Asus RS720-E8-RS24-ECP User Manual

2u rackmount server
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RS720-E8-RS24-ECP
2U Rackmount Server
User Guide

Advertisement

Table of Contents
loading

Related Manuals for Asus RS720-E8-RS24-ECP

Summary of Contents for Asus RS720-E8-RS24-ECP

  • Page 1 RS720-E8-RS24-ECP 2U Rackmount Server User Guide...
  • Page 2 ASUSTeK COMPUTER INC. (“ASUS”). ASUS provides this manual “as is” without warranty of any kind, either express or implied, including but not limited to the implied warranties or conditions of merchantability or fitness for a particular purpose. In no...

  • Page 3: Table Of Contents

    Contents Notices ........................vii Safety information ....................viii Australia statement notice ................ix About this guide ......................x Chapter 1: Product Introduction System package contents ................. 1-2 Serial number label ..................1-3 System specifications ................1-4 Front panel features ................... 1-6 Rear panel features ..................
  • Page 4 BIOS Setup Managing and updating your BIOS ............5-2 5.1.1 ASUS CrashFree BIOS 3 utility........... 5-2 5.1.2 ASUS EZ Flash 2 Utility .............. 5-3 5.1.3 BUPDATER utility ............... 5-4 BIOS setup program .................. 5-6 5.2.1 BIOS menu screen ..............5-7 5.2.2...
  • Page 5 Contents IntelRCSetup menu .................. 5-24 5.5.1 Processor Configuration............5-25 5.5.2 Advanced Power Management Configuration......5-27 5.5.3 Common RefCode Configuration ..........5-27 5.5.4 QPI Configuration..............5-28 5.5.5 Memory Configuration ............... 5-29 5.5.6 IIO Configuration ............... 5-31 5.5.7 PCH Configuration ..............5-32 5.5.8 Miscellaneous Configuration .............
  • Page 6 Contact information menu ............7-16 ® Intel chipset device software installation ..........7-17 ® Installing the Intel I350-AM1/I350-AM2/I210/X540-BT2 Gigabit Adapters Driver ................7-19 VGA driver installation ................7-22 ® Intel Rapid Storage Technology enterprise 4.0 installation ....7-24 Appendix ASUS contact information ..................A-2...

  • Page 7: Notices

    Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. REACH Complying with the REACH (Registration, Evaluation, Authorization, and Restriction of Chemicals) regulatory framework, we publish the chemical substances in our products at ASUS REACH website at http://csr.asus.com/english/REACH.htm.

  • Page 8: Safety Information

    Safety information Electrical Safety • Before installing or removing signal cables, ensure that the power cables for the system unit and all attached devices are unplugged. • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.

  • Page 9: Australia Statement Notice

    If you require assistance please call ASUS Customer Service 1300 2787 88 or visit us at https://www.asus.com/support/.

  • Page 10: About This Guide

    About this guide Audience This user guide is intended for system integrators, and experienced users with at least basic knowledge of configuring a server. Contents This guide contains the following parts: Chapter 1: Product Introduction This chapter describes the general features of the server, including sections on front panel and rear panel specifications.
  • Page 11 Refer to the following sources for additional information, and for product and software updates. ASUS Server Web-based Management (ASWM) user guide This manual tells how to set up and use the proprietary ASUS server management utility. ASUS websites The ASUS websites worldwide provide updated information for all ASUS hardware and...

  • Page 13: Chapter 1: Product Introduction

    Chapter 1: Product Introduction Product Introduction This chapter describes the general features of the server, including sections on front panel and rear panel specifications.

  • Page 14: System Package Contents

    1 x Standard Friction Rail Kit 1 x Additional 800W Redundant Power Supply (80 PLUS Platinum) Optional Items 1 x ASUS PIKE II 3008 8-port SAS HBA card 1 x ASUS PIKE II 3108 8-port HW RAID card *ASUS System Web-based Management If any of the above items is damaged or missing, contact your retailer.

  • Page 15: Serial Number Label

    Serial number label Before requesting support from the ASUS Technical Support team, take note of the product’s 12-character serial number as seen in the example xxS0xxxxxxxx below. With the correct serial number of the product, ASUS Technical Support team members can quickly identify the server model and provide a satisfactory solution to your technical issue.

  • Page 16: System Specifications

    System specifications The ASUS RS720-E8-RS24-ECP is a 2U barebone server system featuring the ASUS ® ® ® Z10PE-D16 Server Board. The server supports Intel LGA2011-3 Intel Xeon E5-2600 Processor v3 plus other latest technologies through the chipsets onboard. Model Name...

  • Page 17: Power Supply

    The power rating and setting may vary depending on countries and regions. Operating temperature: 10°C – 35°C Environment Non operating temperature: -40°C – 70°C Non operating humidity: 20% – 90% (Non condensing) *Specifications are subject to change without notice. ASUS RS720-E8-RS24-ECP...

  • Page 18: Front Panel Features

    Front panel features The barebone server displays a simple yet stylish front panel with easily accessible features. The power and reset buttons, LED indicators, and USB ports for each Node are located on the front panel. Refer to section 1.7.1 Front panel LEDs for the LED descriptions. Asset tag The Asset tag is a simple but useful device that is conveniently located on the front panel of the server that you can pull out or easily slide back in.

  • Page 19: Rear Panel Features

    PS/2 keyboard/mouse combo port Management LAN port* Expansion card back plate Redundant power supply SSD Bay Serial port (Optional) Power connector Gigabit LAN port Gigabit LAN port This port is for ASUS ASMB8-iKVM controller and for technicians only. ASUS RS720-E8-RS24-ECP...

  • Page 20: Internal Features

    Internal features The barebone server includes the basic components as shown. Redundant power supply ASUS Z10PE-D16 server board Front panel system fans SATA/SAS back panel (hidden) HDD bays (24 x 2.5-inch) Front panel (hidden) 2 x SSD bays Asset Tag (hidden) Turn off the system power and detach the power supply before removing or replacing any system component.

  • Page 21: Led Information

    With the onboard ASMB8-iKVM: a hardware monitor event is indicated No LAN connection LAN LEDs Blinking LAN is transmitting or receiving data LAN connection is present Location switch is pressed Location Normal status (Press the location switch again to turn off) ASUS RS720-E8-RS24-ECP...

  • Page 22: Hdd & Ssd Leds

    1.7.2 HDD & SSD LEDs HDD LEDs HDD status LED HDD activity LED SSD LEDs SSD LEDs function only when a SSD is installed. SSD activity LED SSD status LED Chapter 1: Product Introduction 1-10...

  • Page 23: Lan (Rj-45) Leds

    LAN (RJ-45) LEDs SPEED LED ACT/LINK LED SPEED LED ACT/LINK LED ACT/LINK LED SPEED LED Status Description Status Description No link 10 Mbps connection GREEN Linked ORANGE 100 Mbps connection BLINKING Data activity GREEN 1 Gbps connection ASUS RS720-E8-RS24-ECP 1-11...
  • Page 24 Chapter 1: Product Introduction 1-12...

  • Page 25: Chapter 2: Hardware Information

    Chapter 2: Hardware Information Hardware Information This chapter lists the hardware setup procedures that you have to perform when installing or removing system components.

  • Page 26: Chassis Cover

    Chassis cover 2.1.1 Removing the rear cover Loosen the two screws on the rear panel to release the rear cover from the chassis. Loosen the screws without removing them. Use a screwdriver to remove the four screws on the sides. Push the cover backward to release it from the chassis.

  • Page 27: Air Duct

    Secure the screws with a Phillips screwdriver to install the air duct to the motherboard. • Do not force to fasten the screws to prevent damaging the motherboard and the air duct. • Ensure the air duct is firmly installed on the motherboard. ASUS RS720-E8-RS24-ECP...

  • Page 28: Central Processing Unit (Cpu)

    Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components. ASUS shoulders the repair cost only if the damage is shipment/transit- related.
  • Page 29 To prevent damage to the socket pins, do not remove the PnP cap unless you are installing a CPU. Load lever Press the right load lever (D) and move it to the left (E) until it is released from the retention tab. Gently lift the load lever until it is fully extended (F). ASUS RS720-E8-RS24-ECP...
  • Page 30 Gently push the left load lever down to slightly lift the load plate (G). edge of the Load plate Do not insert the load lever into the retention tab. Hold the edge and gently lift the load plate (H). Load plate Prepare the CPU.
  • Page 31 The PnP cap pops out of the load plate when the right load lever is inserted into the retention tab. Keep the PnP cap. ASUS will process Return Merchandise Authorization (RMA) requests only if the motherboard comes with the PnP cap on the LGA 2011-3 socket.
  • Page 32 Apply some Thermal Interface Material to the exposed area of the CPU that the heatsink will be in contact with. Some heatsinks come with pre-applied Thermal Interface Material. If so, skip this step. The Thermal Interface Material is toxic and inedible. DO NOT eat it. If it gets into your eyes or touches your skin, wash it off immediately and seek professional medical help.

  • Page 33: Installing Cpu Heatsink

    Use a Phillips screwdriver to secure the screws until the heatsink sits just on the CPU. Fasten the screws in a diagonal sequence (refer to the illustration below) to secure the heatsink in place. illustration above. Fasten the 4 screws according to the sequence in the ASUS RS720-E8-RS24-ECP...

