Hardware Installation
By itself, your PlexWriter 4/12 is incapable of communicating with your computer.
You must use a hardware link that enables your drive to ''talk'' with the rest of your
computer. PlexWriter 4/12 uses a SCSI interface as its link.
Plextor strongly recommends the use of a high-performance bus-mastering SCSI
interface board (ISA or PCI). You probably purchased a Plextor kit with such a board
included. If you purchased your PlexWriter 4/12 without a SCSI interface board and
want to connect it to a non-bus-mastering interface board (PIO), we strongly recom-
mend you do not connect any other SCSI peripherals to the same board. Connecting
the PlexWriter 4/12 to a parallel-to-SCSI or to the SCSI interface on a soundboard is
not recommended.
5.75" x 8.25" PLEX WRITER MANUAL
Plextor Manual, Carla Williams
1/2/98
---- CHAPTER 8 ----
PX-R412CS OPERATION MANUAL
21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 412-2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Plextor 412-2

Summary of Contents for Plextor 412-2

  • Page 1 PlexWriter 4/12 uses a SCSI interface as its link. Plextor strongly recommends the use of a high-performance bus-mastering SCSI interface board (ISA or PCI). You probably purchased a Plextor kit with such a board included. If you purchased your PlexWriter 4/12 without a SCSI interface board and want to connect it to a non-bus-mastering interface board (PIO), we strongly recom- mend you do not connect any other SCSI peripherals to the same board.

  • Page 2: Board Installation

    Before proceeding, make sure the power to your computer and any external peripherals is OFF and your computer is UNPLUGGED from its power source. PX-R412CS OPERATION MANUAL 5.75" x 8.25" PLEX WRITER MANUAL Plextor Manual, Carla Williams 1/2/98...
  • Page 3 Don’t force it. If you cannot push the board down completely into the slot, remove the board and try again. PX-R412CS OPERATION MANUAL 5.75" x 8.25" PLEX WRITER MANUAL Plextor Manual, Carla Williams 1/2/98...
  • Page 4 CHAPTER 8 ---- Hardware Installation Once you have successfully inserted the board, fasten it in place using the cover plate screw that you removed earlier. PX-R412CS OPERATION MANUAL 5.75" x 8.25" PLEX WRITER MANUAL Plextor Manual, Carla Williams 1/2/98...

  • Page 5: Mounting An Internal Drive

    Do not mount your drive in your computer using screws other than those supplied by Plextor. You may damage the drive if you insert screws that are too long. If you find that you are having difficulty inserting or ejecting a caddy from your drive, the cause may be that you are using screws other than those supplied by Plextor.
  • Page 6 SCSI ID and/or remove the termination resistors. See Chapters 6 and 7 for information on how to change these settings. PX-R412CS OPERATION MANUAL 5.75" x 8.25" PLEX WRITER MANUAL Plextor Manual, Carla Williams 1/2/98...
  • Page 7 Double-check your work; you must ensure the side of the SCSI cable with the red stripe is matched to Pin 1 on the interface board and on the drive. PX-R412CS OPERATION MANUAL 5.75" x 8.25" PLEX WRITER MANUAL Plextor Manual, Carla Williams 1/2/98...
  • Page 8 Y-connector. (Of course, you will lose the use of your 5.25" drive until you buy a splitter/Y-connector.) PX-R412CS OPERATION MANUAL 5.75" x 8.25" PLEX WRITER MANUAL Plextor Manual, Carla Williams 1/2/98...

  • Page 9: External Drive Installation

    See Chapters 6 and 7 for information on how to change these settings. If you are installing a single PX-R412CSe external drive, connect it as shown on the next page. Cross-ref. PX-R412CS OPERATION MANUAL 5.75" x 8.25" PLEX WRITER MANUAL Plextor Manual, Carla Williams 1/2/98...

  • Page 10: Mac Connection

    SCSI Interface Board SCSI Cable Personal Computer PX-R412CSe Rear Panel AC Power Supply Mac Connection (rear view of a Mac) Plugs into SCSI Cable Plugs into PX-R412CS OPERATION MANUAL 5.75" x 8.25" PLEX WRITER MANUAL Plextor Manual, Carla Williams 1/2/98...
  • Page 11 PC Connection & Mac Connection ---- Multiple Drives SCSI Cable Personal Computer 50-pin High Density (No terminator) SCSI Interface Board Daisy Chain Cable (No terminator) (Termination enabled using DIP switch setting) PX-R412CS OPERATION MANUAL 5.75" x 8.25" PLEX WRITER MANUAL Plextor Manual, Carla Williams 1/2/98...

  • Page 12: Audio Cables

    (see listing, p. 44) who offer audio cables and can get them to you quickly at a reasonable price. Call our Technical Support Department directly at 800-886-3935. Please see next page for diagrams illustrating the cable connections. PX-R412CS OPERATION MANUAL 5.75" x 8.25" PLEX WRITER MANUAL Plextor Manual, Carla Williams 1/2/98...
  • Page 13 CD-ROM drive for applications requiring the soundboard. If this is the case, you should connect an audio cable between your soundboard and your CD-ROM drive, not your CD-R drive. PX-R412CS OPERATION MANUAL 5.75" x 8.25" PLEX WRITER MANUAL Plextor Manual, Carla Williams 1/2/98...

  • Page 14: Software Device Driver Installation

    CD-ROM device driver files in Windows 95 or OS/2 Warp, as well as the DOS/Windows driver provided in Plextor Manager. Even if you are not running DOS or Windows 3.11 and do not need the Plextor Manager device driver, there are other valuable utilities provided with Plextor Manager. We recommend you review the separate manual for this software to determine if you want to install these utilities.
  • Page 15 CHAPTER 9 ---- Software Device Driver Installation contact the host adapter manufacturer who should have provided the required *.MPD file. If you bought a PlexWriter kit with a SCSI host adapter, Plextor has included the applicable ASPI Manager and *.MPD files with your Plextor Manager software.
