KitchenAid KUDC20FVBL - ARCHITECT Series II Parts List page 6

TUB AND FRAME PARTS
For Models: KUDC20FVBL3, KUDC20FVWH3, KUDC20FVSS3
(Black)
Illus. Part
No. No.
1 W10213822 Tub Assembly
2 8573061 Strain Relief
3 W10112096 Door Seal
4 W10082838 Plug Tub
5 W10078083 Wheel & Mount
6 9743002 Gasket, Bracket
7 8269110 Seal, Cabinet
8 3400072 Screw
9 W10084086 Door Balance
10 3367670 Screw
11 8269145 Bracket,
12 3400074 Screw
13 8574123 Barrier, Moisture
14 3370389 Screw
15 8268977 Wheel Leg
16 8524584 Leveler, Leg
17 W10266857 Insulator,
18 8270020 Spring, Door
19 3400892 Screw
20 8268991 Cover, Terminal
21 W10158291 Cable, Door
22 304666 Retainer, Push
23 8573241 Shield, Sound
24 9742648 Bracket,
25 661566 Thermostat
26 W10077370 Strike, Latch
27 3378128 Washer,
28 3400014 Screw
29 3400924 Retainer,
(White) (Stainless)
DESCRIPTION
(Includes Heater
Assembly)
Assembly
(Also Order
Item 6)
Mounting
Assembly
Undercounter
Undercounter
Sound
Balance
Box
Balance
Thermostat
Pronged Cup
Push−in
6
W10304967