  • Page 34: System Memory

    NVDIMM into the DIMM sockets using the memory configurations in this section. • Refer to the ASUS AVL for the latest memory information. • To install a DIMM under single CPU configuration, install the DIMM in slot A1 or B1.
  • Page 35 4 DIMMs 8 DIMMs Dual CPU configuration You can refer to the following recommended memory population for a dual CPU configuration. Dual CPU configuration DIMM (CPU1) DIMM (CPU2) 2 DIMMs 4 DIMMs 8 DIMMs 12 DIMMs 16 DIMMs ASUS RS720-E8-RS24-ECP 2-11...

  • Page 36: Installing A Dimm

    2.4.3 Installing a DIMM Ensure to unplug the power supply before adding or removing DIMMs or other system components. Failure to do so may cause severe damage to both the motherboard and the components. DIMM notch Unlock a DIMM socket by pressing the retaining clips outward.

  • Page 37: Hard Disk Drives

    Tray lever Release the screws on each side of the metal beam drive tray to release the drive tray metal beam. The metal beam supports the drive tray horizontally to prevent the drive tray from benting or deforming. ASUS RS720-E8-RS24-ECP 2-13...
  • Page 38 Place a 2.5-inch HDD into the drive tray. Ensure that the four screw holes of the HDD match the screw holes on the drive tray. HDD screw hole Drive tray screw hole Secure the drive tray with four screws (2 screws on each side). Carefully insert the 2.5-inch SATA/ SAS drive tray and push it all the way to the depth of the bay.
  • Page 39 Release the screws on each side of metal beam the drive tray to release the drive tray metal beam. The metal beam supports the drive tray horizontally to prevent the drive tray from benting or deforming. ASUS RS720-E8-RS24-ECP 2-15...
  • Page 40 Orient and place the SSD into the tray. Ensure that the SSD is fitted firmly inside the drive tray and the four screws of the SSD match the four screws holes of the drive tray. SSD screw hole Drive tray screw hole Carefully insert the drive tray and push it all the way to the depth of the bay.

  • Page 41: Expansion Slot

    Remove the two screws securing the slot cover plate and put them aside for future use. Remove the cover plate. cover plate Remove the screw securing the metal cover to the chassis. Remove the metal cover and set it aside for future use. metal cover ASUS RS720-E8-RS24-ECP 2-17...
  • Page 42 Insert the expansion card into the slot. Ensure that the golden fingers are totally inserted into the slot. Secure it with the screw removed in step 4. Reinstall the cover plate. Secure it with the two screws removed in step 2. Chapter 2: Hardware Information 2-18...

  • Page 43: Configuring An Expansion Card

    ACPI Mode when used IRQ Holder for PCI Steering IRQ Holder for PCI Steering PS/2 Compatible Mouse Port Numeric Data Processor Primary IDE Channel Secondary IDE Channel * These IRQs are usually available for ISA or PCI devices. ASUS RS720-E8-RS24-ECP 2-19...

  • Page 44: Installing An M.2 Expansion Card

    2.6.3 Installing an M.2 expansion card You can install an M.2 expansion card to the provided M.2 slot onboard. To install an M.2 expansion card: Locate the M.2 (NGFF1) socket on the motherboard. Remove the screw on the M.2 socket and put it aside.

  • Page 45: Cable Connections

    System panel connector (from motherboard to front I/O board) SATA ports connectors (from motherboard to SATA/SAS backplane) USB connector (from motherboard to front I/O board) SATA connectors (from motherboard to SATA/SAS backplane) 4-pin EATX12V power connector (from power supply to motherboard) ASUS RS720-E8-RS24-ECP 2-21...

  • Page 46: System Fans

    2.8. System fans This server is equipped with 4 easily removable front system fans (80 x 80 x 38 mm) providing the best thermal resolution to the system. • Ensure that the system is turned off before removing any components. •...
  • Page 47 Align and position the fan with the arrow on the fan pointing to the back of the chassis (C). Install the fan to the fan cage. The fan can only be installed in one direction. If the fan cannot be installed, turn it around and try again. ASUS RS720-E8-RS24-ECP 2-23...

  • Page 48: Redundant Power Supply Module

    Redundant power supply module The server system can support up to two 800W 80Plus Platinum redundant power supply module. You can purchase and install the second redundant power supply module if there is only one power supply module in your system. •...

  • Page 49: Chapter 3: Installation Options

    Chapter 3: Installation Options Installation Options This chapter describes how to install the optional components and devices into the barebone server.

  • Page 50: Tool-Less Friction Rail Kit

    Tool-less Friction Rail Kit The tool less design of the rail kit allows you to easily install the rack rails into the server rack without the need for additional tools. The kit also comes with a metal stopping bracket that can be installed to provide additional support and stability to the server.
  • Page 51 Press the spring lock on the other end of rail then insert the stud into the mounting hole on the rack post. Extend the rack rail, if necessary. (Optional) Use the rail screw and rail washer that comes with the kit to secure the rack rail to the rack post (B). Perform step 3 to 4 for the other rack rail. Ensure that the installed rack rails (left and right) are aligned, secured, and stable in place. ASUS RS720-E8-RS24-ECP...
  • Page 52 Lift the server chassis and insert into the rack rail. • Ensure that the rack rail cabinet and the rack posts are stable and standing firmly on a level surface. • We strongly recommend that at least two able-bodied persons perform the steps described in this guide. • We recommend the use of an appropriate lifting tool or device, if necessary. RS720-E8-RS24-ECP Front View The circles in the illustration above indicate the screw holes hidden behind the lever. When mounting the server, use a Phillips screwdriver to secure the server chassis on the rack. Chapter 3: Installation Options...

  • Page 53: Chapter 4: Motherboard Information

    Chapter 4: Motherboard Information Motherboard Information This chapter includes the motherboard layout and brief descriptions of the jumpers and internal connectors.

  • Page 54: Motherboard Layout

    Motherboard layout Layout contents Jumpers Page 1. Clear RTC RAM (CLRTC1) 2. VGA controller setting (3-pin VGA_SW1) 3. LAN controller setting (3-pin LAN_SW1-4) 4. PMBus 1.2 PSU select jumper (3-pin SMART_PSU1) 5. ME firmware force recovery setting (3-pin ME_RCVR1) 6. DDR4 thermal event setting (3-pin DIMMTRIP1) 7. RAID configuration utility selection (3-pin RAID_SEL1) 8. BMC Setting (3-pin BMC_EN1) Chapter 4: Motherboard Information...
  • Page 55 2. Baseboard Management Controller LED (BMCLED1) 4-19 3. CPU Warning LED (ERRCPU1, ERRCPU2) 4-20 4. Power LED (P5VLED1) 4-20 5. Location LED (LOCLED2) 4-21 6. D IMM warning LED (MEMERRA1-A2, MEMERRB1-B2, MEMERRC1-C2, MEMERRD1-D2, MEMERRE1-E2, MEMERRF1-F2, 4-21 MEMERRG1-G2, MEMERRH1-H2) 7. CATT LED (CATTERR1) 4-22 8. Q-Code LEDs 4-22 ASUS RS720-E8-RS24-ECP...

  • Page 56: Jumpers

    Jumpers Clear RTC RAM (3-pin CLRTC1) This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS which includes system setup information such as system passwords. To erase the RTC RAM: Turn OFF the computer and unplug the power cord. M ove the jumper cap from the default pins 1–2 to pins 2–3. Keep the cap on pins 2–3 for about 5 to 10 seconds, then move the cap back to pins 1–2. Plug the power cord and turn ON the computer. H old down the <Del> key during the boot process and enter BIOS setup to re- enter data. DO NOT remove the cap on CLRTC jumper default position except when clearing the RTC RAM. Removing the cap will cause system boot failure! If the steps above do not help, remove the onboard battery and move the jumper again to clear the CMOS RTC RAM data. After the CMOS clearance, reinstall the battery. Chapter 4: Motherboard Information...

  • Page 57: Vga Controller Setting (3-Pin Vga_Sw1)

    VGA controller setting (3-pin VGA_SW1) This jumper allows you to enable or disable the onboard VGA controller. Set to pins 1–2 to activate the VGA feature. LAN controller setting (3-pin LAN_SW1-4) These jumpers allow you to enable or disable the onboard LAN_SW1, LAN_SW2 for I350-AM2; LAN_SW3, LAN_SW4 for I350-BT2 LAN controllers. Set to pins 1–2 to activate the Gigabit LAN feature. ASUS RS720-E8-RS24-ECP...

  • Page 58: Pmbus 1.2 Psu Select Jumper (3-Pin Smart_Psu1)

    PMBus 1.2 PSU select jumper (3-pin SMART_PSU1) This jumper allows you to select PSU PMBus version. Set to pins 1–2 for PMBus, set to pins 2–3 for others. ME firmware force recovery setting (3-pin ME_RCVR1) ® This jumper allows you to force Intel Management Engine (ME) boot from recovery mode when ME becomes corrupted. Chapter 4: Motherboard Information...

