Drying tumblers 25/30/35 pound capacity; stacked 30 pount capacity; stacked 45 pound capacity; 55 pound capacity

Advertisement

Drying Tumblers
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)
25 Pound Capacity
30 Pound Capacity
35 Pound Capacity
Stacked 30 Pound Capacity
Stacked 45 Pound Capacity
55 Pound Capacity
Starting Serial No. 0602004144
Refer to page 3 for Model Identification
Part No. 70392201R8
September 2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dryer Tumblers and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Alliance Laundry Systems Dryer Tumblers

  • Page 1 Drying Tumblers Refer to page 3 for Model Identification Keep These Instructions for Future Reference. (If this machine changes ownership, this manual must accompany machine.) 25 Pound Capacity 30 Pound Capacity 35 Pound Capacity Stacked 30 Pound Capacity Stacked 45 Pound Capacity 55 Pound Capacity Starting Serial No.
  • Page 3 Installation must conform with local codes. WARNING FOR YOUR SAFETY, the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury or death. • Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
  • Page 4: Table Of Contents

    Installation/Operation Supplement Table of Contents © Published by permission of the copyright owner. All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. ©...
  • Page 5: Introduction

    Model Identification Information in this manual is applicable to these models. GU025L GU025N HU025L 25 Pound HU025N KU025L KU025N LU025L GU030L GU030N HU030L 30 Pound HU030N LU030L LU030N GUT30L GUT30N HUT30L HUT30N KUT30L KUT30N LUT30L GU035L GU035N HU035L HU035N 35 Pound KU035L KU035N LU035L...
  • Page 6: Serial Plate Location

    Installation/Operation Supplement Serial Plate Location 25, 30, 35 AND 55 POUND Serial Plate Wiring Diagram The wiring diagram is located inside the junction or contactor box. © Published by permission of the copyright owner – DO NOT COPY or TRANSMIT T30 AND T45 TMB2098N TMB1974N...
  • Page 7: Safety Information

    Safety Information Important Safety Instructions WARNING Hazardous Voltage. Can cause shock, burn or cause death. Allow machine power to remain off for two minutes prior to working in and around AC inverter drive. 1. Read all instructions before using the tumbler. 2.
  • Page 8 Installation/Operation Supplement 22. Install this tumbler according to the INSTALLATION INSTRUCTIONS. All connections for electrical power, grounding, and gas supply must comply with local codes and be made by licensed personnel when required. 23. Remove laundry immediately after tumbler stops. 24.
  • Page 9: Installation

    Specifications and Dimensions Specifications Noise level measured during operation at operator position of 1 meter (3.3 feet) in front of machine and 1.6 meters (5.2 feet) from floor Net Weight (approximate): kg (pounds) Cylinder Size: mm (inches) Cylinder Capacity (dry weight): kg (pounds) Drive Motor Horsepower**...
  • Page 10: Cabinet Dimensions - 25, 30, 35 And 55 Pound Models

    Installation/Operation Supplement Cabinet Dimensions — 25, 30, 35 and 55 Pound Models Models 667 mm 699 mm 25 Pound (26.25 in.) (27.5 in.) 667 mm 699 mm 30 Pound (26.25 in.) (27.5 in.) 711 mm 699 mm 35 Pound (28 in.) (27.5 in.) 810 mm 682.5 mm...
  • Page 11: Cabinet Dimensions - T30 And T45 Model

    Cabinet Dimensions – T30 and T45 Models Models 711 mm (28 in.) 810 mm (31.88 in.) Models 636 mm (25.02 in.) 746 mm (29.37 in.) N/A = Not Applicable NOTE: To meet ADA compliance, install a 102 mm (4 inch) riser on T30 models only. ©...
  • Page 12: Exhaust Outlet Locations

    Installation/Operation Supplement Exhaust Outlet Locations 25, 30, 35 AND 55 POUND Models Diameter 152 mm 25/30 Pound (6 in.) Elliptical Fits 203 mm (8 in.) 203 mm 35 Pound (8 in.) Elliptical Fits 254 mm (10 in.) 203 mm 55 Pound (8 in.) N/A = Not Applicable ©...
  • Page 13: Gas Connection Locations

    Gas Connection Locations 25, 30, 35 AND 55 POUND 1/2 in. NPT Models 1500 mm 25 Pound 1500 mm 30 Pound 1912 mm (75.28 in.) 1500 mm 35 Pound 2000 mm (78.75 in.) 1500 mm 55 Pound © Published by permission of the copyright owner – DO NOT COPY or TRANSMIT 70392201 (EN) TMB2106N TMB2106N...
  • Page 14: Electrical Connection Locations

    Installation/Operation Supplement Electrical Connection Locations 25, 30, 35 AND 55 POUND T30 GAS AND STEAM T45 GAS Models Gas and Steam Models 1581 mm 25/30 Pound (62.25 in.) 1498 mm (59 in.) 1581 mm 35 Pound (62.25 in.) 1588 mm (62.5 in.) 1655.75 mm 55 Pound...
  • Page 15: Steam Connection Locations

    Steam Connection Locations 25, 30 AND 35 POUND Models 1365 mm 25/30/35 Pound (53.75 in.) 1877 mm T30 (Upper) (73.93 in.) 923 mm T30 (Lower) (36.35 in.) NOTE: All connections use 3/4 inch NPT pipe. © Published by permission of the copyright owner – DO NOT COPY or TRANSMIT 70392201 (EN) TMB2108N TMB2108N...
  • Page 16: Position And Level The Tumbler

