, please press <F8> after POST. Network Device BBS Priorities / Hard Drive BBS Priorities These items allow you to set the booting order of the devices. RS720Q-E9-RS8 Series 5-43...

  • Page 116: Tool Menu

    <Enter> to display the submenu. IPMI HWM Allows you to run the IPMI hardware monitor. Start EzFlash Allows you to run ASUS EzFlash BIOS ROM Utility when you press <Enter>. Refer to the ASUS EzFlash Utility section for details. 5.12 Save & Exit menu The Exit menu items allow you to save or discard your changes to the BIOS items.
  • Page 117 Boot Override These items displays the available devices. The device items that appears on the screen depends on the number of devices installed in the system. Click an item to start booting from the selected device. Launch EFI Shell from filesystem device This item allows you to attempt to launch the EFI Shell application (shellx64.efi) from one of the available filesystem devices. RS720Q-E9-RS8 Series 5-45...
  • Page 118 5-46 Chapter 5: BIOS Setup...

  • Page 119: Chapter 6: Raid Configuration

    Chapter 6: RAID Configuration RAID Configuration This chapter provides instructions for setting up, creating, and configuring RAID sets using the available utilities.

  • Page 120: Setting Up Raid

    Setting up RAID ® The motherboard supports the Intel Rapid Storage Technology enterprise Option ROM Utility with RAID 0, RAID 1, RAID 10, and RAID 5 support (for Windows OS and Linux). 6.1.1 RAID definitions RAID 0 (Data striping) optimizes two identical hard disk drives to read and write data in parallel, interleaved stacks.

  • Page 121: Intel ® Virtual Raid On Cpu In Bios

    Go to the Advanced menu > CSM Configuration, then press <Enter> to display the CSM Configuration menu. Refer to Chapter 5 for details on entering and navigating through the BIOS Setup. Select the [Disable] option for the CSM Support option in the CSM Configuration menu. RS720Q-E9-RS8 Series...

  • Page 122: Creating A Raid Set

    Go to the Save & Exit menu > Save Changes and Reset, or press <F10> to save and reset. Enter the BIOS Setup again during POST. Go to the Advanced menu > Intel(R) Virtual Raid on CPU > All Intel VMD ®...

  • Page 123: Deleting A Raid Set

    <Enter>. The following screen appears: When the Delete item is selected, press <Enter>, then select Yes to delete the RAID volume and return to the Intel Virtual Raid on CPU menu, or select No to cancel. ® RS720Q-E9-RS8 Series...

  • Page 124: Intel ® Rapid Storage Technology Enterprise (Windows)

    ® Intel Rapid Storage Technology enterprise (Windows) The Intel Rapid Storage Technology enterprise allows you to create RAID 0, RAID 1, RAID ® 10 (RAID 1+0), and RAID 5 set(s) from Serial ATA hard disk drives that are connected to the Serial ATA connectors supported by the Southbridge.

  • Page 125: Creating A Raid Set

    Select Volume Size tab, you can drag the bar to decide the volume size. Click Next. • If you do not want to keep the data on one of the selected disks, select NO when prompted. • If you want to Enable volume write-back cache or Initialize volume, click Advanced. RS720Q-E9-RS8 Series...
  • Page 126 Confirm the volume creation, than click Create Volume to continue. This process could take a while depending on the number and size of the disks. You can continue using other applications during this time. Wait until the process is completed, then click OK when prompted. You still need to partition your new volume using Windows Disk Management before adding any data.

  • Page 127: Changing A Volume Type

    OK. The available stripe size values range from 4 KB to 128 KB. The following are typical values: RAID 0: 128KB RAID 10: 64KB RAID 5: 64KB We recommend a lower stripe size for server systems, and a higher stripe size for multimedia computer systems used mainly for audio and video editing. RS720Q-E9-RS8 Series...

  • Page 128: Deleting A Volume

    6.3.3 Deleting a volume Be cautious when deleting a volume. You will lose all data on the hard disk drives. Before you proceed, ensure that you back up all your important data from your hard drives. To delete a volume: From the utility main menu, select the volume (ex.

  • Page 129: Preferences

    Allow you to set to show the notification area icon and show system information, warning, or errors here. E-Mail Preferences Allow you to set to sent e-mail of the following events: • Storage system information • Storage system warnings • Storage system errors RS720Q-E9-RS8 Series 6-11...
  • Page 130 6-12 Chapter 6: RAID Configuration...
  • Page 131 Chapter 7: Driver Installation Driver Installation This chapter provides the instructions for installing the necessary drivers for different system components in both ® ® Linux and Windows Operating Systems.

  • Page 132: Intel Rste Raid Driver Installation

    Intel RSTe RAID driver installation After creating the RAID sets for your server system, you are now ready to install an operating system to the independent hard disk drive or bootable array. This part provides the instructions on how to install the RAID controller drivers during OS installation. 7.1.1 Creating a USB flash drive with RAID driver When installing Windows...
  • Page 133 Windows OS installation disc and replace with the motherboard Support DVD into the optical drive. Click Browse to continue. Locate the driver in the corresponding folder of the Support DVD then click OK to continue. Select the RAID controller driver you need from the list and click Next. RS720Q-E9-RS8 Series...
  • Page 134 When the system finishes loading the RAID driver, replace the motherboard Support DVD with the Windows Server installation disc. Select the drive to install Windows and click Next. Setup then proceeds with the OS installation. Follow screen instructions to continue. Chapter 7: Driver Installation...