  • Page 59: Ddr4 Thermal Event Setting (3-Pin Dimmtrip1)

    DDR4 thermal event setting (3-pin DIMMTRIP1) This jumper allows you to enable or disable DDR4 DIMM thermal sensing event pin. RAID configuration utility selection (3-pin RAID_SEL1) This jumper allows you to select the RAID configuration utility to use when you create disk arrays. Place the jumper caps over pins 1–2 to use the third party software LSI MegaRAID software RAID Configuration Utility; otherwise, place the jumper caps to ® pins 2–3 to use the Intel Rapid Storage Technology enterprise SATA Option ROM Utility. ASUS RS720-E8-RS24-ECP...

  • Page 60: Bmc Setting (3-Pin Bmc_En1)

    BMC Setting (3-pin BMC_EN1) This jumper allows you to enable or disable the Baseboard Management Controller (ASMB8). Chapter 4: Motherboard Information...

  • Page 61: Internal Connectors

    (7-pin SATA1-6 [Light Blue], SSATA1-3 [Gray], SSATA4 [Light Gray]) ® Supported by the Intel C612 series Chipset, these connectors are for the Serial ATA signal cables for Serial ATA hard disk drives that allows up to 6 Gbps of data transfer rate. If you installed Serial ATA hard disk drives, you can use a software RAID solution to create a RAID 0, RAID 1, RAID 5, or a RAID 10 configuration. For more information on the SATA RAID solutions supported on this motherboard, refer to the RAID Configuration chapter of this user guide. • The actual data transfer rate depends on the speed of Serial ATA hard disks installed. • The SSATA4 [Light Gray] will be automatically turned off if the M.2 connector (NGFF) is occupied. ASUS RS720-E8-RS24-ECP...

  • Page 62: Ngff) Connector (Ngff1)

    M.2 (NGFF) connector (NGFF1) This connector allows you to install an M.2 device. This connector supports type 2242 devices on both PCI-E and SATA interface. The M.2 (NGFF) device is purchased separately. USB 2.0 connector (10-1 pin USB56) These connectors are for USB 2.0 ports. Connect the USB module cables to connectors USB56. These USB connectors comply with USB 2.0 specification that supports up to 480 Mb/s connection speed. 4-10 Chapter 4: Motherboard Information...

  • Page 63: Usb 3.0 Connector (20-1 Pin Usb3_34)

    CPU, front, and rear fan connectors (4-pin CPU_FAN1-2, FRNT_FAN1-5, REAR_FAN1-2) The fan connectors support cooling fans. Connect the fan cables to the fan connectors on the motherboard, ensuring that the black wire of each cable matches the ground pin of the connector. • DO NOT forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components. • These are not jumpers! DO NOT place jumper caps on the fan connectors! • All fans feature the ASUS Smart Fan technology. 4-11 ASUS RS720-E8-RS24-ECP...

  • Page 64: S Erial General Purpose Input/Output Connector

    Serial General Purpose Input/Output connector (6-1 pin SGPIO1/SSGPIO1) The SGPIO1/SSGPIO1 connectors are used for the Intel Rapid Storage Technology Enterprise SGPIO interface that controls the LED pattern generation, device information, and general purpose data. SGPIO1 is the jumper for SATA1-6 while SSGPIO1 is the jumper for SSATA1-4. 10G LAN LED connector (5-1 pin LAN34_LED1) These leads are for 10G LAN activity LEDs on the front panel. Connect the LAN LED cable to the backplane for LAN activity indication. 4-12 Chapter 4: Motherboard Information...

  • Page 65: Power Supply Smbus Connector (5-Pin Psusmb1)

    This connector allows you to connect SMBus (System Management Bus) to the PSU (power supply unit) to read PSU information. Devices communicate with an SMBus host and/or other SMBus devices using the SMBus interface. This connector functions only when you enable the ASUS ASMB8. Power supply is required to meet PMBus specification and customized BMC FW may be needed. Please contact ASUS if your need further support. Serial port connector (10-1 pin COM1) This connector is for the serial COM port. Connect the serial port module cable to one of these connectors, then install the module to a slot opening at the back of the system chassis. 4-13...

  • Page 66: Trusted Platform Module Connector (20-1 Pin Tpm1)

    Trusted Platform Module connector (20-1 pin TPM1) This connector supports a Trusted Platform Module (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures platform integrity. VGA connector (10-1 pin VGA_HDR1) This connector supports the VGA High Dynamic-Range interface. 4-14 Chapter 4: Motherboard Information...

  • Page 67: Atx Power Connectors

    ATX power connectors (24-pin EATXPWR1, 8-pin EATX12V1, 8-pin EATX12V2, 4-pin EATX12V_NVDIMM1) These connectors are for the ATX power supply plugs. The power supply plugs are designed to fit these connectors in only one orientation. Find the proper orientation and push down firmly until the connectors completely fit. • DO NOT forget to connect the 24-pin and the 8-pin power plugs; otherwise, the system will not boot up. • Use of a power supply unit (PSU) with a higher power output is recommended when configuring a system with more power-consuming devices. The system may become unstable or may not boot up if the power is inadequate. • This motherboard supports ATX2.0 PSU or later version. • The 4-pin EATX12V_NVDIMM1 is only required for NVDIMM. • Ensure that your PSU can provide at least the minimum power required by your system. 4-15 ASUS RS720-E8-RS24-ECP...

  • Page 68: System Panel Connector (20-1 Pin Panel1)

    System panel connector (20-1 pin PANEL1) This connector supports several chassis-mounted functions. System power LED (3-pin PLED) This 3-pin connector is for the system power LED. Connect the chassis power LED cable to this connector. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode. Message LED (2-pin MLED) This 2-pin connector is for the message LED cable that connects to the front message LED. The message LED is controlled by Hardware monitor to indicate an abnormal event occurance. System warning speaker (4-pin SPEAKER) This 4-pin connector is for the chassis-mounted system warning speaker. The speaker allows you to hear system beeps and warnings.

  • Page 69: Auxiliary Panel Connector (20-2 Pin Aux_Panel1)

    LAN activity LED (2-pin LAN1_LINKACTLED, LAN2_LINKACTLED) These connectors are for Gigabit LAN activity LEDs on the front panel. Locator LED (2-pin LOCATORLED1, LOCATORLED2) These connectors are for the locator LED1 and LED2 on the front panel. Connect the Locator LED cables to these 2-pin connector. The LEDs will light up when the Locator button is pressed. Locator Button/Switch (2-pin LOCATORBTN#) These connectors are for the locator button on the front panel. This button queries the state of the system locator. 4-17 ASUS RS720-E8-RS24-ECP...

  • Page 70: Hard Disk Activity Led Connector (4-Pin Hdled1)

    Hard disk activity LED connector (4-pin HDLED1) This LED connector is for the storage add-on card cable connected to the SATA or SAS add-on card. The read or write activities of any device connected to the SATA or SAS add-on card causes the front panel LED to light up. Chassis Intrusion (2-pin INTRUSION1) These leads are for the intrusion detection feature for chassis with intrusion sensor or microswitch. When you remove any chassis component, the sensor triggers and sends a high level signal to these leads to record a chassis intrusion event. The default setting is short CHASSIS# and GND pin by jumper cap to disable the function.

  • Page 71: Onboard Leds

    Onboard LEDs Standby Power LED (SBPWR1) The motherboard comes with a standby power LED. The green LED lights up to indicate that the standby mode of the system is ON, the system is in sleep mode, or the system is in soft-off mode. This is a reminder that you should shut down the system and unplug the power cable before removing or plugging in any motherboard component. The illustration below shows the location of the onboard LED. Baseboard Management Controller LED (BMCLED1) The green heartbeat LED blinks per second to indicate that the ASMB8 is working normally. The heartbeat LED functions only when you install the ASUS ASMB8. 4-19 ASUS RS720-E8-RS24-ECP...

  • Page 72: Cpu Warning Led (Errcpu1, Errcpu2)

    CPU Warning LED (ERRCPU1, ERRCPU2) The CPU warning LEDs light up to indicate failure on either CPU1, CPU2, or both. Power LED (P5VLED1) This LED lights up when you turn on the system using the Power-on button. 4-20 Chapter 4: Motherboard Information...

  • Page 73: Location Led (Locled2)

    Location LED (LOCLED2) This onboard LED lights up when the Location button on the server is pressed or when triggered by a system management software. The Location LED helps visually locate and quickly identify the server in error on a server rack. DIMM warning LED (MEMERRA1-A2, MEMERRB1-B2, MEMERRC1-C2, MEMERRD1-D2, MEMERRE1-E2, MEMERRF1-F2, MEMERRG1-G2, MEMERRH1-H2) The DIMM warning LEDs light up to indicate failure on the corresponding DIMMs. The warning LEDs only function when you enable the ASUS ASMB8. 4-21 ASUS RS720-E8-RS24-ECP...

  • Page 74: Catt Led (Catterr1)

    CATT LED (CATTERR1) The CATT LED indicates that the system has experienced a fatal or catastrophic error and cannot continue to operate. Q-Code LEDs (LED1) The Q-Code LED provides a 2-digit display that shows the status of your system. Refer to the Q-Code table of this user guide for more information about the 2-digit codes. 4-22 Chapter 4: Motherboard Information...
  • Page 75 Memory Init. MRC Progress Memory Init. MRC Progress Memory Init. MRC Progress Memory Init. MRC Progress Memory Init. MRC Progress Memory Init. MRC Progress Memory Init. MRC Progress Memory Init. Done MRC Progress Other config. After RC end Progress Memory already installed Progress CPU Init. Progress CPU Init. Progress CPU Init. Progress DXE Initial Program Load (IPL) 4-23 ASUS RS720-E8-RS24-ECP...
  • Page 76 Action PHASE POST CODE TYPE DESCRIPTIONS Progress DXE Core Started Progress DXE NVRAM Init. Progress SB run-time init. Progress DXE CPU Init. Progress NB Init. DXE (Driver Progress NB Init. Execution Progress NB Init. Environment) phase Progress SB Init. Progress SB Init. Progress SB Init. Progress ACPI Init. Progress CSM Init. Progress BDS started Progress Connect device event Progress...

