Plextor 8PL-3 Operation Manual

Using CD-ROM Discs
and Caddies
YOUR TASK: Learn how to use a caddy and how to handle and
care for your discs.
YOUR OBJECTIVE:
Protect your discs. Insert and eject caddies properly
so your drive operates without interruption.
YOUR METHOD: Practice loading discs into caddies and caddies into
drives.
Plextor's CD-ROM drives use an industry-standard disc caddy to protect the disc from
scratches and contamination. A standard caddy is made of plastic and has a metal
shutter on its bottom which slides open and shut. Plextor is also constantly evaluating
other caddy designs for possible use in the future. Unless provided or recommended
by Plextor, use of a non-standard caddy (e.g., one that lacks a metal shutter on its
bottom) is not recommended. For their protection, CD-ROM discs should be stored in
their original packaging or in a caddy.
Inserting the Disc into a Caddy
1) To open the lid of the caddy,
press the tabs at the side
as shown.
2) Place the disc into the caddy
with the label facing UP.
Be sure to place the disc
beneath the edge of the
caddy under the arrow mark.
Handle the disc by the sides.
Don't touch its surface.
40
PX-83CS/PX-85CS OPERATION MANUAL
---- CHAPTER 10 ----
