Tumble Dryer
Touch Vend Control
Refer to Page 10 for Model Identification
TMB1851R_SVG
Original Instructions
Keep These Instructions for Future Reference.
CAUTION: Read the instructions before using the machine.
(If this machine changes ownership, this manual must accompany machine.)
Part No. 70600001ENR6
www.alliancelaundry.com
March 2020