  • Page 77: Chapter 5: Bios Setup

    Chapter 5: BIOS Setup BIOS Setup This chapter tells how to change the system settings through the BIOS Setup menus. Detailed descriptions of the BIOS parameters are also provided.

  • Page 78: Managing And Updating Your Bios

    BIOS in the future. Copy the original motherboard BIOS using the BUPDATER utility. 5.1.1 ASUS CrashFree BIOS 3 utility The ASUS CrashFree BIOS 3 is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can update a corrupted BIOS file using a USB flash drive that contains the updated BIOS file.

  • Page 79: Asus Ez Flash 2 Utility

    5.1.2 ASUS EZ Flash 2 Utility The ASUS EZ Flash 2 Utility feature allows you to update the BIOS without having to use a DOS‑based utility. Before you start using this utility, download the latest BIOS from the ASUS website at www.asus.com. To update the BIOS using EZ Flash 2 Utility: Insert the USB flash disk that contains the latest BIOS file into the USB port. Enter the BIOS setup program. Go to the Tool menu then select ASUS EZ Flash 2 Utility.

  • Page 80: Bupdater Utility

    The BUPDATER utility allows you to update the BIOS file in the DOS environment using a bootable USB flash disk drive with the updated BIOS file. Updating the BIOS file To update the BIOS file using the BUPDATER utility: Visit the ASUS website at www.asus.com and download the latest BIOS file for the motherboard. Save the BIOS file to a bootable USB flash disk drive. Copy the BUPDATER utility (BUPDATER.exe) from the ASUS support website at www.asus.com/support to the bootable USB flash disk drive you created earlier. Boot the system in DOS mode, then at the prompt, type: BUPDATER /i[filename].CAP where [filename] is the latest or the original BIOS file on the bootable USB flash disk drive, then press <Enter>. A:\>BUPDATER /i[file name].CAP Chapter 5: BIOS Setup...
  • Page 81 The utility verifies the file, then starts updating the BIOS file. ASUS Tek. EzFlash Utility Current Platform New Platform Platform : Z10PE-D16 Platform : Z10PE-D16 Version : 0301 Version : 0301 Build date: 05/13/2014 Build date: 05/13/2014 Start Programming Flash. DO NOT SHUTDOWN THE SYSTEM!!! Write DO NOT shut down or reset the system while updating the BIOS to prevent system boot failure! The utility returns to the DOS prompt after the BIOS update process is completed.

  • Page 82: Bios Setup Program

    If the system becomes unstable after changing any BIOS settings, load the default settings to ensure system compatibility and stability. Press <F5> and select Yes to load the BIOS default settings. • The BIOS setup screens shown in this section are for reference purposes only, and may not exactly match what you see on your screen. • Visit the ASUS website (www.asus.com) to download the latest BIOS file for this motherboard. Chapter 5: BIOS Setup...

  • Page 83: Bios Menu Screen

    For changing the Server Mgmt settings For changing the event log settings Event Logs Monitor F or displaying the system temperature, power status, and changing the fan settings Security For changing the security settings Boot For changing the system boot configuration Tool For configuring options for special functions Exit For selecting the exit options To select an item on the menu bar, press the right or left arrow key on the keyboard until the desired item is highlighted. ASUS RS720-E8-RS24-ECP...

  • Page 84: Menu Items

    5.2.3 Menu items The highlighted item on the menu bar displays the specific items for that menu. For example, selecting Main shows the Main menu items. The other items (Event Logs, Advanced, Monitor, Boot, Tool, and Exit) on the menu bar have their respective menu items. 5.2.4 Submenu items A solid triangle before each item on any menu screen means that the item has a submenu. To display the submenu, select the item then press <Enter>. 5.2.5 Navigation keys At the bottom right corner of the menu screen are the navigation keys for the BIOS setup program. Use the navigation keys to select items in the menu and change the settings.

  • Page 85: Main Menu

    Main menu When you enter the BIOS Setup program, the Main menu screen appears. The Main menu provides you an overview of the basic system information, and allows you to set the system date, time, language, and security settings. 5.3.1 System Date [Day xx/xx/xxxx] Allows you to set the system date. 5.3.2 System Time [xx:xx:xx] Allows you to set the system time. ASUS RS720-E8-RS24-ECP...

  • Page 86: Advanced Menu

    Advanced menu The Advanced menu items allow you to change the settings for the CPU and other system devices. Take caution when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. 5-10 Chapter 5: BIOS Setup...

  • Page 87: Acpi Settings

    Allows you to enable or disable the ability of the system to hibernate (OS/Sleep State). Configuration options: [Disabled] [Enabled] This option may be not effective with some OS. 5.4.2 Smart Settings SMART Self Test [Disabled] Allows you to run SMART Self Test on all HDDs during POST. Configuration options: [Disabled] [Enabled] ASUS RS720-E8-RS24-ECP 5-11...

  • Page 88: Nct6779D Super Io Configuration

    5.4.3 NCT6779D Super IO Configuration Serial Port 1 / Serial Port 2 Configuration Allows you to set the parameters of Serial Port 1 / Serial Port 2. Serial Port [Enabled] Allows you to enable or disable Serial Port. Configuration options: [Disabled] [Enabled] Change Settings [Auto] Allows you to choose the setting for Super IO device.

  • Page 89: Onboard Lan I350 Io Configuration

    Allows you to enable or disable the Intel LAN. Configuration options: [Disabled] [Enabled] The following items appear only when Intel LAN I350 LAN3 / LAN4 Enable is set to [Enabled]. LAN3 / LAN4 Option ROM Support [Enabled] Allows you to load the Intel LAN ROM. Configuration options: [Disabled] [Enabled] ASUS RS720-E8-RS24-ECP 5-13...

  • Page 90: Serial Port Console Redirection

    5.4.5 Serial Port Console Redirection COM1 Console Redirection [Disabled] Allows you to enable or disable the console redirection feature. Configuration options: [Disabled] [Enabled] The following item appears only when you set Console Redirection to [Enabled]. Console Redirection Settings This item becomes configurable only when you enable the Console Redirection item. The settings specify how the host computer and the remote computer (which the user is using) will exchange data.
  • Page 91 Configuration options: [Always Enable] [Bootloader] Serial Port for Out-of-Band Management/Windows Emergency Management Services (EMS) Console Redirection [Disabled] Allows you to enable or disable the console redirection feature. Configuration options: [Disabled] [Enabled] The following item appears only when you set Console Redirection to [Enabled]. ASUS RS720-E8-RS24-ECP 5-15...

  • Page 92: Console Redirection Settings

    Console Redirection Settings Out-of-Band Mgmt Port [COM1] Microsoft Windows Emergency Management Services (EMS) allow for remote management of a Windows Server OS through a serial port. Configuration options: [COM1] [COM2] Terminal Type [VT-UTF8] Microsoft Windows Emergency Management Services (EMS) allow for remote management of a Windows Server OS through a serial port. Configuration options: [VT100] [VT100+] [VT-UTF8] [ANSI] Bits per second [115200] Microsoft Windows Emergency Management Services (EMS) allow for remote management of a Windows Server OS through a serial port. Configuration options: [9600] [19200] [38400] [57600] [115200] Flow Control [None] Microsoft Windows Emergency Management Services (EMS) allow for remote management of a Windows Server OS through a serial port. Configuration options: [None] [Hardware RTS/CTS] [Software Xon/Xoff] 5-16 Chapter 5: BIOS Setup...

  • Page 93: Apm

    Configuration options: [Power Off] [Power On] [Last State] Power On By PCIE [Disabled] [Disabled] Disables the PCIE devices to generate a wake event. [Enabled] Enables the PCIE devices to generate a wake event. Power On By Ring [Disabled] [Disabled] Disables the PCIE devices to generate a wake event. [Enabled] Enables the PCIE devices to generate a wake event. Power On By RTC [Disabled] [Disabled] Disables RTC to generate a wake event. [Enabled] W hen set to [Enabled], the items RTC Alarm Date (Days) and Hour/Minute/Second will become user-configurable with set values. ASUS RS720-E8-RS24-ECP 5-17...

  • Page 94: Pci Subsystem Settings

    5.4.7 PCI Subsystem Settings Load RT32 Image [Enabled] Allows you to enable or disable RT32 Image Loading. Configuration options: [Disabled] [Enabled] Above 4G Decoding [Disabled] Allows you to enable or disable 64‑bit capable devices to be decoded in above 4G address space. It only works if the system supports 64-bit PCI decoding. Configuration options: [Disabled] [Enabled] SR-IOV Support [Disabled] This option enables or disables SIngle Root IO Virtualization Support if the system has SR‑...

