Configuration Examples for Digital Modem PVDM2s

Configuration Examples for Digital Modem PVDM2s
This section provides the following configuration examples:
•
•
Configuring a T1 Controller for CAS Digital Trunk Calls: Example
The following example shows the T1 CAS configuration for a PVDM2-36DM module in PVDM slot 0
of a Cisco 2851 router.
version 12.4
service timestamps debug datetime msec
service timestamps log datetime msec
no service password-encryption
!
card type t1 1
!
no aaa new-model
!
resource policy
!
network-clock-participate slot 1
network-clock-select 1 T1 1/0
!
modem country v12 t1-default
!
ip cef
!
no ip domain lookup
!
controller T1 1/0
framing esf
linecode b8zs
ds0-group 1 timeslots 1-24 type e&m-immediate-start
!
controller T1 1/1
framing esf
linecode b8zs
!
interface Loopback0
ip address 10.0.0.1 255.255.255.255
!
interface GigabitEthernet0/0
no ip address
duplex auto
speed auto
!
interface GigabitEthernet0/1
no ip address
duplex auto
speed auto
!
interface Dialer101
ip address 10.101.0.1 255.255.0.0
encapsulation ppp
dialer pool 1
dialer idle-timeout 2147483
dialer string 101
Cisco IOS Release 12.4(9)T, 12.4(11)XW, and 12.4(20)T
22
Cisco PVDM2-12DM, PVDM2-24DM, and PVDM2-36DM Digital Modem Packet Voice Data Modules
Configuring a T1 Controller for CAS Digital Trunk Calls: Example, page 22
Configuring a T1 Controller for ISDN Digital Modem Calls: Example, page 23