    Installation/Operation Supplement Position and Level the Tumbler To reduce the risk of severe injury, clearance of tumbler cabinet from combustible construction must conform to the minimum clearances. NOTE: Shaded areas indicate adjacent structure. 13 mm (0.5 in.) recommended between machines for removal or installations. Allow 51-102 mm (2-4 in.) opening at top of machine to aid in removal or installation.
  • Page 17: Gas Requirements

    Gas Requirements Natural Gas and Liquefied Petroleum WARNING To reduce the risk of fire or explosion, DO NOT CONNECT THE GAS LINE TO THE TUMBLER IF THE GAS SERVICE IS NOT THE SAME AS THAT SPECIFIED ON THE TUMBLER SERIAL PLATE! It will first be necessary to convert the gas burner orifice and gas valve.
  • Page 18 Installation/Operation Supplement Gases and Configurations Country Gas Type Group Code Natural Gas DK/NO/ SE/FI/CZ/ EE/LV/LT/ L.P. Gas SI/SK Natural Gas L.P. Gas Natural Gas L.P. Gas Burner orifice information at 0-600 meters (0-2000 feet) altitude. © Published by permission of the copyright owner – DO NOT COPY or TRANSMIT Burner Supply Orifice...
  • Page 19 Country Gas Type Group Code Natural Gas BE/FR* L.P. Gas Natural Gas GB/IE/PT/ ES/IT/GR/ L.P. Gas LU/CH Natural Gas L.P. Gas L.P. Gas CY/IS/MT Burner orifice information at 0-600 meters (0-2000 feet) altitude. *For Natural Gas, Group E+ applications, convert using L.P. Gas model and replace burner orifice.
  • Page 20 Installation/Operation Supplement Country Gas Type Group Code Natural Gas L.P. Gas Natural Gas L.P. Gas Burner orifice information at 0-600 meters (0-2000 feet) altitude. © Published by permission of the copyright owner – DO NOT COPY or TRANSMIT Table 1 (continued) Burner Supply Orifice...
  • Page 21: Exhaust Requirements

    Exhaust Requirements WARNING A drying tumbler produces combustible lint. To reduce the risk of fire, the tumbler must be exhausted to the outdoors. To reduce the risk of fire and accumulation of combustible gases, DO NOT exhaust tumbler air into a window well, gas vent, chimney or enclosed, unventilated area such as an attic wall, ceiling, crawl space under a building, or concealed space of a...
  • Page 22: Electrical Requirements

    Installation/Operation Supplement Electrical Requirements WARNING To reduce the risk of electric shock, fire, explosion, serious injury or death: • Disconnect electric power to the tumbler before servicing. • Close gas shut-off valve to gas tumbler before servicing. • Close steam valve to steam tumbler before servicing.
  • Page 23: Steam Requirements

    Steam Requirements NOTE: The maximum allowable steam pressure is 8.6 bar (125 psig). In no case may the pressure exceed this value. Obtain specific steam service pipe sizes from the steam system supplier or a qualified steam fitter. Refer to Figure 2 for proper steam pipe ●...
  • Page 24 Installation/Operation Supplement Note: Refer to Table 2 for sizing of steam lines. Piping must also be sized accordingly for length of runs, and number of elbows. Steam Coil 305 mm (12 in.) Riser Condensate Return Line from Supply Line Shut-Off Valve Check Valve Steam Pressure Model...
  • Page 25: Operation

    To reduce the risk of fire: • DO NOT DRY articles containing foam rubber or similarly textured rubberlike materials. • DO NOT DRY plastics, anything containing wax or chemicals such as mops and cleaning cloths, or anything dry-cleaned at home with a dry-cleaning solvent. •...
  • Page 26: Control Instructions

    Installation/Operation Supplement Control Instructions Dual Digital Timer Control QT Control Suffix 1. Select HIGH, MED, LOW or NO HEAT by turning the temperature knob. Figure 4 2. Set the HEAT TIME for the number of minutes (from 0-60) desired. Figure 5 3.
  • Page 27: Electronic Opl Micro Control

    Electronic OPL Micro Control H, L, P, S, U and Y Models with OM Control Suffix 1. To use an Automatic Cycle, press an ON/ SELECT pad. Select HIGH, MEDIUM, MED LOW, LOW or NO HEAT for items that should not be dried with heat. A light to the left of the selected pad lights up.
  • Page 28: Single Drop Control

    Installation/Operation Supplement 2. Press START pad to start tumbler. Figure 13 NOTE: All pads can be pressed in any sequence without damaging control or tumbler. To stop the tumbler at any time, open the door or press STOP. Figure 14 NOTE: The window display will flash.
  • Page 29: Mdc Coin And Card Control

    MDC Coin and Card Control BC, BG, BL, BX and BY Control Suffixes 1. Select temperature by pressing the appropriate temperature pad. Figure 18 2. Insert the coin(s) in the coin slot, or the card into the opening. TMB1492N Figure 19 ©...
  • Page 30: Ignition Control Operation

    Installation/Operation Supplement Ignition Control Operation Flame Probe Tests Unexpected Presence of Flame The Unexpected Presence of Flame test is performed when no flame is expected. Failure of this test results in the ignition control entering Lockout Mode with the Diagnostic LED displaying Error Code 3. Flame Monitoring During the Flame Monitoring test, the flame is checked to ensure the gas is being burned when the gas...
  • Page 31: Disposal Of Unit

    Installation/Operation Supplement Disposal of Unit This appliance is marked according to the European directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE). This symbol on the product or on its packaging indicates that this product shall not be treated as household waste.