  • Page 95: Network Stack Configuration

    The following item appears only when Network stack is set to [Enabled]. Ipv4 PXE Support [Enabled] Enables or disables the Ipv4 PXE Boot Support. If disabled, Ipv4 PXE boot option will not be created. Configuration options: [Disabled] [Enabled] Ipv6 PXE Support [Enabled] Enables or disables the Ipv6 PXE Boot Support. If disabled, Ipv6 PXE boot option will not be created. Configuration options: [Disabled] [Enabled] PXE boot wait time [0] Wait time to press ESC key to abort the PXE boot. Media detect time [0] Wait time (in seconds) to detect media. ASUS RS720-E8-RS24-ECP 5-19...

  • Page 96: Csm Configuration

    5.4.9 CSM Configuration CSM Support [Enabled] This option allows you to enable or disable CSM Support. Configuration options: [Disabled] [Enabled] GateA20 Active [Upon Request] This allows you to set the GA20 option. Configuration options: [Upon Request] [Always] Option ROM Messages [Force BIOS] This allows you to set the display mode for option ROM. Configuration options: [Force BIOS] [Keep Current] Boot Option filter [Legacy only] This option allows you to control the Legacy/UEFI ROMs priority.

  • Page 97: Trusted Computing

    5.4.10 Trusted Computing Configuration Security Device Support [Disabled] Allows you to enable or disable the BIOS support for security device. Configuration options: [Disabled] [Enabled] ASUS RS720-E8-RS24-ECP 5-21...

  • Page 98: Usb Configuration

    5.4.11 USB Configuration Legacy USB Support [Enabled] Allows you to enable or disable Legacy USB device support. Configuration options: [Enabled] [Disabled] [Auto] XHCI Hand-off [Enabled] This is a workaround for OSes without XHCI hand-off support. The XHCI ownership change should be claimed by XHCI driver. Configuration options: [Disabled] [Enabled] EHCI Hand-off [Disabled] This is a workaround for OSes without EHCI hand-off support. The EHCI ownership change should be claimed by EHCI driver. Configuration options: [Disabled] [Enabled] USB Mass Storage Driver Support [Enabled] Allows you to enable or disable the USB Mass Storage drvier support.

  • Page 99: Iscsi Configuration

    USB hardware delays and time-outs USB transfer time-out [20 sec] The time-out value for control, bulk, and interrupt transfer. Configuration options: [1 sec] [5 sec] [10 sec] [20 sec] Device reset time-out [20 sec] USB mass storage device start unit command time‑out. Configuration options: [10 sec] [20 sec] [30 sec] [40 sec] Device power-up delay [Auto] This is the maximum time the device will take before it properly reports itself to the host controller. Configuration options: [Auto] [Manual] 5.4.12 iSCSI Configuration Allows you to configure the iSCSi parameters. ASUS RS720-E8-RS24-ECP 5-23...

  • Page 100: Intelrcsetup Menu

    IntelRCSetup menu 5-24 Chapter 5: BIOS Setup...

  • Page 101: Processor Configuration

    Hyper Threading [Enabled] Allows you to enable or disable the Intel Hyper-Threading Technology function. When ® disabled, only one thread per activated core is enabled. Configuration options: [Disabled] [Enabled] Execute Disable Bit [Enabled] XD can prevent certain classes of malicious buffer overflow attacks when combined with a supporting OS (Windows Server 2003 SP1, Windows XP SP2, SuSE Linux 9.2, Redhat Enterprise 3 Update 3). Configuration options: [Disabled] [Enabled] Enable Intel TXT Support [Disabled] Forces the XD feature log to always return 0 when disabled. Configuration options: [Disabled] [Enabled] VMX [Enabled] Enables the Vanderpool Technology. Takes effect after reboot. Configuration options: [Disabled] [Enabled] ASUS RS720-E8-RS24-ECP 5-25...
  • Page 102 Enable SMX [Disabled] Enables the Safer Mode Extensions. Configuration options: [Disabled] [Enabled] Hardware Prefetcher [Enabled] This Item allows you to turn on/off the mid level cache (L2) streamer prefetcher. Configuration options: [Disabled] [Enabled] Adjacent Cache Prefetch [Enabled] This Item allows you to turn on/off prefetching of adjacent cache lines. Configuration options: [Disabled] [Enabled] DCU Streamer Prefetcher [Enabled] This Item allows you to enable or disable prefetcher of next L1 data line.

  • Page 103: Advanced Power Management Configuration

    PO TotalTimeThreshold Low [35] The HW switching mechanism disables the performance setting (0) when the total PO time is less than this threshold. PO TotalTimeThreshold High [58] The HW switching mechanism enables the performance setting (0) when the total PO time is greater than this threshold. 5.5.3 Common RefCode Configuration Numa [Enabled] This item enables or disables the Non uniform Memory Access (NUMA). Configuration options: [Disabled] [Enabled] ASUS RS720-E8-RS24-ECP 5-27...

  • Page 104: Qpi Configuration

    5.5.4 QPI Configuration QPI General Configuration QPI Status This item displays information about the QPI status. Link Speed Mode [Fast] This item allows you to select the QPI link speed as either the fast mode or slow mode. Configuration options: [Slow] [Fast] Link Frequency Select [Auto] This item allows you for selecting the QPI link frequency. Configuration options: [Auto] [6.4 GT/s] [8.0 GT/s] [9.6 GT/s] QPI Link0p Enable [Enable] Configuration options: [Disable] [Enable] QPI Link1 Enable [Enable] Configuration options: [Disable] [Enable] 5-28 Chapter 5: BIOS Setup...

  • Page 105: Memory Configuration

    Displays memory topology with DIMM population information. Memory Thermal Allows you to configure thermal settings. Set Throttling Mode [Disabled] Configuration options: [Disabled] [OLTT] [CLTT] OLLT Peak BW [xxx] Allows you to set the peak allowed bandwidth for OLTT. This is in percentage and valid offset values is from 25-100. DIMM Temp Stat [xx] Allows you to select DIMMTEMPSTAT as temp_mid or temp_hi. Memory Power Savings Mode [Auto] Allows you to configure the CKE and other related Memory Power Savings features. Configuration options: [Auto] [Disabled] [APD On] [User Defined] [Reserve] [Reserved] ASUS RS720-E8-RS24-ECP 5-29...

  • Page 106: Memory Ras Configuration

    Memory Power Savings Advanced Options CK in SR [Auto] Configuration options: [Auto] [Driven] [Tri-State] [Pulled Low] Pulled High] MDLL Off [Auto] Allows you to shut down MDLL during SR when enabled. Configuration options: [Auto] [Disabled] [Enabled] MEMHOT Throttling Mode [Input-only] Allows you to shut down MDLL during SR when enabled. Configuration options: [Disabled] [Input-only] [Output-only] Mem Electrical Throttling [Disabled] Allows you to configure Memory Electical throttling.

  • Page 107: Iio Configuration

    Allows you to enable or disable the Intel Virtualization Technology for Directed I/O. Configuration options: [Disabled] [Enabled] PCI Express Global Options TX EQ WA [Enabled] Use special table for TX_EQ and vendor specific cards. Configuration options: [Disabled] [Enabled] PCI-E ASPM Support (Global) [L1 Only] This option enables or disables the ASPM support for all downstream devices. Configuration options: [Disabled] [L1 Only] ASUS RS720-E8-RS24-ECP 5-31...

  • Page 108: Pch Configuration

    5.5.7 PCH Configuration PCH Devices DeepSx Power Policies [Disabled] Allows you to configure the DeepSx Mode configuration. Configuration options: [Disabled] [Enabled in S5] [Enabled in S4 and S5] PCI Express Configuration PCH DMI ASPM [Enabled] Allows you to configure the PCH DMI ASPM. Configuration options: [Disabled] [Enabled] PCI Express Root Port 1 to Port 8 Allows you to configure the PCI Express Root port settings. PCIE ASMP [Disable ASPM] Allows you to configure the PCH DMI ASPM. Configuration options: [ Disable ASPM] [ASPM L0s] [ASPM L1] [ASPM L0sL1] [ASPM Auto] PCH sSATA Configuration sSATA Controller [Enabled] Allows you to enable or disable the sSATA Controller.
  • Page 109 USB 3.0 Port #1 / #2 / #3 / #4 [Enabled] Configuration options: [Disabled] [Enabled] Platform Thermal Configuration PCH Thermal Device [Auto] Allows you to enable or disable the PCH Thermal Device (D31:F6). Configuration options: [Auto] [Disabled] [Enabled] Alert Enable Lock [Disabled] Allows you to lock all Alert Enable settings. Configuration options: [Disabled] [Enabled] ASUS RS720-E8-RS24-ECP 5-33...

  • Page 110: Miscellaneous Configuration

    5.5.8 Miscellaneous Configuration Active Video [Offboard Device] Allows you to select the video type. Configuration options: [Onboard Device] [Offboard Device] 5.5.9 Server ME Configuration Displays the Server ME Technology parameters on your system. 5.5.10 Runtime Error Logging Support Runtime Error Logging Whea Support [Disabled] This item allows you to enable or disable the WHEA support. Configuration options: [Disabled] [Enabled] 5-34 Chapter 5: BIOS Setup...

