xSeries 335
Type 8676

Installation Guide

Welcome. . .
Thank you for buying an
IBM xSeries server.
is based on the X-Architecture
technology, and it features
superior performance, availability,
and scalability.
Installation Guide
This server
contains information for setting
up and configuring your server.
For detailed information about
your server, view the publications
on the
Documentation CD.
You can also find the most
current information about your
server on the IBM Web site at:
http://www.ibm.com/pc/support.
Your server
System is ready to use.
Go to the Server Support
and profile your server.
Install options:
• Drives
• Microprocessors
• Adapters
• Memory
Install the server in
the rack, if required
Cable the server
and options
Start the server
No
Did the server
start correctly?
Yes
Use ServerGuide™
to set up and
configure hardware
No
Did configuration
complete?
Yes
Use
No
ServerGuide to
install operating
system?
Yes
Install applications,
such as IBM systems
management software
and IBM ServeRAID
programs
flow chart to register
Go to the Server Support
flow chart
Go to the Web for instructions,
http://www.ibm.com/pc/support