  • Page 135: Management Applications And Utilities Installation

    The contents of the support DVD are subject to change at any time without notice. Visit the ASUS website (www.asus.com) for the latest updates on software and utilities. Running the Support DVD When you place the support DVD into the optical drive, the DVD automatically displays the main screen if Autorun is enabled in your computer.
  • Page 136 7.3.1 Drivers menu tab The Drivers Menu shows the available device drivers if the system detects installed devices. Install the necessary drivers to activate the devices. 7.3.2 Utilities menu tab The Utilities menu displays the software applications and utilities that the motherboard supports. Chapter 7: Driver Installation...
  • Page 137 You need an internet browser installed in your OS to view the User Guide. 7.3.4 Contact information menu The Contact menu displays the ASUS contact information, e-mail addresses, and useful links if you need more information or technical support for your motherboard. RS720Q-E9-RS8 Series...

  • Page 138: Intel ® Chipset Device Software Installation

    Intel chipset device software installation ® This section provides the instructions on how to install the Intel chipset device software on ® the system. You need to manually install the Intel chipset device software on a Windows operating ® system. To install the Intel chipset device software: ®...
  • Page 139 Read the License Agreement and click Accept to continue the process. Read the Readme File Information and click Install to start the installation process. Click Restart Now to complete the setup process. RS720Q-E9-RS8 Series...

  • Page 140: Installing The Intel ® I350-Am2/I210 Gigabit Adapters Driver

    ® Installing the Intel I350-AM2/I210 Gigabit Adapters driver This section provides the instructions on how to install the Intel I350-AM2/I210 Gigabits ® Adapter Driver on the system. To install the Intel I350-AM2/I210 Gigabit Adapters Driver on the Windows operating ® ®...
  • Page 141 Tick I accept the terms in the license agreement and click Next to continue. From the Setup Options window, click Next to start the installation. By default, Intel(R) PROSet for Windows Device Manager and Windows PowerShell Module are ticked. RS720Q-E9-RS8 Series 7-11...
  • Page 142 Click Install to start the installation. When the installation is done, press Finish to complete the installation. 7-12 Chapter 7: Driver Installation...

  • Page 143: Vga Driver Installation

    If Autorun is NOT enabled in your computer, browse the contents of the support DVD to locate the file ASSETUP.EXE from the BIN folder. Double-click the ASSETUP.EXE to run the support DVD. Click the ASPEED AST2500 Display Driver to begin installation. From the installation window, click Next to start the installation. RS720Q-E9-RS8 Series 7-13...
  • Page 144 Click Install to start the installation process. Click Finish to complete the installation. 7-14 Chapter 7: Driver Installation...

  • Page 145: Intel ® Rapid Storage Technology Enterprise 5.0 Installation

    Insert the motherboard/system support DVD into the optical drive, and navigate to the Utilities menu. ® Click the Intel Rapid Storage Technology enterprise to begin installation. ® The Intel Rapid Storage Technology enterprise window appears. Click Next to start the installation. RS720Q-E9-RS8 Series 7-15...
  • Page 146 Read the Warning message and click Next to continue. Read the License Agreement and click Accept to continue the process. Select the destination folder and click Next to continue. 7-16 Chapter 7: Driver Installation...
  • Page 147 Tick the features that you would like to install and click Next to continue. Click Install to start the installation process. Click Restart Now to complete the setup process. RS720Q-E9-RS8 Series 7-17...
  • Page 148 7-18 Chapter 7: Driver Installation...

  • Page 149: Appendix

    Appendix Appendix...

  • Page 150: Z11Ph-D12 Block Diagram

    Z11PH-D12 block diagram Appendix...

  • Page 151: Asus Contact Information

    ASUS contact information ASUSTeK COMPUTER INC. Address 4F, No. 150, Li-Te Rd., Peitou, Taipei 112, Taiwan Telephone +886-2-2894-3447 +886-2-2890-7798 Web site https://www.asus.com Technical Support Telephone +86-21-38429911 +86-21-58668722 ext: 9101 Online Support https://www.asus.com/support/Product/ContactUs/Services/ questionform/?lang=en ASUSTeK COMPUTER INC. (Taiwan) Address 4F, No. 150, Li-Te Rd., Peitou, Taipei 112, Taiwan...
  • Page 152 +1-510-608-4555 Web site https://www.asus.com/us/ Technical Support Support fax +1-812-284-0883 General support +1-812-282-2787 Online support https://www.asus.com/support/Product/ContactUs/Services/ questionform/?lang=en-us ASUS COMPUTER GmbH (Germany and Austria) Address Harkort Str. 21-23, 40880 Ratingen, Germany +49-2102-959911 Web site https://www.asus.com/de/ Technical Support Telephone +49-1805-010923 Support Fax +49-2102-959911 Online support https://www.asus.com/support/Product/ContactUs/Services/...
  • Page 153 Marconistraat 2, 7825GD EMMEN, The Netherlands Web site https://www.asus.com/nl/ Technical Support Telephone +31-(0)591-5-70292 +31-(0)591-666853 E-mail advance.rma.eu@asus.com Online Support https://www.asus.com/support/Product/ContactUs/Services/ questionform/?lang=nl-nl ASUS Polska Sp. z o.o. (Poland) Address Ul. Postępu 6, 02-676 Warszawa, Poland Web site https://www.asus.com/pl/ Technical Support Telephone +48-225718033 Online Support https://www.asus.com/support/Product/ContactUs/Services/ questionform/?lang=pl-pl ASK-Service (Russia and CIS) г.Москва, ул.
  • Page 154 Appendix...

Table of Contents