  • Page 111: Server Mgmt Menu

    This item allows you to start a BIOS timer which can only be shut off by Intel Management Software after the OS loads. Configuration options: [Disabled] [Enabled] The following items is configurable only when the OS Watchdog Timer is set to [Enabled]. OS Wtd Timer Timeout [10 minutes] Allows you to configure the length fo the OS Boot Watchdog Timer. Configuration options: [5 minutes] [10 minutes] [15 minutes] [20 minutes] OS Wtd Timer Policy [Reset] This item allows you to configure how the system should respond if the OS Boot Watch Timer expires. Configuration options: [Do Nothing] [Reset] [Power Down] Serial Mux [Disabled] This item allows you to enable or disable Serial Mux configuration. Configuration options: [Disabled] [Enabled] ASUS RS720-E8-RS24-ECP 5-35...

  • Page 112: System Event Log

    System Event Log Allows you to change the SEL event log configuration. SEL Components [Enabled] Allows you to enable or disable all features of system Event Logging during boot. Configuration options: [Disabled] [Enabled] • The following items appears only when you set SEL Components to [Enabled]. • All values changed here do not take effect until computer is restarted. Erase SEL [No] Allows you to choose options for erasing SEL. Configuration options: [No] [Yes, On next reset] [Yes, On every reset] When SEL is Full [Do Nothing] Allows you to choose options for reactions to a full SEL.
  • Page 113 Displays the uppercase or lowercase letters of the alphabet. Configuration options: [Lower Case] [Upper Case] IPv6 BMC Lan Option [Enable] This item allows you to enable or disable the IPv6 BMC LAN channel function. Disabling this item will not modify any BMC network during BIOS phase. Configuration options: [Disable] [Enable] IPv6 BMC LAN IP Address source [Previous State] Select to configure LAN channel parameters statically or dynamically (by BIOS or BMC). Configuration options: [ Previous State] [Static] [Dynamic-Obtained by BMC running DHCP] ASUS RS720-E8-RS24-ECP 5-37...
  • Page 114 The following items appear only when you set IP BMC Lan IP Address Source to [Static]. IPv6 BMC LAN IP Address Allows you to input IPv6 BMC Lan IP address. IPv6 BMC LAN IP Prefix Length Allows you to input IPv6 BMC Lan IP Prefix Length. IPv6 BMC LAN Default Gateway Allows you to input IPv6 BMC Lan Default Gateway.

  • Page 115: Event Logs Menu

    Choose options for erasing Smbios Event Log. Erasing is done prior to any logging activation during reset. Configuration options: [No] [Yes, Next reset] [Yes, Every reset] When Log is Full [Do Nothing] Allows you to choose options for reactions to a full Smbios Event Log. Configuration options: [Do Nothing] [Erase Immediately] ASUS RS720-E8-RS24-ECP 5-39...

  • Page 116: View Smbios Event Log

    Smbios Event Log Standard Settings Log System Boot Event [Disabled] Allows you to choose options to enable/disable logging of System boot event. Configuration options: [Enabled] [Disabled] MECI [1] Mutiple Event Count Increment (MECI). The number of occurrences of a duplicate event that must pass before the multiple-event counter associated with the log entry is updated, specified as a numeric value in the range 1 to 255. METW [60] Mutiple Event Time Windows (METW). The number of minutes which must pass between duplicate log entries which utilize a multiple-event counter. The value ranges from 0 to 99...

  • Page 117: Monitor Menu

    The onboard hardware monitor automatically detects the voltage output through the onboard voltage regulators. CPU FAN1&2 FRNT FAN1 mode [Generic Mode] Allows you to configure the ASUS Smart Fan feature that smartly adjusts the fan speeds for more efficient system operation. Configuration options: [Generic Mode] [High Speed Mode] [Full Speed Mode] [Manual Mode] Duty % [50] This item appears only when CPU FAN1&2 FRNT FAN1 mode is set to [Manual Mode]. This item allows you to configure the fan duty setting from 10% to 100%. FRNT FAN2&3/4&5; REAR FAN1&2 mode [Generic Mode] Allows you to configure the ASUS Smart Fan feature that smartly adjusts the fan speeds for more efficient system operation. Configuration options: [Generic Mode] [High Speed Mode] [Full Speed Mode] [Manual Mode] ASUS RS720-E8-RS24-ECP 5-41...

  • Page 118: Security Menu

    Security menu This menu allows a new password to be created or a current password to be changed. The menu also enables or disables the Secure Boot state and lets the user configure the System Mode state. Administrator Password To set an administrator password: Select the Administrator Password item and press <Enter>. From the Create New Password box, key in a password, then press <Enter>. Confirm the password when prompted. To change an administrator password: Select the Administrator Password item and press <Enter>.

  • Page 119: User Password

    This item allows you to customize the Secure Boot settings. Secure Boot [Disabled] Secure Boot can be enabled if the system is running in User mode with enrolled platform Key (EPK) or if the CSM function is disabled. Configuration options: [Disabled] [Enabled] Secure Boot Mode [Custom] Allows you to set the Secure Boot selector. Configuration options: [Custom] [Standard] ASUS RS720-E8-RS24-ECP 5-43...
  • Page 120 Key Management This item only appears when the item Secure Boot Mode is set to [Custom]. The Key Management item allows you to modify Secure Boot variables and set Key Management page. Default Key Provision [Disabled] Configuration options: [Disabled] [Enabled] Enroll All Factory Default Keys This item will ask you if you want to Install Factory Default secure keys. Select Yes if you want to load the default secure keys, otherwise select No. Save All Secure Boot Variables This item will ask you if you want to save all secure boot variables. Select Yes if you want to save all secure boot variables, otherwise select No. Platform Key (PK) / Key Exchange Key (KEK) / Authorized Signatures (DB) /Authorized TimeStamps (DBT) / Forbidden Signatures (DBX) Configuration options: [Delete] [Set New] [Append] 5-44 Chapter 5: BIOS Setup...

  • Page 121: Boot Menu

    Allows you to set an action when chassis intrusion has occured. Configuration options: [Warning] [Halt] Boot Option Priorities These items specify the boot device priority sequence from the available devices. The number of device items that appears on the screen depends on the number of devices installed in the system. ASUS RS720-E8-RS24-ECP 5-45...

  • Page 122: Tool Menu

    Tool menu The Tool menu items allow you to configure options for special functions. Select an item then press <Enter> to display the submenu. Start EZ Flash Allows you to run ASUS EZ Flash BIOS ROM Utility when you press <Enter>. Refer to the ASUS EZ Flash Utility section for details. 5-46 Chapter 5: BIOS Setup...

  • Page 123: Exit Menu

    Discard Changes & Reset Reset system setup without saving any changes. Save Options Save Changes Save changes done so far to any of the setup options. Discard Changes Discard changes done so far to any of the setup options. ASUS RS720-E8-RS24-ECP 5-47...

  • Page 124: Restore Defaults

    Restore Defaults Restore/load default values for all the setup options. Save as User Defaults Save the changes done so far as User Defaults. Restore User Defaults Restore the User Defaults to all the setup options. Boot Override These items display the available devices. The device items that appear on the screen depend on the number of devices installed in the system. Click an item to start booting from the selected device.

  • Page 125: Raid Configuration

    Chapter 6: RAID Configuration RAID Configuration This chapter provides instructions for setting up, creating, and configuring RAID sets using the available utilities.

  • Page 126: Setting Up Raid

    Setting up RAID The motherboard supports the following SATA RAID solutions: • LSI MegaRAID software RAID Configuration Utility with RAID 0, RAID 1, and RAID 10 support (for both Linux and Windows OS). ® • Intel Rapid Storage Technology enterprise Option ROM Utility with RAID 0, RAID 1, RAID 10, and RAID 5 support (for Windows OS only).

  • Page 127: Installing Hard Disk Drives

    Rapid Storage Technology if you installed Serial ATA ® hard disk drives on the Serial ATA connectors supported by the Intel C602 chipset. ® Refer to the succeeding section for details on how to use the RAID configuration utility. ASUS RS720-E8-RS24-ECP...

  • Page 128: Lsi Software Raid Configuration Utility

    LSI Software RAID Configuration Utility The LSI MegaRAID software RAID configuration utility allows you to create RAID 0, RAID 1, or RAID 10 set(s) from SATA hard disk drives connected to the SATA connectors supported by the motherboard southbridge chip. To enter the LSI MegaRAID software RAID configuration utility: Turn on the system after installing all the SATA hard disk drives.

  • Page 129: Creating A Raid Set

    New Configuration Configure View/Add Configuration Initialize Clear Configuration Objects Select Boot Drive Rebuild Check Consistency Defines Physical Arrays. An Array Will Automatically Become A VD Use Cursor Keys to Navigate Between Items And Press Enter To Select An Option ASUS RS720-E8-RS24-ECP...
  • Page 130 The ARRAY SELECTION MENU displays the available drives connected to the SATA ports. Use the up/down arrow keys to select the drives you want to include in the RAID set, and then press <Space>. When selected, the drive indicator changes from READY to ONLIN A[X]-[Y], where X is the array number, and Y is the drive number.
  • Page 131 RAID = 1 READY RAID 1 Units= MB Size = 152146MB = OFF = On Accept SPAN = NO Choose RAID Level For This VD Use Cursor Keys To Navigate Between Items And Press Enter To Select An Option ASUS RS720-E8-RS24-ECP...
  • Page 132 Select Units from the Virtual Drive sub-menu, and then press <Enter>. Select the units for virtual drive size from the menu, and then press <Enter>. LSI Software RAID Configuration Utility Ver C.05 Sep 17,2010 BIOS Version A.10.09231523R Virtual Drive(s) Configured Easy Configuration - ARRAY SELECTION MENU RAID Size...
  • Page 133 Clear Configuration Initialize Select Boot Drive Objects Virtual Drive(s) Configured Rebuild Check Consistency RAID Size #Stripes StripSz Status 148.580GB 64KB ONLINE Select Yes Or No Use Cursor Keys To Navigate Between Items And Press Enter To Select An Option ASUS RS720-E8-RS24-ECP...

  • Page 134: Using New Configuration

    Using New Configuration When a RAID set already exists, using the New Configuration command erases the existing RAID configuration data. If you do not want to delete the existing RAID set, use the View/Add Configuration command to view or create another RAID configuration. To create a RAID set using the New Configuration option: From the Management Menu, select Configure >...

  • Page 135: Adding Or Viewing A Raid Configuration

    SPACE-Sel,ENTER-EndArray,F10-Configure,F2-Drive Info,F3-Virtual Drives,F4-HSP The information of the selected hard disk drive displays at the bottom of the screen. Follow step 3 to 12 of section 6.2.1 Creating a RAID set: Using Easy Configuration to add a new RAID set. ASUS RS720-E8-RS24-ECP 6-11...

  • Page 136: Initializing The Virtual Drives

    6.2.3 Initializing the virtual drives After creating the RAID set(s), you must initialize the virtual drives. You may initialize the virtual drives of a RAID set(s) using the Initialize or Objects command on the Management Menu. Using the Initialize command To initialize the virtual drive using the Initialize command: From the Management Menu, select Initialize, and then press <Enter>.
  • Page 137 RAID Size #Stripes StripSz Status Management Menu Configure Init of VD Is In Process 148.580GB 64KB ONLINE Initialize VD 0 Initialization Complete. Press Esc.. Objects Rebuild Check Consistency 100% Completed Virtual Drives Virtual Drive 0 SPACE-(De)Select, F10-Initialize ASUS RS720-E8-RS24-ECP 6-13...
  • Page 138 Using the Objects command To initialize the virtual drives using the Objects command: From the Management Menu, select Objects > Virtual Drive, and then press <Enter>. LSI Software RAID Configuration Utility Ver C.05 Sep 17,2010 BIOS Version A.10.09231523R Objects Management Menu Adapter Configure Virtual Drive...
  • Page 139 Init Will Destroy Data On Selected VD(s) Use Cursor Keys To Navigate Between Items And Press Enter To Select An Option A progress bar appears on screen. If desired, press <Esc> to abort initialization. When initialization is completed, press <Esc>. ASUS RS720-E8-RS24-ECP 6-15...

  • Page 140: Rebuilding Failed Drives

    6.2.4 Rebuilding failed drives You can manually rebuild failed hard disk drives using the Rebuild command in the Management Menu. To rebuild a failed hard disk drive: From the Management Menu, select Rebuild, and then press <Enter>. LSI Software RAID Configuration Utility Ver C.05 Sep 17,2010 BIOS Version A.10.09231523R Management Menu...
  • Page 141 FAIL A00-01 Rebuilding of Drive Will Take A Few Minutes. Start Rebuilding Drive (Y/N)? Check Consistency Port # 1 DISK 77247MB HDS72808PLA380 PF20A60A SPACE-(De)Select,F10-Start Rebuild,F2-Drive Information,F3-View Virtual Drives When rebuild is complete, press any key to continue. ASUS RS720-E8-RS24-ECP 6-17...

  • Page 142: Checking The Drives For Data Consistency

    6.2.5 Checking the drives for data consistency You can check and verify the accuracy of data redundancy in the selected virtual drive. The utility can automatically detect and/or detect and correct any differences in data redundancy depending on the selected option in the Objects > Adapter menu. The Check Consistency command is available only for virtual drives included in a RAID 1 or RAID 10 set.
  • Page 143 • Continue - Continues the consistency check. • Abort - Aborts the consistency check. When you restart checking, it continues from zero percent. When checking is complete, press any key to continue. ASUS RS720-E8-RS24-ECP 6-19...
  • Page 144 Using the Objects command To check data consistency using the Objects command: From the Management Menu, select Objects, and then select Virtual Drive from the sub-menu. Use the arrow keys to select the virtual drive you want to check, and then press <Enter>.

  • Page 145: Deleting A Raid Configuration

    Clear Configuration Objects Select Boot Drive Rebuild Check Consistency Clear Existing Configuration Use Cursor Keys To Navigate Between Items And Press Enter To Select An Option The utility clears all the current array(s). Press any key to continue. ASUS RS720-E8-RS24-ECP 6-21...

  • Page 146: Selecting The Boot Drive From A Raid Set

    6.2.7 Selecting the boot drive from a RAID set You must have created a new RAID configuration before you can select the boot drive from a RAID set. See section 6.2.1 Creating a RAID set: Using New Configuration for details. To select the boot drive from a RAID set: From the Management Menu, select Configure >...

  • Page 147: Enabling Writecache

    Disk WC = On Check Consistency Read Ahead = On Disk Write Cache Setting of VD Use Cursor Keys To Navigate Between Items And Press Enter To Select An Option When finished, press any key to continue. ASUS RS720-E8-RS24-ECP 6-23...

  • Page 148: Intel ® Rapid Storage Technology Enterprise

    ® Intel Rapid Storage Technology enterprise SATA/SSATA Option ROM Utility The Intel Rapid Storage Technology enterprise SATA/SSATA Option ROM utility allows you ® to create RAID 0, RAID 1, RAID 10 (RAID 1+0), and RAID 5 set from Serial ATA hard disk drives that are connected to the Serial ATA connectors supported by the Southbridge.

  • Page 149: Creating A Raid Set

    ]-Prev/Next [TAB]-(M)aster [SPACE]-(R)ecovery [ENTER]-Done Use the up/down arrow keys to move the selection bar then press <Space> to select a disk. A small triangle before the Port number marks the selected drive. Press <Enter> when you are done. ASUS RS720-E8-RS24-ECP 6-25...
  • Page 150 Use the up/down arrow keys to select the stripe size for the RAID array (for RAID 0, 10 and 5 only) then press <Enter>. The available stripe size values range from 4 KB to 128 KB. The following are typical values: RAID 0: 128KB RAID 10: 64KB RAID 5: 64KB...

  • Page 151: Deleting A Raid Set

    <N> to return to the DELETE VOLUME menu. DELETE VOLUME VERIFICATION ALL DATA IN THE VOLUME WILL BE LOST! (This does not apply to Recovery volumes) Are you sure you want to delete volume “Volume0”? (Y/N): ASUS RS720-E8-RS24-ECP 6-27...

  • Page 152: Resetting Disks To Non-Raid

    6.3.3 Resetting disks to Non-RAID Take caution before you reset a RAID volume hard disk drive to non-RAID. Resetting a RAID volume hard disk drive deletes all internal RAID structure on the drive. To reset a RAID set: From the utility main menu, select 3. Reset Disks to Non-RAID and press <Enter>. Press the up/down arrow keys to select the drive(s) or disks of the RAID set you want to reset, then press <Space>.

  • Page 153: Exiting The Intel ® Rapid Storage Technology Enterprise Sata Option Rom Utility

    Rebuild completes in the operating system. Select the port of destination disk for rebuilding (ESC to exit): Port Drive Model Serial # Size XXXXXXXXXXX XXXXXXXX XXX.GB ]-Previous/Next [ENTER]-Select [ESC]-Exit Select a destination disk with the same size as the original hard disk. ASUS RS720-E8-RS24-ECP 6-29...
  • Page 154 The utility immediately starts rebuilding after the disk is selected. When done, the status of the degraded RAID volume is changed to “Rebuild”. Intel(R) Rapid Storage Technology enterprise - SATA Option ROM - 4.5.0.1012 Copyright(C) 2003-15 Intel Corporation. All Rights Reserved. MAIN MENU 1.

  • Page 155: Setting The Boot Array In The Bios Setup Utility

    Use up/down arrow keys to select the boot priority and press <Enter>. See the Boot menu section of Chapter 5 for more details. From the Exit menu, select Save Changes & Exit, then press <Enter>. When the confirmation window appears, select Yes, then press <Enter>. ASUS RS720-E8-RS24-ECP 6-31...

  • Page 156: Intel ® Rapid Storage Technology Enterprise (Windows)

    ® Intel Rapid Storage Technology enterprise (Windows) ® The Intel Rapid Storage Technology enterprise allows you to create RAID 0, RAID 1, RAID 10 (RAID 1+0), and RAID 5 set(s) from Serial ATA hard disk drives that are connected to the Serial ATA connectors supported by the Southbridge.

  • Page 157: Creating A Raid Set

    Select Volume Size tab, you can drag the bar to decide the volume size. Click Next. • If you do not want to keep the data on one of the selected disks, select NO when prompted. • If you want to Enable volume write-back cache or Initialize volume, click Advanced. ASUS RS720-E8-RS24-ECP 6-33...
  • Page 158 Confirm the volume creation, then click Create Volume to continue. This process could take a while depending on the number and size of the disks. You can continue using other applications during this time. Wait until the process is completed, then click OK when prompted. You still need to partition your new volume using Windows Disk Management before adding any data.

  • Page 159: Changing A Volume Type

    OK. The available stripe size values range from 4 KB to 128 KB. The following are typical values: RAID 0: 128KB RAID 10: 64KB RAID 5: 64KB We recommend a lower stripe size for server systems, and a higher stripe size for multimedia computer systems used mainly for audio and video editing. ASUS RS720-E8-RS24-ECP 6-35...

  • Page 160: Deleting A Volume

    6.4.3 Deleting a volume Be cautious when deleting a volume. You will lose all data on the hard disk drives. Before you proceed, ensure that you back up all your important data from your hard drives. To delete a volume: From the utility main menu, select the volume (ex.

  • Page 161: Preferences

    Allow you to set to show the notification area icon and show system information, warning, or errors here. E-Mail Preferences Allows you to set to sent e-mail of the following events: • Storage system information • Storage system warnings • Storage system errors ASUS RS720-E8-RS24-ECP 6-37...
  • Page 162 6-38 Chapter 6: RAID Configuration...

  • Page 163: Chapter 7: Driver Installation

    Chapter 7: Driver Installation Driver Installation This chapter provides the instructions for installing the necessary drivers for different system components in both ® ® Linux and Windows Operating Systems.

  • Page 164: Raid Driver Installation

    RAID driver installation After creating the RAID sets for your server system, you are now ready to install an operating system to the independent hard disk drive or bootable array. This part provides the instructions on how to install the RAID controller drivers during OS installation. 7.1.1 Creating a RAID driver disk The system does not include a floppy drive. You have to use a USB floppy drive when...

  • Page 165: Installing The Raid Controller Driver

    To install the RAID controller driver when installing Windows Server 2008 R2 OS: ® Boot the computer using the Windows Server 2008 R2 OS installation disc. Follow the screen instructions to start installing Windows Server 2008 R2. When prompted to choose a type of installation, click Custom (advanced). Click Load Driver. ASUS RS720-E8-RS24-ECP...
  • Page 166 A message appears reminding you to insert the installation media containing the driver of the RAID controller driver. If you have only one optical drive installed in your system, eject the Windows OS installation disc and replace with the motherboard Support DVD into the optical drive.
  • Page 167 Do you have a driver disk? ® Insert the Red Hat Enterprise RAID driver disk to the USB floppy disk drive, select OK, then press <Enter>. Insert Driver Disk Insert your driver disk into /dev/fd0 and press “OK” to continue. Back The drivers for the RAID card are installed to the system. ASUS RS720-E8-RS24-ECP...
  • Page 168 When asked if you will load additional RAID controller drivers, select No, then press <Enter>. More Driver Disks? Do you wish to load any more driver disks? Follow the onscreen instructions to finish the OS installation. When the installation is completed, DO NOT click Reboot. Press <Ctrl> + <Alt> + <F2> to switch to the command-line interface from graphic user interface.
  • Page 169 ® Boot the system from the Red Hat OS installation CD. Press <Tab> to edit options. While booting from DVD, press <ESC> to give the third party driver. Enter the following command at the boot: Linux dd blacklist=isci blacklist=ahci nodmraid , then press <ENTER>. ASUS RS720-E8-RS24-ECP...
  • Page 170 Select Yes using the <Tab> key when asked if you have the driver disk, then press <Enter>. Main Menu Do you have a driver disk? You have multiple devices which could serve as source for a driver disk. Choose one you like to use and select OK, then press <Enter>. Driver Disk Source You have multiple devices which could serve as source for a driver disk.
  • Page 171 The drivers for the RAID card are installed to the system. When asked if you will load additional RAID controller drivers, select No, then press <Enter>. More Driver Disks? Do you wish to load any more driver disks? Follow the onscreen instructions to finish the OS installation. ASUS RS720-E8-RS24-ECP...
  • Page 172 Preparing the Linux Driver Ensure that there is another computer with a Linux-based OS to create the RAID driver. When creating the RAID driver, you may refer to the examples below which uses a 64bit SUSE Linux system to create a 64bit RAID driver for SUSE11 sp1. Copy the image file into the Linux system. Example: megasr-15.00.0120.2012-1-sles11-ga-x86_64.img Create a folder. Example: image Mount the image file into the image folder using this command format: mount -oloop [image file name] image...
  • Page 173 Installing SUSE 11 Linux OS To install the LSI MegaRAID controller driver when installing SUSE Linux Enterprise Server Boot the system from the SUSE OS installation CD. Use the arrow keys to select Installation from the Boot Options menu. Press <F6>, then select Yes from the menu. Press <Enter>. ASUS RS720-E8-RS24-ECP 7-11...
  • Page 174 Use the USB drive to provide the third-party driver during the OS installation. Type the command brokenmodules=ahci in Boot Options field, and press <Enter>. When below screen appears, select the USB floppy disk drive (sda) as the driver update medium. Select OK, then press <Enter>. Please choose the Driver Update medium. sda: USB Floppy other device Back Select Back and follow the onscreen instructions to finish the installation. 7-12 Chapter 7: Driver Installation...

  • Page 175: Management Applications And Utilities Installation

    The main screen of the Support DVD contains the following tabs: Drivers Utilities MakeDisk Manual Contact ® The main screen of the Support DVD looks exactly the same on the Windows Server 2008 ® R2 and on the Windows Server 2012 Operating System (OS). ASUS RS720-E8-RS24-ECP 7-13...

  • Page 176: Drivers Menu Tab

    7.3.1 Drivers menu tab The Drivers Menu shows the available device drivers if the system detects installed devices. Install the necessary drivers to activate the devices. 7.3.2 Utilities menu tab The Utilities menu displays the software applications and utilities that the motherboard supports. 7-14 Chapter 7: Driver Installation...

  • Page 177: Makedisk Menu Tab

    MakeDisk menu tab The MakeDisk menu contains items to create the Intel RAID driver disks. Press the arrow down button in the lower part of the menu to view more items. 7.3.4 Manual menu The Manual menu provides the link to the Broadcom NetXtreme II Network Adapter user guide. You need an internet browser installed in your OS to view the User Guide. ASUS RS720-E8-RS24-ECP 7-15...

  • Page 178: Contact Information Menu

    7.3.5 Contact information menu The Contact menu displays the ASUS contact information, e-mail addresses, and useful links if you need more information or technical support for your motherboard. 7-16 Chapter 7: Driver Installation...

  • Page 179: Intel ® Chipset Device Software Installation

    If Autorun is NOT enabled in your computer, browse the contents of the support DVD to locate the file ASSETUP.EXE from the BIN folder. Double-click the ASSETUP.EXE to run the support DVD. Click the item Intel Chipset Device Software from the menu. ® The Intel Chipset Device Software window appears. Click Next to start installation. ASUS RS720-E8-RS24-ECP 7-17...
  • Page 180 Select Yes to accept the terms of the License Agreement and continue the process. Read the Readme File Information and press Next to continue the installation. Toggle Yes, I want to restart the computer now and click Finish to complete the setup process.

  • Page 181: Installing The Intel ® I350-Am1/I350-Am2/I210/X540-Bt2 Gigabit Adapters Driver

    BIN folder. Double-click the ASSETUP.EXE to run the support DVD. ® Click Intel I350-AM1/I350-AM2/I210/X540-BT2 Gigabit Adapters Driver in the Drivers menu of the main screen to start the installation. Click Install Drivers and Software option to begin installation. ASUS RS720-E8-RS24-ECP 7-19...
  • Page 182 Click Next when the Intel(R) Network Connections Install Wizard window appears. Tick I accept the terms in the license agreement and click Next to continue. From the Setup Options window, click Next to start the installation. By default, Intel(R) PROSet for Windows Device Manager and Windows PowerShell Module are ticked.
  • Page 183 Click Install to start the installation. When the installation is done, press Finish to complete the installation. ASUS RS720-E8-RS24-ECP 7-21...

  • Page 184: Vga Driver Installation

    VGA driver installation This section provides the instructions on how to install the ASPEED Video Graphics Adapter (VGA) driver. ® You need to manually install the ASPEED VGA driver on a Windows operating system. To install the ASPEED VGA driver: Restart the computer and then log on with Administrator privileges. Insert the motherboard/system support DVD to the optical drive. The support DVD automatically displays the Drivers menu if Autorun is enabled in your computer.
  • Page 185 Click Install to proceed with the installation. Click Finish to complete the installation. ASUS RS720-E8-RS24-ECP 7-23...

  • Page 186: Intel ® Rapid Storage Technology Enterprise 4.0 Installation

    ® Intel Rapid Storage Technology enterprise 4.0 installation ® This section provides the instructions on how to install the Intel Rapid Storage Technology enterprise 4.0 on the system. ® You need to manually install the Intel Rapid Storage Technology enterprise 4.0 utility on a ® Windows operating system.
  • Page 187 Read the Warning message and click Next to continue. Read the License Agreement and click Yes to continue. Read the Readme File Information and click Next to continue. ASUS RS720-E8-RS24-ECP 7-25...
  • Page 188 After completing the installation, click Next to complete the setup process. Select Yes, I want to restart this computer now and click Finish to restart your computer before using the program. 7-26 Chapter 7: Driver Installation...
